Replacing the Compact Flash Card
on the ProxySG 300
Blue Coat Systems, Inc. 420 North Mary Ave Sunnyvale, CA 94085
408.220.2200
408.220.2250
www.bluecoat.com
T:
F:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProxySG 300 and is the answer not in the manual?

Questions and answers

Related Manuals for Blue Coat ProxySG 300

Summary of Contents for Blue Coat ProxySG 300

  • Page 1 Replacing the Compact Flash Card on the ProxySG 300 Blue Coat Systems, Inc. 420 North Mary Ave Sunnyvale, CA 94085 408.220.2200 408.220.2250 www.bluecoat.com...

  • Page 2: What You Need

    Replacing Compact Flash Card on ProxySG 300 Overview Follow this step-by-step procedure when it is required to replace the compact flash card on the ProxySG 300. What You Need • 3/32” Hexalobular Socket/ Torx Screw Driver or 3/32” Flathead Screw Driver •...

  • Page 3: Safety Warnings And Cautions

    Replacing Compact Flash Card on ProxySG 300 Safety Warnings and Cautions Caution: This product is designed to work with power systems having a grounded neutral. To reduce the risk of electric shock, do not plug this product into any other type of power system. Contact a qualified electrician if you are not sure what type of power is supplied to your building.

  • Page 4: Electrostatic Discharge (Esd) Warning

    Replacing Compact Flash Card on ProxySG 300 • Do not access the inside of the power supply. There are no serviceable parts in the power supply. Return to manufacturer for servicing. • Power down the server and disconnect all power cords before adding or replacing any non hot- plug component.
  • Page 5 1. To remove the top cover, use the 3/32” hexalobular screwdriver (or 3/32” flathead screwdriver) to loosen the two hexalobular screws from the ProxySG 300. Slide the top cover backward. (Assume: You are facing the front panel of the SG300 when sliding.)
  • Page 6 Replacing Compact Flash Card on ProxySG 300 2. With the top cover open, locate the compact flash card.
  • Page 7 Replacing Compact Flash Card on ProxySG 300 3. Pull and remove the existing compact flash card out of the system.
  • Page 8 Replacing Compact Flash Card on ProxySG 300 4. Insert the new compact flash card sent by Blue Coat into the compact flash card slot.
  • Page 9 Replacing Compact Flash Card on ProxySG 300 5. Replace the top cover, aligning the edges of the cover with the chassis, and slide forward. When fully seated, tighten the two hexalobular screws. (Assume: You are facing the front panel of the SG300 when sliding.)
