Denon AVR-987 Specifications

A/V Surround Receiver
AVR-987
The AVR-987 is Denon's latest addition of versatile A/V Receivers,
which incorporate all current surround formats and enhanced installation
flexibility, all with great simplicity of setup and operation.
Audio section
■ Full discrete 7-channel high power amplifier
Front 110 W + 110 W
Center 110 W
Surround 110 W + 110 W
Surround back 110 W + 110 W
■ Latest 32-bit floating point DSP for the decoder
• 24-bit/192-kHz D/A converter
• 96kHz A/D converter
■ 'AL24 Processing Plus,' for high sound quality
■ Digital interface receiver supporting 24-bit/192-kHz signals
■ Large-output power amp section and power supply configuration,
for stable high-power output
■ Stable power supply for high-quality sound and picture playback
■ Pure Direct mode, for the pure enjoyment of music in high-quality sound
■ Supports the most advanced surround playback formats
• Dolby Digital EX • Dolby Digital • Dolby Pro Logic
• DTS-ES • DTS 96/24 • DTS Neo:6 • DTS
■ Configurable surround back amplifiers
a 5.1-channel theater in the main room and a stereo
• Multi-zone system:
environment in a second room.
• "Bi-amp" system: Front (L/R) channels are bi-wired in a 5.1-channel theater to
improve playback quality in the front for enhanced listening enjoyment.
Video section
■ HDMI digital video interface supporting high-quality video of 1080p (*1)
The AVR-987 has HDMI digital video interface terminals (2 inputs and 1 output) that
can be switched for high-resolution 1080p video signal transmission. These HDMI
terminals also support digital input of multi-channel audio signals.
*1) Version 1.1 compliant. Since HDCP is also supported, video cannot be viewed on a non-HDCP display
connected to the AVR-987; please connect a HDCP-compliant display when viewing video material.
(8 ohms, 20Hz - 20kHz, 0.05 % THD)
(8 ohms, 20Hz - 20kHz, 0.05 % THD)
(8 ohms, 20Hz - 20kHz, 0.05 % THD)
(8 ohms, 20Hz - 20kHz, 0.05 % THD)
IIx
■ Video Up/Down Conversion capable of output to HDMI
The AVR-987 includes a video up/down conversion function that allows the unit to be
connected to the video monitor via a single cable regardless of the video input signal's
format as follows:
1) Composite video signals are converted to HDMI (*2), component video, & S-video;
2) S-video signals are converted to HDMI (*2), component video, & composite video;
3) Component video signals are converted to HDMI (*2), composite video (*3), & S-video (*3).
*2. I/P conversion from 480i/576i to 480p/576p
*3. Down-conversion from component video to composite or S-video applies only to 480i input signals.
■ High-speed, high-accuracy 12-bit/216-MHz Video DAC
■
3 sets of component video inputs
■
Dual component outputs
■
High definition quality video switching
■ Composite and S-video signal processing
The AVR-987 uses a time base corrector (TBC) in converting composite video & S-video
signals to component video to suppress jitter in the video signal during playback.
Connectivity/ Expandability
■ ASD-1R Control Dock for iPod ® (option): Supports iPod playback
when connected to the AVR-987
iPod (*4) playback can be enjoyed through the AVR-987 when the ASD-1R, Denon's
original Control Dock for iPod (sold separately), is connect-
ed to the dedicated control terminal of the AVR-987. The
iPod can also be controlled via the remote controller sup-
plied with the AVR-987.
*4) Supports 3rd-generation and later iPods equipped with a Dock connec-
tor. Some functions may not work depending on the generation of the iPod
and the version of the software..
■ New Auto Set-up and Room EQ, featuring MultEQ from Audyssey,
for overall listening area support using supplied microphone
■ XM Satellite Radio Ready
Optional XM plug n' play antenna and subscribes are required.
■ 8ch Analog EXT IN terminal
Black version is also available.
