NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com
TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and insert into the assembled stand. Make sure the
pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch hinges.
7. Insert green label extension cord into adapter and adapter insert into the wall outlet. (See Fig. B), your entire tree should now be lit.
If some bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Connecting the plugs or
replace the bad bulbs promptly in order to maintain the performance and life expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one to
the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform look. Shift branches to fill any
gaps. Your Christmas tree is now complete and ready to be decorated.
MODEL #:TG76M4E28D01
1-888-919-0070
OR
Polygroup®!
Tree top
Section 2
Section 1
Side view
SKU: 741-668
Carefully follow the instructions below on how to quickly
*Electrical Rating Of Power Adapter
(For Indoor Use Only)
Input: 100V-240V, 50/60Hz, 0.35A
Output: 29V DC 0.45A
Insert Red Label
Plugs Into Red
Labeled Extension Cord
Control box
Insert Green
Label Extension
Cord into Adapter
1
Unfold the legs and lay the
stand in a flat area. Then slide
the locking disc downward and
snap into place.
Adapter
To Be Plugged
Into Wall
Outlet
