TOOLS REQUIRED
1. Drill with #2
Phillips-Head Tip
2. #2 Philips head
Screwdriver
PARTS LIST
1. 8 x Horizontal crossbars
2. 2 x Center verticals
3. 2 x Left & right rear corner verticals
4. 1 x Left front corner vertical
5. 1 x Right front corner vertical
6. 4 x Wall mount flanges
7. 4 x Wall mount extensions tubes
8. 8 x Horizontal slide rails
FASTENER LIST
1. 44 x #08 x 3/4 in. Fastening screws
2. 8 x #08 x 1-½ in. Wall mount
Extension tube fastening screws
3. 12 x #10 x 1-½ in. Wall mount
flange screws
4. 12 x Plastic wall anchors
NOTE
Separate all parts into groups
(as shown) and familiarize. Read
all instructions before beginning
assembly.
Solutions Murales PROSLAT inc.
225 Industriel blvd, Chateauguay (QC) J6J 4Z2
1 888 691-2944
Model # 65001 / JAN21
8 TOTE STORAGE RACK
Assembly instructions
#1
#7
#6
#2
#3
#4
#5
#1
#3
#8
#2
#4
