Pin Assignment - Addi-Data MSX-E3511 Quick Installation

Ethernet
Pin No.
1
2
3
4
Trigger/Synchro
Pin No.
1
2
3
4
5
3

Pin assignment

Port 0
Female connector,
D-coded, M12
TD0+
RD0+
TD0-
RD0-
Trig/Sync In
Male connector,
5-pin, M12
Trigger input -
Trigger input +
Synchro input +
Synchro input -
GND
Port 1
Female connector,
D-coded, M12
TD1+
RD1+
TD1-
RD1-
Trig/Sync Out
Female connector,
5-pin, M12
Trigger input -
Trigger input +
Synchro output +
Synchro output -
GND
Cable (green)
Lead colour
yellow
white
orange
blue
Cable (purple)
Lead Lead
colour pair
blue
1
white
red
2
black
