COPYRIGHT Copyright 2021 Technimount E.M.S. Holding Inc. (Technimount), an affiliated company of Technologies CGC Inc. All Rights Reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Technimount or its affiliate companies.
CONTACT INFORMATION OFFICE ADDRESS Technimount E.M.S. Holding Inc.. 3770 Jean Marchand Street, Suite 100-C Quebec (QC) G2C 1Y6 Canada info@technimount.com www.technimount.com T + 1 888.639.2758 F + 1 855.339.6351 NOTE: For any issues with your Technimount product, its components, or for any technical questions during the installation or maintenance processes, please send an email to techsupport@technimount.com.
TABLE OF CONTENT COPYRIGHT ................................2 Legal Notice ...................................2 CONTACT INFORMATION ............................3 Symbols and Definitions ...............................6 Warning/Caution/Note ..............................7 Product Illustration ..............................8 Bracket Pro Serie 152 ............................8 Front View ..................................8 Back View ....................................9 INTRODUCTION ..............................10 Purpose of the Document ............................10 Product Description ..............................10 Intended Use of the Product .............................10 Limitation of Liability ..............................10 Technical Specifications..............................11...
Page 5
TABLE OF CONTENT RETURN POLICY ..............................26 Return Policy ................................26 Prior to 30 Days ..............................26 Prior 45 Days ................................26 Prior 60 Days ................................26 Return Authorization ..............................26 Damaged Merchandise ..............................27 Claim Process ................................27 Required Information ............................27 Findings and Conclusion .............................27 Questions about our Policy ............................27 www.technimount.com BP152 UG 202108-01...
INTRODUCTION SYMBOLS AND DEFINITIONS SYMBOL DESCRIPTION Warning and Caution, special attention is required. Consult accompanying documents Safe working load symbol and Load balance symbol Return to Table of Content BP152 UG 202108-01 www.technimount.com...
INTRODUCTION WARNING/CAUTION/NOTE The word warning, caution, or note carry special meaning and should be carefully reviewed. SYMBOL DESCRIPTION Warning Alerts the reader about a situation which, if not avoided, could result in death or serious injury. It may also describe potential serious adverse reactions and safety hazards.
INTRODUCTION PRODUCT ILLUSTRATION BRACKET PRO SERIE 152 Front View High-Density Aluminum with Top Support Block to Secure Black-Anodized Finish Medical Device Front Support Plate to Secure Medical Device Return to Table of Content BP152 UG 202108-01 www.technimount.com...
INTRODUCTION PRODUCT ILLUSTRATION (CONTINUED) BRACKET PRO SERIE 152 (SUITE) Back View Anti-Rotation Micro Disc for Rubber Cusions Inside the Bracket Installation on Vertical and to Protect the Medical Device Wall Mounting Systems Return to Table of Content www.technimount.com BP152 UG 202108-01s...
INTRODUCTION PURPOSE OF THE DOCUMENT This user guide is designed to assist you with the installation, operation and maintenance of the Technimount Bracket Pro Serie 152 for the Medfusion 4000 Syringe Infusion Pump from Smiths Medical. PRODUCT DESCRIPTION The Bracket Pro Serie 152 is a universal solution to mount the Smiths Medical Medfusion 4000 Syringe Infusion Pump in different applications such as, on surface, a vertical system, stretcher or wall systems.
INTRODUCTION TECHNICAL SPECIFICATIONS Product Name Bracket Pro Serie® 152 Product Description Bracket for Transport of Medfusion® 4000 on Stretcher during Neonatal Critical Care Compatibility of Medical Device* Smiths Medical® Medfusion® 4000 Syringe Infusion Pump Environment of Usage EMS/CCT (Ground) – Hospital/Clinic Product Section Material •...
9 It is the responsibility of the operator of the bracket or any of its options, to ensure equipment being used with the Technimount products meets the installation specifications. Injury may result if non-compatible products are used with Technimount System products. 9 Do not attempt to operate, install or remove the equipment while mobile. Ensure that installation and removal of equipment is done while vehicle or aircraft is immobilized.
Page 13
9 Inspect regularly all components on the equipment for any issue and loose screws, bolts and nuts. 9 Never install the mount into or on other similar mounting systems or brackets without written confirmation by Technimount System as these different systems may be from other brands or models and may not be compatible with Technimount System.
NOTICE/CERTIFICATION The Bracket Pro Serie® 152 is designed to comply with the essential requirements and other relevant provisions of the Directive 1999/5/EC and SAE J3043. For more information, please contact Technimount Customer Service (customerservice@technimount.com). Technimount E.M.S. Holding Inc. C/O: Regulatory Affairs 3770, Jean Marchand Street, Suite 100-C Quebec (QC) G2C 1Y6 Canada...
INSTALLATION GUIDE REMOVING THE PACKAGING FOR INSTALLATION 1. Unpack boxes and check all items are included for installation. 2. Ensure that all shipping and packaging materials have been properly removed from the product(s) prior to installation. 3. Identify all of the product components and hardware prior to starting the installation. 4.
INSTALLATION GUIDE IDENTIFICATION OF COMPONENTS FRONT SUPPORT PLATE The Black-Anodized Finish Aluminum support plate is used for the installation of the Syringe Infusion Pump Medfusion 4000. It allows to secure the medical device. HARDWARE KIT The following hardware is provided for the installation of the Bracket Pro Serie 152 : 9 Four (4) Black Oxide Stainless Steel Round Head Phillips Screws 10-32 x 3/8"...
INSTALLATION GUIDE INSTALLATION OF THE BRACKET ONTO THE MEDFUSION 4000 SYRINGE PUMP 1. The Bracket Pro Serie 152 is designed to be installed on the Medfusion 4000 Syringe Infusion Pump from Smiths Medical. 2. Install the main assembly on a stable surface. 3.
Page 18
INSTALLATION GUIDE INSTALLATION OF THE BRACKET ONTO THE MEDFUSION 4000 SYRINGE PUMP (CONTINUED) 4. Install the medical device into the main assembly. 5. Align the screws with the screws holes of the main assembly and front support plate. 6. Install the (4) Black Oxide Stainless Steel Round Head Phillips Screws 10-32 x 3/8"...
MAINTENANCE GUIDE CLEANING CLEANING PROCESS WARNING ENSURE TO REMOVE MEDICAL DEVICE FROM THE BRACKET IF THOROUGH CLEANING IS NEEDED. Follow your EMS service's protocol or medical device manufacturer's user guide for the recommended cleaning procedure of your medical devices. Cleaning procedure below does NOT provide recommendations for cleaning of the medical device.
MAINTENANCE GUIDE CLEANING (CONTINUED) CLEANING SOLUTIONS Phenolic type or quaternary type disinfectants can be used (excluding Virex® TB). Iodophor type disinfectants, Peracetic Acid, Chlorine, and especially Hydrogen Peroxide are not recommended for use because staining and corrosion may result. Suggested cleaners for the bracket: 9 Quaternary Cleaners (active ingredient - ammonium chloride) 9 Water and soft soap 9 A mild 10% bleach solution, a solution containing alcohol or a quaternary ammonium chloride solution.
MAINTENANCE GUIDE INSPECTION PROCESS AND SCHEDULE MAINTENANCE PROGRAM The following inspection routine and schedule is intended as a general guide for preventive maintenance of the bracket. Factors such as weather, environment, geographical location, and individual usage will necessitate different maintenance. If you are unsure as to how to perform these maintenance inspections or at what interval to perform these inspections, please contact your Technical Support Team at techsupport@technimount.com.
MAINTENANCE GUIDE INSPECTION AND MAINTENANCE RECORD PREVENTIVE MAINTENANCE DATE TIME PERFORMED Return to Table of Content BP152 UG 202108-01 www.technimount.com...
MAINTENANCE GUIDE TRAINING RECORD DATE TRAINING METHOD BASIC TRAINING TRAINEE NAME TRAINING UPDATE Return to Table of Content www.technimount.com BP152 UG 202108-01s...
MAINTENANCE GUIDE REPLACEMENT PARTS The parts and accessories listed are all currently available for purchase. Some of the parts identified on the assembly drawing parts in this user guide may not be individually available for purchase. Please call Technimount Customer Service: +1 888.639.2758 or at customerservice@technimount.com for availability and pricing.
WARRANTY WARRANTY POLICY This statement constitutes TECHNIMOUNT’s entire warranty policy with regards to the TECHNIMOUNT Products. TECHNIMOUNT MAKES NO OTHER WARRANTY OR REPRESENTATION NEITHER EXPRESSED NOR IMPLIED, EXCEPT AS SET FORTH HEREIN. THERE IS NO WARRANTY OF MERCHANTABILITY AND THERE ARE NO WARRANTIES OF FITNESS FOR ANY PARTICULAR PURPOSE.
Page 26
RETURN POLICY RETURN POLICY Mounting systems and bracket systems for portable medical devices may be returned up to 60 days of receipt if: ▪ The product is not what was originally ordered ▪ The product does not meet specifications with TECHNIMOUNT’s technical sheets according to the customer ▪...
Page 27
RETURN POLICY DAMAGED MERCHANDISE ICC Regulations require that claims for damaged merchandise must be made with the carrier within fifteen (15) days of receiving merchandise. DO NOT ACCEPT DAMAGED SHIPMENTS UNLESS SUCH DAMAGE IS NOTED ON THE DELIVERY RECEIPT AT THE TIME OF RECEIPT. Upon prompt notification, TECHNIMOUNT will file a freight claim with the appropriate carrier for damages incurred.
