WLAN throughout the house
The dLAN Wireless extender transmits data using
the existing 230V power circuit as well as via wire-
less LAN. With the dLAN Wireless extender, every
power socket becomes a WLAN connection – even
through thick concrete walls. Ideal if you want to
extend your Internet connection wirelessly, or
expand your home network. Several PCs and note-
books can access the network wirelessly at the
same time using dLAN Wireless extenders (used as
an access point). Similarly, the wireless connection
Connection of dLAN and WLAN
dLAN
Highspeed
Ethernet
et
Eth ern
dLA N 85
PE ED
HIG HS
Simple installation
1 2
Each socket in your
home becomes a
network interface
devolo AG Deutschland
Sonnenweg 11, 52070 Aachen
Tel. : +49 (0)241-18279-79
Fax : +49 (0)241-18279-99
E-Mail: info@devolo.de
Web: www.devolo.com
can be transmitted from one WLAN router using
the dLAN Wireless extender in the power circuit
(used as client bridging).
The exchange of data and surfing on the Internet
are possible with up to 85 Mbit/s via the power
circuit and with up to 54 Mbit/s via wireless LAN.
Ultimate security is provided through DES pro
encryption on the power circuit and WEP, WPA or
WPA2 encryption via WLAN. It couldn't be more
versatile or secure!
dLAN Wireless
extender
dLAN
Highspeed Ethernet
Eth ern et
dLA N
PE ED 85
HIG HS
Modem-Router
3
Eth ern et
dLA N
PE ED 85
HIG HS
ory
Fact ult 9V DC
Defa
ETH
DSL
Connect PC, router or Modem
via the WLAN interface or
Ethernet interface
®
dLAN Wireless extender
4
Overview of technical data
Product highlights
•
Use as access point: Every socket becomes a WLAN access
point – optimum WLAN coverage throughout the house
•
Up to 85 Mbit/s transfer rate via the power circuit, up to
54 Mbit/s via wireless LAN
•
200 metre range via the power circuit, 300 metre range
via wireless LAN – wireless network and Internet access
in every room of the house
•
Ethernet interface for direct connection of a PC
•
Use as client: Data transmission from an access point to
the internal power circuit and thus connection of remote
PCs to the WLAN network
•
3 year manufacturer's warranty
Simple start-up and operation
•
Fast connection of the adapter, even for inexperien
ced users
•
No new cables, no drilling, no mess, simply plug into
the socket and you're ready to go!
•
No more problems with thick walls: now you can really
have wireless LAN in every room and on every floor
of your house
•
Free network connection or wireless LAN interface to PC,
notebook, modem or other network equipment
•
Run the user-friendly, self-explanatory and multilingual
configuration software to assign a password, and you're
done.
Security features
•
dLAN Wireless extender guarantees a high degree of data
security via the power circuit thanks to powerful DES pro
encryption.
•
There is also secure WEP, WPA, WPA2 encryption via WLAN
Complete package contents
•
dLAN Wireless extender
•
Starter Kit also with dLAN Highspeed Ethernet and
Ethernet cable
•
Printed instruction manual
•
CD-ROM with PDF manual, configuration software for
® ®
Windows XP/Vista , Mac OS X and Linux
32BIT
•
3 year manufacturer's warranty
®
