- Page 1 2-Port Digital Output I/O Gateway SIG-5451 User Manual Version 1.0 Sollae Systems https://www.ezTCP.com...
- Page 2 SIG-5451 User Manual Ver. 1.0 This symbol, found on your product or on its packaging, indicates that this product should not be treated as household waste when you wish to dispose of it. Instead, it should be handed over to an applicable collection point for the recycling of electrical and electronic equipment.
-
Page 3: Table Of Contents
SIG-5451 User Manual Ver. 1.0 Contents Overview ............- 4 - 1.1 Introduction ............- 4 - 1.2 Features ............- 4 - 1.3 Specification ............- 5 - 1.4 Interface ............- 6 - 1.4.1 Power ..............- 6 - 1.4.2 Ethernet ............... - Page 4 SIG-5451 User Manual Ver. 1.0 4.3.1 Output Tab ............- 21 - 4.3.2 FW Log Tab ............- 22 - 4.3.3 Timeout ............... - 22 - 4.4 Export/Import Setting Values ........- 23 - 4.5 Factory Reset ............- 24 - Technical Support and Warranty ........
-
Page 5: Overview
Overview 1.1 Introduction SIG-5451 is an industrial I/O Gateway connected to Sollae Cloud. It is equipped with 2 digital output ports and an Ethernet interface. Users can use this product to control remote devices by using a web browser on your PC, tablet or smartphone. -
Page 6: Specification
SIG-5451 User Manual Ver. 1.0 1.3 Specification Digital Output Output Type Relay (Type C - NO/NC, Max DC 30V/2A with resistive load) Number of Ports 2 ports Network Physical Interface Network Interface 10Base-T/100Base-TX Ethernet (RJ45) Ethernet Speed Auto Sense 1:1 or Cross-over Cable Auto Sense... -
Page 7: Interface
SIG-5451 User Manual Ver. 1.0 1.4 Interface Figure 1-1 Interface 1.4.1 Power SIG-5451 requires DC5V power supply whose specification is as follows: Figure 1-2 Power - 6 - https://www.ezTCP.com... -
Page 8: Ethernet
SIG-5451 User Manual Ver. 1.0 1.4.2 Ethernet SIG-5451 provides 10/100Mbps Ethernet. The pin assignment is as follows: Figure 1-3 Ethernet 1.4.3 Digital Output Port This port is interfaced with a 3.5mm pitch 6-pole terminal block. Figure 1-4 Digital output port ⚫... -
Page 9: Led
SIG-5451 User Manual Ver. 1.0 1.4.4 LED SIG-5451 provides 8 LEDs. Figure 1-5 4 LED operations according to each state are as follows: When the supplied power is stable: PWR When the supplied power is NOT stable: PWR When the script is running: RUN... -
Page 10: Function Button
SIG-5451 User Manual Ver. 1.0 1.4.5 Function Button This button is used to implement a factory reset. 1.4.6 Setup Port This port is used for making a connection with a PC via USB cable. - 9 - https://www.ezTCP.com... -
Page 11: Preparation
SIG-5451 User Manual Ver. 1.0 Preparation 2.1 Installing the Setting Tool You need a Windows program which is called spFinder to use this product. Download the program on our web site and install it on your PC. Functions of the spFinder are as follows: ⚫... -
Page 12: Settings
SIG-5451 User Manual Ver. 1.0 Settings 3.1 Network 3.1.1 Obtain an IP address automatically This product can automatically obtain an IP address by DHCP. A DHCP server is required to use this. Figure 3-1 Obtain an IP address automatically ⚫ Select the [Obtain an IP address automatically]. -
Page 13: Use A Static Ip Address
SIG-5451 User Manual Ver. 1.0 3.1.2 Use a Static IP address You can set a static IP address to this product. Figure 3-2 Use a static IP address ⚫ Select the [Use static IP address]. ⚫ Set the [Local IP address], [Subnet mask], [Gateway IP address] and [DNS IP address]. -
Page 14: General
This setting is for storing the product description. The maximum setting size of this item is 32 bytes. We can add information such as: When a device is registered to the cloud, this field will be used as the default device description on Sollae Cloud. -
Page 15: Security
SIG-5451 User Manual Ver. 1.0 3.3 Security Figure 3-4 Security 3.3.1 Password Both ID and password are required to access this product. Note that changing the default password to another is highly recommended for security. The password should be longer than 8 characters. -
Page 16: Client Id
If this item is checked, the product can be connected from the remote network. For security, this item is unchecked by default. 3.3.4 Client ID The Unique ID which is used to register the device under your account in Sollae Cloud. See more detail on Sollae Cloud. -
Page 17: Management
SIG-5451 User Manual Ver. 1.0 Management 4.1 Checking Status This is a function to view the current status of the product. Information in the [Status] window automatically updated every second. After searching connecting the product with spFinder, press the [Status] button to display this window. -
Page 18: Communication Status
This area shows some communication status of your product. This area is refreshed every second. Figure 4-2 Communication Status Window ⚫ REGISTRATION STATE The registration state indicates whether the device is registered on Sollae Cloud under an account or not. Status Description... -
Page 19: Timeout
SIG-5451 User Manual Ver. 1.0 ⚫ DEVICE STATE The device operation state. Status STARTING UPDATING INFORMATION TO CLOUD FAILED TO UPDATE INFORMATION TO CLOUD DEVICE IS UNREGISTERED TO AN USER CONNECTING MQTT SERVER MQTT CLOSED MQTT CONNECTED TO CLOUD MQTT PING TO CLOUD... -
Page 20: Firmware Change
SIG-5451 User Manual Ver. 1.0 4.2 Firmware Change New firmware can be released when adding functions or fixing bugs. If you are using old firmware, you can upgrade it to the latest version. Firmware can be upgraded online or manually via spFinder, or remotely via Cloud. -
Page 21: Manual Upgrade
SIG-5451 User Manual Ver. 1.0 4.2.2 Manual Upgrade Figure 4-4 Manual Upgrade ⚫ Download a Firmware file to your PC. ⚫ Search and connect to your product by spFinder. ⚫ Click [Advanced] > [Firmware Change] menu. ⚫ Select to [Manual upgrade] on the [Firmware Upgrade] window. -
Page 22: Console
SIG-5451 User Manual Ver. 1.0 4.3 Console The console function analyzes and displays the the device’s operation status and log. After searching and connecting the product with spFinder, click [Console] in the [Advanced] menu to display the console window. When you open this window, the spFinder connects to the product and keeps the connection until you close the window or time out. -
Page 23: Fw Log Tab
SIG-5451 User Manual Ver. 1.0 4.3.2 FW Log Tab This tab displays the log message from Firmware. 4.3.3 Timeout This is the timeout display function that appears in the upper right of the console window. When this time reaches zero, the connection between spFinder and the product is lost. -
Page 24: Export/Import Setting Values
SIG-5451 User Manual Ver. 1.0 4.4 Export/Import Setting Values The [Export setting values] menu saves setting values of your product as a file. The password is not included in the file. The [Import setting values] menu loads a setting values from a file which is saved by the [Export setting values] menu. Find these functions at the [Advanced] menu. -
Page 25: Factory Reset
SIG-5451 User Manual Ver. 1.0 4.5 Factory Reset Performing the Factory Reset, you can restore all the settings to the default including the password. Follow the procedure below by checking the status of RUN LED. 1. Press and immediately release the function button. -
Page 26: Technical Support And Warranty
Technical Support and Warranty 5.1 Technical Support If you have any question regarding operation of the product, visit Customer Support FAQ corner and the message board on Sollae Systems’ web site or send us an email at the following address: ⚫ E-mail: support@eztcp.com... -
Page 27: Precaution And Exemption From Liability
⚫ Specifications of the product are subject to change without prior notice for performance improvement. ⚫ Sollae Systems does not guarantee successful operation of the product if the product was used under conditions deviating from the product specifications. ⚫ Reverse engineering of firmware and applications provided by Sollae Systems is prohibited. -
Page 28: Exemption From Liability
(including, without limitation, damages for loss of profit, operating cost for commercial interruption, loss of information, or any other financial loss) from the use or inability to use the SIG-5451 even if Sollae Systems Co., Ltd. or its distributors have been informed of such damages. -
Page 29: French Version
à leur propriétaire et Fabricant respectif. ⚫ Conditions d’utilisations et limite de responsabilité En aucun cas Sollae Systems Co., Ltd. ou un de ses distributeurs ne pourra être tenu responsable de dommages quels qu'ils soient (intégrant, mais sans limitation, dommages... - Page 30 SIG-5451 sans que la responsabilité de Sollae Systems Co., Ltd. et de ses distributeurs ne puissent être mise en cause, ni que le boîtier SIG-5451 puisse être échangé au titre de la garantie.
-
Page 31: Revision History
SIG-5451 User Manual Ver. 1.0 Revision History Date Version Description Author 2020.12.02. 1. Created Khanh - 30 - https://www.ezTCP.com...
