- Page 1 4-Port I/O Gateway SIG-5601 User Manual Version 1.1 Sollae Systems https://www.ezTCP.com...
- Page 2 SIG-5601 User Manual Ver. 1.1 This symbol, found on your product or on its packaging, indicates that this product should not be treated as household waste when you wish to dispose of it. Instead, it should be handed over to an applicable collection point for the recycling of electrical and electronic equipment.
-
Page 3: Table Of Contents
SIG-5601 User Manual Ver. 1.1 Contents Overview......................- 4 - 1.1 Introduction ............................- 4 - 1.2 Features..............................- 4 - 1.3 Specification ............................- 5 - 1.4 Interface ............................... - 7 - 1.4.1 Power ................................- 7 - 1.4.2 Ethernet ................................. - 8 - 1.4.3 Setup Port .............................. - Page 4 SIG-5601 User Manual Ver. 1.1 3.4.3 spFinder ..............................- 23 - 3.4.4 Client ID ..............................- 25 - Management ....................- 26 - 4.1 Checking Status ..........................- 26 - 4.1.1 Product Information ..........................- 26 - 4.1.2 Communication Status ........................- 27 - 4.1.3 Timeout ..............................
-
Page 5: Overview
Overview 1.1 Introduction SIG-5601 is an industrial I/O gateway connected to Sollae Cloud. It is equipped with 4 analog input ports, 4 digital input ports, 4 digital output ports, an Ethernet and a WiFi interface. Users can remotely monitor the values of sensors/devices connected to the digital and analog input ports of this product, as well as control the devices connected to the digital output ports by using a web browser on your PC, tablet or smartphone. -
Page 6: Specification
SIG-5601 User Manual Ver. 1.1 1.3 Specification Digital Input Input Type Dry Contact / Wet Contact / NPN / PNP Input Voltage Range 4.5V ~ 25V Number of Ports 4 ports Digital Output Relay (Type C - NO: Max DC 30V/5A with resistive load, NC: Max... - Page 7 SIG-5601 User Manual Ver. 1.1 Registration (KN 32, KN 35) EMC 2014/30/EU, RoHS 2011/65/EU FCC Part 15 Subpart B, Class A Table 1-1 Specification - 6 - https://www.ezTCP.com...
-
Page 8: Interface
SIG-5601 User Manual Ver. 1.1 1.4 Interface Figure 1-1 Interface 1.4.1 Power ⚫ PWR1 Port This port is one of the main input ports for supplying power (DC 8.5V ~ 38V). This port is interfaced with a 2-pole terminal block. -
Page 9: Ethernet
SIG-5601 User Manual Ver. 1.1 1.4.2 Ethernet SIG-5601 provides 10/100Mbps Ethernet. The pin assignment is as follows: Figure 1-3 Ethernet 1.4.3 Setup Port This port is used for making a connection with a PC via USB cable. 1.4.4 Function Button This button is used to implement a factory reset. -
Page 10: Led
SIG-5601 User Manual Ver. 1.1 1.4.6 LED LED operations according to each state are as follows: When the supplied power is stable: PWR When the supplied power is NOT stable: PWR When the script is running: RUN When the script is running: RUN... -
Page 11: Digital Output Port
SIG-5601 User Manual Ver. 1.1 1.4.7 Digital Output Port This port is interfaced with a 5mm pitch 12-pole terminal block. Figure 1-5 Digital output port ⚫ Port Specification Division Value Number of ports Max. Allowed Current Normal Open at DC 30V... -
Page 12: Digital Input Port
SIG-5601 User Manual Ver. 1.1 1.4.8 Digital Input Port This port is interfaced with a 5mm pitch 8-pole terminal block. Figure 1-6 Digital Input Port ⚫ Port Specification Division Value Number of ports Maximum Input Voltage DC 25V Voltage Required for HIGH decision higher than DC 4.5V... - Page 13 SIG-5601 User Manual Ver. 1.1 Figure 1-7 Circuit Diagram of Digital Input - 12 - https://www.ezTCP.com...
- Page 14 SIG-5601 User Manual Ver. 1.1 ⚫ WET contact Figure 1-8 WET contact ⚫ DRY contact Figure 1-9 DRY contact - 13 - https://www.ezTCP.com...
-
Page 15: Usb Host Port
SIG-5601 User Manual Ver. 1.1 ⚫ NPN transistor Figure 1-10 NPN transistor ⚫ PNP transistor Figure 1-11 PNP transistor 1.4.9 USB Host Port This port is for connecting a USB wireless LAN adapter. You can connect your product to IEEE802.11b/g wireless LAN with connecting a USB wireless LAN adapter to this port. -
Page 16: Preparation
SIG-5601 User Manual Ver. 1.1 Preparation 2.1 Installing the Setting Tool You need a Windows program which is called spFinder to use this product. Download the program on our web site and install it on your PC. Functions of the spFinder are as follows: ⚫... -
Page 17: Settings
SIG-5601 User Manual Ver. 1.1 Settings 3.1 Network 3.1.1 Obtain an IP address automatically This product can automatically obtain an IP address by DHCP. A DHCP server is required to use this. Figure 3-1 Obtain an IP address automatically ⚫ Select the [Obtain an IP address automatically]. -
Page 18: Use A Static Ip Address
SIG-5601 User Manual Ver. 1.1 3.1.2 Use a Static IP address You can set a static IP address to this product. Figure 3-2 Use a static IP address ⚫ Select the [Use static IP address]. ⚫ Set the [Local IP address], [Subnet mask], [Gateway IP address] and [DNS IP address]. -
Page 19: Wlan
SIG-5601 User Manual Ver. 1.1 3.2 WLAN WLAN setting is only for connecting your product to a wireless LAN. Make sure to connect a USB wireless LAN adapter before you set it. Note: Ethernet connectivity of your product is disabled when you using the wireless ... - Page 20 SIG-5601 User Manual Ver. 1.1 ⚫ Click the [Save] button. - 19 - https://www.ezTCP.com...
-
Page 21: Advanced Settings
SIG-5601 User Manual Ver. 1.1 3.2.2 Advanced Settings You can configure advanced settings for WLAN by clicking the [Advanced Settings] button. We recommend using the default values if you do not have any problem with it. ⚫ PHY Mode You have three options for PHY mode and those are [802.11], [802.11b] and [802.11b/g] mode. -
Page 22: General
This item selects the analog input type. The setting value can be selected among [0 ~ 5V], [4 ~ 20mA] and [0 ~ 20mA]. The default value is [0 ~ 5V]. The analog input mode can be set via spFinder only. It is impossible to set via Sollae ... -
Page 23: Digital Output
Sollae Cloud is lost, if Fail-Safe is enabled, the output port is set to LOW, otherwise the output port keeps the current state. The fail-safe mode can be set via spFinder only. It is impossible to set via Sollae ... -
Page 24: Security
SIG-5601 User Manual Ver. 1.1 3.4 Security Figure 3-6 Security 3.4.1 Password Both ID and password are required to access this product. Note that changing the default password to another is highly recommended for security. The password should be longer than 8 characters. - Page 25 SIG-5601 User Manual Ver. 1.1 set only when the product is connected via USB. - 24 - https://www.ezTCP.com...
-
Page 26: Client Id
If this item is checked, the product can be connected from the remote network. For security, this item is unchecked by default. 3.4.4 Client ID The Unique ID which is used to register the device under your account in Sollae Cloud. See more detail on Sollae Cloud. -
Page 27: Management
SIG-5601 User Manual Ver. 1.1 Management 4.1 Checking Status This is a function to view the current status of the product. Information in the [Status] window is automatically updated every second. After searching and connecting the product with spFinder, press the [Status] button to display this window. When you open this window, the spFinder connects to the product and keeps the connection until you close the window or time out. -
Page 28: Communication Status
SIG-5601 User Manual Ver. 1.1 ⚫ Product Information List Item Description Product name Product name Pkgware Model name, package version, Firmware version File name File name Uptime Elapsed time since it boots up (day / hour:min:sec) IPv4 Assigned IPv4 address... - Page 29 SIG-5601 User Manual Ver. 1.1 ⚫ REGISTRATION STATE The registration state indicates whether the device is registered on Sollae Cloud under an account or not. Status Description checking Checking the registration status unregistered The device is unregistered under any account...
- Page 30 SIG-5601 User Manual Ver. 1.1 20mA, or 0 to 20mA in 0~5V, 4~20mA, or 0~20mA input types, respectively. This value may be rescaled by Sollae Cloud to other measurement (e.g., temperature, humidity…) to be displayed on the Cloud. Table 4-5 ANALOG INPUT - 29 - https://www.ezTCP.com...
-
Page 31: Timeout
SIG-5601 User Manual Ver. 1.1 ⚫ DIGITAL OUTPUT Shows the state of digital output ports. Item Description DO0~3 Current state of each digital output port Table 4-6 DIGITAL OUTPUT ⚫ DIGITAL INPUT Shows the state and counter’s value of digital input ports. -
Page 32: Firmware Change
SIG-5601 User Manual Ver. 1.1 4.2 Firmware Change New firmware can be released when adding functions or fixing bugs. If you are using old firmware, you can upgrade it to the latest version. Firmware can be upgraded online or manually via spFinder, or remotely via Cloud. -
Page 33: Manual Upgrade
SIG-5601 User Manual Ver. 1.1 4.2.2 Manual Upgrade Figure 4-4 Manual Upgrade ⚫ Download a Firmware file to your PC. ⚫ Search and connect to your product by spFinder. ⚫ Click [Advanced] > [Firmware Change] menu. ⚫ Select to [Manual upgrade] on the [Firmware Upgrade] window. -
Page 34: Console
SIG-5601 User Manual Ver. 1.1 4.3 Console The console function analyzes and displays the the device’s operation status and log. After searching and connecting the product with spFinder, click [Console] in the [Advanced] menu to display the console window. When you open this window, the spFinder connects to the product and keeps the connection until you close the window or time out. -
Page 35: Fw Log Tab
SIG-5601 User Manual Ver. 1.1 4.3.2 FW Log Tab This tab displays the log message from Firmware. 4.3.3 Timeout This is the timeout display function that appears in the upper right of the console window. When this time reaches zero, the connection between spFinder and the product is lost. -
Page 36: Export/Import Setting Values
SIG-5601 User Manual Ver. 1.1 4.4 Export/Import Setting Values The [Export setting values] menu saves setting values of your product as a file. The password is not included in the file. The [Import setting values] menu loads a setting values from a file which is saved by the [Export setting values] menu. -
Page 37: Factory Reset
SIG-5601 User Manual Ver. 1.1 4.5 Factory Reset Performing the Factory Reset, you can restore all the settings to the default including the password. Follow the procedure below by checking the status of RUN LED. 1. Press and immediately release the function button. -
Page 38: Technical Support And Warranty
Technical Support and Warranty Technical Support If you have any question regarding operation of the product, visit Customer Support FAQ corner and the message board on Sollae Systems’ web site or send us an email at the following address: ⚫ E-mail: support@eztcp.com... -
Page 39: Precaution And Exemption From Liability
⚫ Do not use the product for a purpose that requires exceptional quality and reliability relating to user’s injuries or accidents – aerospace, aviation, health care, nuclear power, transportation, and safety purposes. ⚫ Sollae Systems is not responsible for any accident or damage occurring while using the product. - 38 -... -
Page 40: Exemption From Liability
Sollae Systems Co., Ltd. and its distributors entire liability and your exclusive remedy shall be Sollae Systems Co., Ltd. and its distributors option for the return of the price paid for, or repair, or replacement of the SIG-5601. -
Page 41: French Version
à caractère commercial ou de toute autre perte financière) provenant de l'utilisation ou de l'incapacité à pouvoir utiliser le boîtier SIG-5601, même si Sollae Systems Co., Ltd. ou un de ses distributeurs a été informé de la possibilité de tels dommages. - Page 42 SIG-5601 sans que la responsabilité de Sollae Systems Co., Ltd. et de ses distributeurs ne puissent être mise en cause, ni que le boîtier SIG-5601 puisse être échangé au titre de la garantie.
-
Page 43: Revision History
SIG-5601 User Manual Ver. 1.1 Revision History Date Version Description Author 2020.12.02. 1. Created Khanh 2021.09.08 1. Change condition of digital input volt range Amy Kim - 42 - https://www.ezTCP.com...
