- Page 1 592400 | 592600 | 592700 3-Cube Organizer INSTALLATION INSTRUCTIONS 01-61072-00 07/20 © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
-
Page 2: Before Beginning
SAFETY PRECAUTIONS BEFORE BEGINNING • Please read all instructions carefully. • Familiarize yourself with all parts (see “PARTS”) and check quantities. • Follow all safety precautions (see “SAFETY PRECAUTIONS”). WARNING • • CHOKING HAZARD FOR SMALL CHILDREN. This unit DO NOT MOUNT OR ATTACH ANYTHING TO THE SIDES, REAR, OR FRONT OF THE UNIT. -
Page 3: Tools Required
PARTS Call 1-800-874-0008 for parts and service. For faster service, have the style number ready when calling. TOOLS REQUIRED HARDWARE PROVIDED Name Size (Qty) Part Number Allen Wrench 4 mm. (1) 65649 Hex Screw M6 x 15 mm. (8) 65629 Long Screw M7 x 48 mm. - Page 4 Call 1-800-874-0008 for parts and service. For faster service, have the style number ready when calling. PRODUCT Name Part Number Left Metal Side Panel 62392 Right Metal Side Panel 62304 61150 61151 61152 Top/Bottom Wood Panel (592400) (592600) (592700) 61177 61178 61179 Wood Shelf (592400) (592600) (592700) X Brace 62303...
- Page 5 STEP 1 Connect metal side panels to bottom wood panel. Align both metal side panels (A & B) with the bottom wood panel (C) as shown. The top/bottom wood panels (C) will only have holes on one side. Make sure the horizontal bars on each metal side panel are below the screw holes and facing toward the inside of the assembly (fig.
- Page 6 STEP 2 Attach first wood shelf. Place the wood shelf (D) on the lower horizontal bars of the metal side panels (A & B). Use the supplied allen wrench (AA) to secure both metal side panels (A & B) to the wood shelf (D) using two long screws (CC) per side.
- Page 7 STEP 3 Attach second wood shelf. Place the wood shelf (D) on the upper horizontal bars of the metal side panels (A & B). Use the supplied allen wrench (AA) to secure both metal side panels (A & B) to the wood shelf (D) using two long screws (CC) per side.
- Page 8 STEP 4 Connect metal side panels to top wood panel. Align both metal side panels (A & B) with the top wood panel (C) as shown. Use the supplied allen wrench (AA) to secure both metal side panels (A & B) to the top wood panel (C) using two hex screws (BB) per side.
- Page 9 STEP 5 Secure X brace to back of unit. Align the X brace (E) with the predrilled holes on the left metal side panel (A). Secure the X brace to the left metal side panel (A) by using the stamped wrench (FF) to attach two X brace cap nuts (EE) to two X brace screws (DD).
- Page 10 STEP 6 Secure to wall using stud mounting. Align top of unit with wall stud. Position L-bracket (GG) on wall stud and bottom of the top wood panel (C). The longer side of the bracket will connect to the top wood panel and the shorter side will connect to the stud. Secure the bracket (GG) to the top wood panel (C) using one L-bracket screw (HH).
