Connection and installation
Technical requirements
b
b
2.2.1

Initial use

| |
dsl+ 1100 WLAN
|
+
dsl 1100 WLAN
+
To use your dsl 1100 WLAN, you need a computer with an operating
system that provides network support with web browser (e.g. Windows
2000, Windows XP, Mac OS X, Linux) connected to the dsl
WLAN.
WLAN USB stick
A computer running the Windows 2000 or Windows XP (32-bit) oper-
ating system is required when using the devolo WLAN USB stick and
automatic WLAN configuration (WECT).
Remove the rear panel of the device.
Move the WLAN antenna of the dsl
Use the included mains power adapter to connect the dsl
power outlet.
Use the switch on the rear panel to turn the device on. The 'Power' LED will
light up on the front panel.
Use the DSL cable to connect the 'DSL' port of dsl
Internet service provider's DSL line.
+
1100 WLAN into an upright position.
+
+
1100 WLAN to your
+
1100
1100 WLAN to a
