NHD-4.3-480272FT-CSXN-CTP
4.3" EVE2 TFT Module (SPI) – Supports: Display | Touch | Audio
NHD-
Newhaven Display
4.3-
4.3" Diagonal
480272-
480xRGBx272 Pixels
FT-
Model
C-
On-board Controller
S-
Sunlight Readable
X-
TFT
N-
TN, Wide Temperature
CTP-
Capacitive Touch Panel
Newhaven Display International, Inc.
Ph: 847-844-8795
www.newhavendisplay.com
nhtech@newhavendisplay.com
2661 Galvin Ct.
Elgin IL, 60124
Fax: 847-844-8796
nhsales@newhavendisplay.com
Advertisement
Table of Contents
Related Manuals for Newhaven Display International NHD-4.3-480272FT-CSXN-CTP
Summary of Contents for Newhaven Display International NHD-4.3-480272FT-CSXN-CTP
- Page 1 4.3” EVE2 TFT Module (SPI) – Supports: Display | Touch | Audio NHD- Newhaven Display 4.3- 4.3” Diagonal 480272- 480xRGBx272 Pixels Model On-board Controller Sunlight Readable TN, Wide Temperature CTP- Capacitive Touch Panel Newhaven Display International, Inc. 2661 Galvin Ct. Elgin IL, 60124 Ph: 847-844-8795 Fax: 847-844-8796 www.newhavendisplay.com nhtech@newhavendisplay.com nhsales@newhavendisplay.com...
-
Page 2: Document Revision History
Document Revision History Revision Date Description Changed by 9/27/17 Initial Release PB, ML Functions and Features 4.3" Sunlight Readable EVE2 TFT Module w/ Capacitive Touch On-board FTDI/Bridgetek FT813 Embedded Video Engine (EVE2) Supports Display, Touch, Audio SPI Interface (D-SPI/Q-SPI modes available) ... - Page 3 DO NOT SCALE DRAWING SHEET 1 OF 1 THIS DRAWING IS SOLELY THE PROPERTY OF NEWHAVEN DISPLAY INTERNATIONAL, INC. Take special care when handling this area of the display module to make sure these connections are never strained nor creased.
- Page 4 SCHEMATIC/PART NUMBER: REVISION: NHD-4.3C-FT813 Controller Board SIZE: DRAWN BY: CHECKED BY: P. Bartek M. LaVine SHEET: DRAWN DATE: CHECKED DATE: 1 of 1 07/10/17 07/13/17 Released under the Creative Commons Attribution Share-Alike 4.0 License http://creativecommons.org/licenses/by-sa/4.0...
-
Page 5: Pin Description
Pin Description Pin No. Symbol External Connection Function Description Power Supply Input Voltage for TFT and FT81x (3.3V) Power Supply Ground SPI Clock (Input) MISO/IO1 SPI MISO (Output) / Quad-SPI mode: SPI data line 1 MOSI/IO0 SPI MOSI (Input) / Quad-SPI mode: SPI data line 0 SPI Chip Select (Input), Active LOW /INT Interrupt to host (Output), Active LOW... -
Page 6: Electrical Characteristics
Electrical Characteristics Item Symbol Condition Min. Typ. Max. Unit Operating Temperature Range Absolute Max ⁰C Storage Temperature Range Absolute Max ⁰C Supply Voltage Supply Current = 3.3V “H” Level Input “L” Level Input “H” Level Output -0.4 “L” Level Output Supply Voltage for LED Backlight Driver = 3.3V Supply Current for LED Backlight Driver... -
Page 7: Serial Host Interface
FT81x Block Diagram FT81x with EVE (Embedded Video Engine) technology simplifies the system architecture for advanced Human Machine Interfaces (HMIs) by providing support for display, touch, and audio as well as an object oriented architecture approach that extends from display creation to the rendering of the graphics. Serial Host Interface By default the SPI slave operates in the SINGLE channel mode with MOSI as input from the master and MISO as output to the master. -
Page 8: Graphics Engine
TFT Timing Characteristics Shown below are the FT81x registers that control the TFT’s timing (clock and sync signals), along with the values recommended to use for this EVE2 TFT Module: Horizontal Timing Vertical Timing Clock Settings Register Value Register Value Register Value REG_HSIZE... -
Page 9: Audio Engine
Touch-Screen Engine The Capacitive Touch Screen Engine (CTSE) of the FT813 communicates with the external Capacitive Touch Panel Module (CTPM) through an I2C interface. The CTPM will assert its interrupt line when there is a touch detected. Upon detecting CTP_INT_N line active, the FT813 will read the touch data through I2C. Up to 5 touches can be reported and stored in FT813 registers. - Page 10 Audio Filter and Amplifier Reference Circuit This is a reference schematic from FTDI, which can be used to successfully filter and amplify the audio signals coming from the NHD EVE2 TFT Module. [10]...
-
Page 11: Additional Information Resources
Additional Information/Resources FT81x Datasheet: FTDI/Bridgetek FT81x Embedded Video Engine (EVE2) http://www.ftdichip.com/Support/Documents/DataSheets/ICs/DS_FT81x.pdf Programmers Guide: FT81x Series Programmers Guide http://www.ftdichip.com/Support/Documents/ProgramGuides/FT81X_Series_Programmer_Guide.pdf NHD GitHub Page: NHD EVE2 TFT Module Example Projects https://github.com/NewhavenDisplay/EVE2-TFT-Modules EVE2 Software Examples: FT81x Example Projects http://www.ftdichip.com/Support/SoftwareExamples/FT800_Projects.htm FTDI/Bridgetek Utilities: Screen Designer http://www.ftdichip.com/Support/Utilities.htm#ESD3 Image Converters http://www.ftdichip.com/Support/Utilities.htm#EVEImageConverters Audio Converter... -
Page 12: Quality Information
Quality Information Test Item Content of Test Test Condition Note High Temperature storage Endurance test applying the high storage +80⁰C , 96hrs temperature for a long time. Low Temperature storage Endurance test applying the low storage -30⁰C , 96hrs temperature for a long time. High Temperature Endurance test applying the electric stress +70⁰C , 96hrs...
