Jamara Crossmo EP Instruction
Jamara Crossmo EP Instruction

Jamara Crossmo EP Instruction

Monstertruck 2,4 ghz

Advertisement

Quick Links

No. 053130 EP
No. 053131 EP LiPo
DE - Gebrauchsanleitung
GB - Instruction
DE - Allgemeine Hinweise
Jamara e. K. übernimmt keine Haftung für Schäden, die an dem Produkt selbst oder durch dieses
entstehen, sofern diese auf falsche Bedienung oder Handhabungsfehler zurückzuführen sind. Der
Kunde allein trägt die volle Verantwortung für die richtige Bedienung und Handhabung; dies umfasst
insbesondere die Montage, den Ladevorgang, die Verwendung bis hin zur Wahl des Einsatzberei-
ches. Bitte beachten Sie hierzu die Bedienungs- und Gebrauchsanleitung, diese enthält wichtige
Informationen und Warnhinweise.
Dieses ferngesteuerte Modell ist kein Spielzeug!
Geeignet für Personen ab 14 Jahren.
Achtung:
Von Kleinkindern unbedingt fernhalten.
Enthält verschluckbare Kleinteile. ERSTICKUNGSGEFAHR.
Für Kinder unter 36 Monaten nicht geeignet.
Bei diesem Produkt handelt es sich um einen Modellbau Artikel. D. h., das Fahrzeug muss
stets gewartet werden (auf Beschädigungen kontrollieren, Schraubverbindungen kontrollie-
ren, reinigen usw.) Verschleißteile wie z. B. das Hauptzahnrad, Motorritzel, Knochenpfanne
usw. werden im Lauf der Zeit abgenutzt sein und müssen daher getauscht werden. Auch
Crashs werden sich nicht immer vermeiden lassen, daher müssen auch Crashschäden re-
pariert oder ersetzt werden. Verschleißteile oder defekte Teile durch Crashs oder zu wenig
Wartung unterliegen nicht der Gewährleistung, Kosten und Reparatur müssen vom Käufer
selbst übernommen werden.
DE - Konformitätserklärung
Hiermit erklärt JAMARA e.K., dass die Produkte‚ "Crossmo EP 2,4 GHz, No. 053130, No.
053131" den Richtlinien 2014/35/EU, 2014/53/EU, 2011/65/EU entspricht.
Der vollständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse
verfügbar: www.jamara-shop.com/Konformitaet
DE - Achtung!
Vor dem Betrieb: Erst den Sender und dann das Modell einschalten.
Bei Beendigung: Erst das Modell und dann den Sender ausschalten.
● Betreiben Sie Ihr Modell niemals in Distanzen die außerhalb Ihrer Sichtweite liegen. Sowohl die
maximale Sichtweite als auch die max. Reichweite Ihres Modells hängen von vielen Faktoren
wie Witterung, Einsatzort und vorhandenen Störfrequenzen ab. Führen Sie deshalb vor jedem
Einsatz mit einer zweiten Person, die das Modell während des Tests sicher fixiert hält, einen
Reichweitentest durch und prüfen Sie auch wie sich das Modell während des Betriebs bei
einem Signalausfall wie z.B. bei leeren Senderbatterien oder ausgeschaltetem bzw.
ausgefallenem Sender verhält.
Bitte lesen Sie die komplette Bedienungsanleitung und Sicherheitshinweise sorgfältig
durch bevor Sie das Modell in Betrieb nehmen.
Achtung! Warnhinweise / Sicherheitshinweise unbedingt komplett lesen. Diese
dienen Ihrer Sicherheit und können Unfälle / Verletzungen vermeiden.
Empfohlenes Werkzeug
No. 190065
No. 232060
Radsturzwinkel Meßgerät
Doppelseitiges Klebeband
Camber adjusting Tool
Doublesided power tape
No.153059
X-Peak 80 V2
Ladegerät
Charger
Frequency bands: 2.4GHz
Monstertruck
Crossmo EP 2,4 GHz
No. 232423
medium
Schraubensicherungslack
Nut lock
Frequency range: 2405,5 MHz - 2475,0 MHz
GB - General information
Jamara e.K. is not liable for any damage caused to the product itself or through this, provided this
is due to improper operation or handling errors. The Customer alone bears the full responsibility for
the proper use and handling, including without limitation, the assembly, the charging process, the
use and choice of the operation area. Please refer to the operating and user instructions, it contains
important information and warnings.
This model is not a toy!
Not suitable for people under 14 year.
Warning:
Keep away necessarily from children.
Contains small parts which can be swallowed. RISK OF SUFFOCATION!
Not suitable for children under 36 months.
This product is a model building article. This means that the vehicle must always be serviced
(check for damage, check screw connections, clean etc...). Wear parts such as the main
gear, motor pinion, bone socket, etc. will wear out over time and must therefore be replaced.
Crashes cannot always be avoided, so crash damage must also be repaired or replaced.
Wear parts or defective parts due to crashes or insufficient maintenance are not covered by
warranty, costs and repairs must be covered by the buyer himself.
GB - Certificate of Conformity
Hereby JAMARA e.K. declares that the products "Crossmo EP 2,4 GHz, No. 053130, No.
053131" complies with Directives 2014/35/EU, 2014/53/EU and 2011/65/EU.
The full text of the EU Declaration of Conformity is available at the following Internet
address:
www.jamara-shop.com/Conformity
GB - Attention!
Before operating: Switch the transmitter on first then the model.
When finished: First switch off the model then the transmitter.
● Never operate your model beyond sight. Both the maximum visibility as well as the max. range
of your model will depend on many factors such as weather, location and interfering
frequencies. Therefore, before each use perform a range test with a second person securely
holding the model and also check how the model reacts if there is a signal failure e.g. when
empty transmitter batteries are installed.
Read the complete instructions and security instructions carefully before using the model.
Caution! Please fully and carefully read warnings/ safety instructions. These are for
our own security and can avoid accidents/injuries.
Recommended Tool
No. 281730
No. 505401
Lexanschere
Karosseriesplint
Lexan scissors
Body clips
EIRP:
<
50 mW (max. power transmitted)
=
klein/small
No. 059273
1:10
Karosseriesplint
Body clips
18/21
