- Page 1 4-Port Digital Input I/O Gateway SIG-5441 User Manual Version 1.1 Sollae Systems https://www.ezTCP.com...
- Page 2 SIG-5441 User Manual Ver. 1.1 This symbol, found on your product or on its packaging, indicates that this product should not be treated as household waste when you wish to dispose of it. Instead, it should be handed over to an applicable collection point for the recycling of electrical and electronic equipment.
-
Page 3: Table Of Contents
SIG-5441 User Manual Ver. 1.1 Contents Overview......................- 4 - 1.1 Introduction ............................- 4 - 1.2 Features..............................- 4 - 1.3 Specification ............................- 5 - 1.4 Interface ............................... - 6 - 1.4.1 Power ................................- 6 - 1.4.2 Ethernet ................................. - 7 - 1.4.3 Digital Input Port ............................ - Page 4 SIG-5441 User Manual Ver. 1.1 4.1.4 Copy status ............................... - 25 - 4.2 Firmware Change .......................... - 26 - 4.2.1 Online Upgrade ............................- 26 - 4.2.2 Manual Upgrade ............................ - 27 - 4.2.3 Remote Upgrade via cloud ....................... - 27 - 4.3 Console .............................
-
Page 5: Overview
Overview 1.1 Introduction SIG-5441 is an industrial I/O Gateway connected to Sollae Cloud. It is equipped with 4 digital input ports and an Ethernet interface. Users can remotely monitor digital values of sensors/devices connected to this product by using a web browser on your PC, tablet or smartphone. -
Page 6: Specification
SIG-5441 User Manual Ver. 1.1 1.3 Specification Digital Input Input Type Dry Contact / Wet Contact / NPN / PNP Input Voltage Range 4.5V ~ 25V Number of Ports 4 ports Network Physical Interface Network Interface 10Base-T/100Base-TX Ethernet (RJ45) Ethernet Speed Auto Sense... -
Page 7: Interface
SIG-5441 User Manual Ver. 1.1 1.4 Interface Figure 1-1 Interface 1.4.1 Power SIG-5441 requires DC5V power supply whose specification is as follows: Figure 1-2 Power - 6 - https://www.ezTCP.com... -
Page 8: Ethernet
SIG-5441 User Manual Ver. 1.1 1.4.2 Ethernet SIG-5441 provides 10/100Mbps Ethernet. The pin assignment is as follows: Figure 1-3 Ethernet 1.4.3 Digital Input Port This port is interfaced with a 3.5mm pitch 6-pole terminal block. Figure 1-4 Digital Input Port ⚫... - Page 9 SIG-5441 User Manual Ver. 1.1 ⚫ Circuit Diagram of Digital Input Figure 1-5 Circuit Diagram of Digital Input ⚫ WET contact Figure 1-6 WET contact - 8 - https://www.ezTCP.com...
- Page 10 SIG-5441 User Manual Ver. 1.1 ⚫ DRY contact Figure 1-7 DRY contact ⚫ NPN transistor Figure 1-8 NPN transistor - 9 - https://www.ezTCP.com...
- Page 11 SIG-5441 User Manual Ver. 1.1 ⚫ PNP transistor Figure 1-9 PNP transistor - 10 - https://www.ezTCP.com...
-
Page 12: Led
SIG-5441 User Manual Ver. 1.1 1.4.4 LED SIG-5441 provides 8 LEDs. Figure 1-10 4 LED LED operations according to each state are as follows: When the script is running: RUN When the script is running: RUN When a network is not connected: LINK When a network is connected: LINK When a MQTT connection is NOT established: MTX &... -
Page 13: Function Button
SIG-5441 User Manual Ver. 1.1 1.4.5 Function Button This button is used to implement a factory reset. 1.4.6 Setup Port This port is used for making a connection with a PC via USB cable. - 12 - https://www.ezTCP.com... -
Page 14: Preparation
SIG-5441 User Manual Ver. 1.1 Preparation 2.1 Installing the Setting Tool You need a Windows program which is called spFinder to use this product. Download the program on our web site and install it on your PC. Functions of the spFinder are as follows: ⚫... -
Page 15: Settings
SIG-5441 User Manual Ver. 1.1 Settings 3.1 Network 3.1.1 Obtain an IP address automatically This product can automatically obtain an IP address by DHCP. A DHCP server is required to use this. Figure 3-1 Obtain an IP address automatically ⚫ Select the [Obtain an IP address automatically]. -
Page 16: Use A Static Ip Address
SIG-5441 User Manual Ver. 1.1 3.1.2 Use a Static IP address You can set a static IP address to this product. Figure 3-2 Use a static IP address ⚫ Select the [Use static IP address]. ⚫ Set the [Local IP address], [Subnet mask], [Gateway IP address] and [DNS IP address]. -
Page 17: General
This setting is for storing the product description. The maximum setting size of this item is 32 bytes. We can add information such as: When a device is registered to the cloud, this field will be used as the default device description on Sollae Cloud. - 16 -... -
Page 18: Digital Input
Valid Time, Counter Type, Counter Direction, and Default Count Value can also be set via Sollae Cloud after the device is registered under an account. User Interface and other features configurations can only be set via Sollae Cloud. - 17 -... -
Page 19: Security
SIG-5441 User Manual Ver. 1.1 3.3 Security Figure 3-4 Security 3.3.1 Password Both ID and password are required to access this product. Note that changing the default password to another is highly recommended for security. The password should be longer than 8 characters. - Page 20 SIG-5441 User Manual Ver. 1.1 set only when the product is connected via USB. - 19 - https://www.ezTCP.com...
-
Page 21: Client Id
If this item is checked, the product can be connected from the remote network. For security, this item is unchecked by default. 3.3.4 Client ID The Unique ID which is used to register the device under your account in Sollae Cloud. See more detail on Sollae Cloud. -
Page 22: Management
SIG-5441 User Manual Ver. 1.1 Management 4.1 Checking Status This is a function to view the current status of the product. Information in the [Status] window is automatically updated every second. After searching and connecting the product with spFinder, press the [Status] button to display this window. When you open this window, the spFinder connects to the product and keeps the connection until you close the window or time out. - Page 23 SIG-5441 User Manual Ver. 1.1 Gateway Assigned gateway IP address Assigned DNS server IP address Table 4-1 Product Information List - 22 - https://www.ezTCP.com...
-
Page 24: Communication Status
This area shows some communication status of your product. This area is refreshed every second. Figure 4-2 Communication Status Window ⚫ REGISTRATION STATE The registration state indicates whether the device is registered on Sollae Cloud under an account or not Status Description... - Page 25 SIG-5441 User Manual Ver. 1.1 CONNECTED Table 4-3 SSL STATE - 24 - https://www.ezTCP.com...
-
Page 26: Timeout
SIG-5441 User Manual Ver. 1.1 ⚫ DEVICE STATE The device operation state. Status STARTING UPDATING INFORMATION TO CLOUD FAILED TO UPDATE INFORMATION TO CLOUD DEVICE IS UNREGISTERED TO AN USER CONNECTING MQTT SERVER MQTT CLOSED MQTT CONNECTED TO CLOUD MQTT PING TO CLOUD... -
Page 27: Firmware Change
SIG-5441 User Manual Ver. 1.1 4.2 Firmware Change New firmware can be released when adding functions or fixing bugs. If you are using old firmware, you can upgrade it to the latest version. Firmware can be upgraded online or manually via spFinder, or remotely via Cloud. -
Page 28: Manual Upgrade
SIG-5441 User Manual Ver. 1.1 4.2.2 Manual Upgrade Figure 4-4 Manual Upgrade ⚫ Download a Firmware file to your PC. ⚫ Search and connect to your product by spFinder. ⚫ Click [Advanced] > [Firmware Change] menu. ⚫ Select to [Manual upgrade] on the [Firmware Upgrade] window. -
Page 29: Console
SIG-5441 User Manual Ver. 1.1 4.3 Console The console function analyzes and displays the the device’s operation status and log. After searching and connecting the product with spFinder, click [Console] in the [Advanced] menu to display the console window. When you open this window, the spFinder connects to the product and keeps the connection until you close the window or time out. -
Page 30: Fw Log Tab
SIG-5441 User Manual Ver. 1.1 4.3.2 FW Log Tab This tab displays the log message from Firmware. 4.3.3 Timeout This is the timeout display function that appears in the upper right of the console window. When this time reaches zero, the connection between spFinder and the product is lost. -
Page 31: Export/Import Setting Values
SIG-5441 User Manual Ver. 1.1 4.4 Export/Import Setting Values The [Export setting values] menu saves setting values of your product as a file. The password is not included in the file. The [Import setting values] menu loads a setting values from a file which is saved by the [Export setting values] menu. -
Page 32: Factory Reset
SIG-5441 User Manual Ver. 1.1 4.5 Factory Reset Performing the Factory Reset, you can restore all the settings to the default including the password. Follow the procedure below by checking the status of RUN LED. 1. Press and immediately release the function button. -
Page 33: Technical Support And Warranty
Technical Support and Warranty Technical Support If you have any question regarding operation of the product, visit Customer Support FAQ corner and the message board on Sollae Systems’ web site or send us an email at the following address: ⚫ E-mail: support@eztcp.com... -
Page 34: Precaution And Exemption From Liability
⚫ Do not use the product for a purpose that requires exceptional quality and reliability relating to user’s injuries or accidents – aerospace, aviation, health care, nuclear power, transportation, and safety purposes. ⚫ Sollae Systems is not responsible for any accident or damage occurring while using the product. - 33 -... -
Page 35: Exemption From Liability
Sollae Systems Co., Ltd. and its distributors entire liability and your exclusive remedy shall be Sollae Systems Co., Ltd. and its distributors option for the return of the price paid for, or repair, or replacement of the SIG-5441. -
Page 36: French Version
à caractère commercial ou de toute autre perte financière) provenant de l'utilisation ou de l'incapacité à pouvoir utiliser le boîtier SIG-5441, même si Sollae Systems Co., Ltd. ou un de ses distributeurs a été informé de la possibilité de tels dommages. - Page 37 SIG-5441 sans que la responsabilité de Sollae Systems Co., Ltd. et de ses distributeurs ne puissent être mise en cause, ni que le boîtier SIG-5441 puisse être échangé au titre de la garantie.
-
Page 38: Revision History
SIG-5441 User Manual Ver. 1.1 Revision History Date Version Description Author 2020.12.02. 1. Created Khanh 2021.09.08 1. Change condition of digital input volt range Amy Kim - 37 - https://www.ezTCP.com...
