Specifications - SPL Control One Manual

Analog inputs & outputs; 6.35 mm (1/4") TRS Jack (balanced), RCA
Input gain (max.)
Line Input 1 (balanced): Input impedance
Line Input 1: Common mode rejection
Line Input 2 (unbalanced): Input impedance
Output gain (max.): Speaker Outputs (600 Ω)
Line Output (unbalanced): Output impedance
Speaker Output 1 (balanced): Output impedance
Sub Output low filter
Sub Output (balanced): Output impedance
Speaker Output 2 (unbalanced): Output impedance
Frequency range (-3dB)
Dynamic range
Noise (A-weighted, 600 Ω load)
Total harmonic distortion (0 dBu, 10 Hz – 22 kHz)
Crosstalk (1 kHz)
Fade-out attenuation
4

Specifications

Headphones Output; 6.35 mm (1/4") TRS Jack
+22.5 dBu
Wiring
20 kΩ
Source impedance
< 60 dB
Frequency range (-3 dB)
10 kΩ
Noise (A-weighted, 600 Ω)
+22 dBu
THD + N (0 dBu, 10 Hz – 22 kHz, 600 Ω)
75 Ω
THD + N (0 dBu, 10 Hz – 22 kHz, 32 Ω)
150 Ω
Max output power (600 Ω)
none (full range)
Max output power (250 Ω)
150 Ω
Max output power (47 Ω)
75 Ω
Fade-out attenuation (600 Ω)
10 Hz - 200 kHz
Crosstalk (1 kHz, 600 Ω)
121 dB
Dynamic range
-99 dBu
0.002 %
< 75 dB
-93 dB
Tip = Left, Ring = Right,
Sleeve = GND
20 Ω
10 Hz - 200 kHz
-97 dBu
0,002 %
0,013 %
2 x 190 mW
2 x 330 mW
2 x 400 mW
-99 dB
-75 dB
117 dB
Control One
