Axxess AX-DSPX-HD1-WR Installation Instructions Manual

INTERFACE COMPONENTS

• AX-DSP-X circuit board

• AX-DSPX-HD1-WR harness (with gaskets)

• AX-DSPX-HD1-WR enclosure

• Case

• Cap (with O-ring)

AxxessInterfaces.com

Harley Davidson DSP

Package with Water

1998-2013

Resistant Enclosure

INTERFACE FEATURES

• Water resistant plug-n-play harness for the AX-DSP-X

• AX-DSP-X included

• Water resistant enclosure with zip tie mounts included

• Amplifier, if equipped, does not need to be retained

• All wiring will be done at the radio location

• Micro-B USB updatable

AX-DSPX-HD1-WR

I N S T A L L A T I O N I N S T R U C T I O N S

TABLE OF CONTENTS

Connections ............................................................2

Installation ......................................................... 3-4

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

Product Info

REV. 8/16/19 INSTAX-DSPX-HD1-WR

Table of Contents

Need help?

Do you have a question about the AX-DSPX-HD1-WR and is the answer not in the manual?

Page 1 • Amplifier, if equipped, does not need to be retained • All wiring will be done at the radio location • Micro-B USB updatable INTERFACE COMPONENTS • AX-DSP-X circuit board • AX-DSPX-HD1-WR harness (with gaskets) Product Info • AX-DSPX-HD1-WR enclosure • Case • Cap (with O-ring) AxxessInterfaces.com...
Page 2 Factory Radio White / Front Left + Green / Rear Left + White/Black / Front Left - Green/Black / Rear Left - AX-DSPX-HD1-WR Gray / Front Right + Purple / Rear Right + Circuit Board Gray/Black Front Right - Purple/Black / Rear Right -...
Page 3 6. Slide the assembly into the case, then click it shut. Zip-tie the enclosure to a secure 16-Pin 20-Pin location in the fairing to secure it. Make sure the Axxess logo is facing up to further Gasket ensure that no outside elements can enter the enclosure.
Page 4 10. Connect the amp turn-on wire from the AX-DSPX-HD1-WR harness. 11. Click the Identify button to confirm that the AX-DSPX-HD1-WR is connected properly. If so, a chime will be heard from the front left speaker. Test all functions of the installation for proper operation.
Page 5 REV. 8/16/2019 INSTAX-DSPX-HD1-WR...
Page 7 REV. 8/16/2019 INSTAX-DSPX-HD1-WR...
Page 8 AX-DSPX-HD1-WR I N S T A L L A T I O N I N S T R U C T I O N S Having difficulties? We’re here to help. Contact our Tech Support line at: 386-257-1187 Or via email at: techsupport@metra-autosound.com...
