- Page 1 TECHNICAL DESCRIPTION MSX-Box-500 General handling Edition: 02.05-03/2011 DIN EN ISO 9001:2008 certified...
- Page 2 The content of this manual and the technical product data may be changed without prior notice. ADDI-DATA GmbH reserves the right to make changes to the technical data and the materials included herein.
-
Page 3: Warning
If the instructions are ignored, the MSX-Box, the PC and/or peripherals may be destroyed. WARNING! Designates a possibly dangerous situation. If the instructions are ignored, the MSX-Box, the PC and/or peripherals may be destroyed and persons may be endangered. www.addi-data.com... -
Page 4: Table Of Contents
Contents MSX-Box-500 Contents Warning............................. 3 General presentation of the MSX-Box ................5 Side view (left)..........................5 Front side ............................6 Mounting the MSX-Box ....................7 DIN rail mounting .......................... 7 2.1.1 Fasten the rail clamp to the MSX-Box ..................7 2.1.2 Mounting the MSX-Box to the DIN rail .................. -
Page 5: General Presentation Of The Msx-Box
General presentation of the MSX-Box MSX-Box-500 1 General presentation of the MSX-Box Side view (left) Fig. 1-1: Side view (left) Switch “I” = ON (switched on) Switch “0” = OFF (switched off) * Power cable is contained in the standard delivery. -
Page 6: Front Side
General presentation of the MSX-Box MSX-Box-500 Front side Fig. 1-2: Front side When the display „”Power“ lights, the MSX-Box is switched on. Fig. 1-3: Side view (right) IMPORTANT! The standard delivery of the MSX-Box does not include a PC board. -
Page 7: Mounting The Msx-Box
Mounting the MSX-Box MSX-Box-500 2 Mounting the MSX-Box DIN rail mounting WARNING! Should you have already mounted the MSX-Box and want to transport it in a switch cabinet or in other systems, do ensure that there is sufficient transportation lock. The MSX-Box could fall e.g. -
Page 8: Mounting The Msx-Box To The Din Rail
Mounting the MSX-Box MSX-Box-500 2.1.2 Mounting the MSX-Box to the DIN rail Introduce the clamp by placing the spring under the rail Fig. 2-3: Guiding the clamp to the rail Lift the MSX-Box until the upper part of the clamp locks on the rail. -
Page 9: Wall Mounting
Mounting the MSX-Box MSX-Box-500 Wall mounting 2.2.1 Fasten the wall boards to the MSX-Box Fasten the clamps in the holes with the 2 delivered screws. Fig. 2-5: Mounting the wall boards Right side Left side (switch) 2.2.2 Location of the wall board Fig. -
Page 10: Board Installation
Board installation MSX-Box-500 3 Board installation Switch off the MSX-Box and all the units connected to the MSX-Box. Pull the Box mains plug from the socket. Unscrew the 6 screws from the housing lid. Fig. 3-1: Unscrew the housing lid... -
Page 11: Fig. 3-3: Correct Handling Of The Board
Board installation MSX-Box-500 Discharge yourself from electrostatic charges. Remove the back cover of the selected slot. Take the board out of its package. Fig. 3-3: Correct handling of the board Insert the board vertically into the chosen slot. Fig. 3-4: Inserting the board... -
Page 12: Fig. 3-5: Fasten The Board
Board installation MSX-Box-500 Fasten the board to the rear of the housing with the screw which was fixed on the back cover. Fig. 3-5: Fasten the board Screw the board holding clamp and the earthing line. Push the screw to the rear or the front of the clamp to fix the board. -
Page 13: Connecting The Msx-Box To The Peripheral
Connecting the MSX-Box to the peripheral MSX-Box-500 4 Connecting the MSX-Box to the peripheral Connecting the network cable Fig. 4-1: Connecting the network cable The "Communication" LED blinks when the cable is connected to an active network. Fig. 4-2: "Communication" LED... -
Page 14: Contact And Support
Contact and support MSX-Box-500 5 Contact and support Do you have any questions? Write or phone us: Address: ADDI-DATA GmbH Airpark Business Center Airport Boulevard B210 77836 Rheinmünster Germany Phone: +49 7229 1847-0 Fax: +49 7229 1847-222 E-mail: info@addi-data.com Manual and software download from the Internet: www.addi-data.com...
