BIN WAREHOUSE 65004/JAN21 Assembly Instructions

8 filebox storage rack

Download this manual

TOOLS REQUIRED

1. Drill with #2

Phillips-Head bit

PARTS LIST

1. 8 x Horizontal crossbars

2. 2 x Center verticals

3. 4 x Corner verticals

4. 6 x Vertical top caps

5. 4 x Front and rear grid

connecting tubes

6. 4 x Wall mount brackets

7. 8 x Horizontal slide rails

FASTENER LIST

1. 48 x #06 x ½ in. fastening screws

2. 08 x #10 x 1-¼ in. fastening screws

3. 08 x Plastic wall anchors

NOTE

Separate all parts into groups

(as shown) and familiarize. Read

all instructions before beginning

assembly.

Solutions Murales PROSLAT inc.

225 Industriel blvd, Chateauguay (QC) J6J 4Z2

1 888 691-2944

Model # 65004 / JAN21

8 FILEBOX STORAGE RACK

Assembly instructions

48 x

8 x

Need help?

Do you have a question about the 65004/JAN21 and is the answer not in the manual?

Page 1 Solutions Murales PROSLAT inc. 225 Industriel blvd, Chateauguay (QC) J6J 4Z2 1 888 691-2944 Model # 65004 / JAN21 8 FILEBOX STORAGE RACK Assembly instructions TOOLS REQUIRED 1. Drill with #2 Phillips-Head bit PARTS LIST 1. 8 x Horizontal crossbars 2.
Page 2 FRONT GRID ASSEMBLY Alignment dimples Alignment dimples down Holes down Holes down Other side Short side to floor Short side to floor Other side Parts needed: STEP 1 STEP 2 4 of #1 2 of #3 4 Horizontal crossbars (#1) inserted through 1 Center Vertical Two corner vertical (#3) inserted through 1 of #2 (#2) Note: Slide horizontal crossbar into left side of center...
Page 3 (#1) and fasten to wall using 8 – #10 x 1¼ wall anchors – and proceed with step 1 Congratulations! We hope you fastening screws. (#2). – Insert decorative top caps (#4) into all enjoy your Bin Warehouse file verticals. box storage rack!
Page 4 Solutions Murales PROSLAT inc. (hereafter Proslat) warrants its Bin Warehouse Rack against defects in material or workmanship for a lifetime period. Proslat will replace any defective Rack as long as it was installed and maintained according to the printed instructions. Any Proslat Bin Warehouse Rack replaced under the terms of the Lifetime Warranty inherits the remaining warranty period from the original purchase.
