OptiPlex 580 Technical Specifications
AMD Phenom™ II X4 Quad Core B9x Processors (8M, AMD-V™, PowerNow!™, EVP)
AMD Phenom™ II X3 Triple Core B7x Processors (7.5M, AMD-V™, PowerNow!™, EVP)
AMD Phenom™ II X2 Dual Core B5x Processors (7M, AMD-V™, PowerNow!™, EVP)
AMD Phenom™ II X2 Dual Core B2x Processors (2M, AMD-V™, PowerNow!™, EVP)
Processor Options*
AMD Athlon™ II X4 Quad Core 6xx Processors (2M, AMD-V™, Cool'n Quiet, EVP)
AMD Athlon™ II X3 Triple Core 4xx Processors (1.5M, AMD-V™, Cool'n Quiet, EVP)
AMD Athlon™ II X2 Dual Core 2xx Processors (2M, AMD-V™, Cool'n Quiet, EVP)
AMD Sempron™ Single Core 1xx Processor (1M, AMD-V™, Cool'n Quiet, EVP)
AMD 785G
Chipset
Microsoft® Windows® 7 Home Basic 32-bit (select countries); Microsoft® Windows® 7 Home Premium 32-bit ; Microsoft® Windows® 7 Professional 32-bit and
64-bit; Microsoft® Windows® 7 Ultimate 32-bit
Microsoft® Windows Vista® Home Basic 32-bit; Microsoft® Windows Vista® Business 32-bit and 64-bit; Microsoft® Windows Vista® Ultimate 32-bit;
Operating System Microsoft® Windows® XP Professional 32-bit Downgrade via Windows® 7 Professional or Ultimate 32-bit
Microsoft® Windows XP® Professional 32-bit Downgrade via Windows Vista® Business or Ultimate 32-bit
Options
Microsoft® Windows Vista® 32-bit Business Downgrade via Windows® 7 Professional 32-bit Microsoft® Windows Vista® Ultimate 32-bit Downgrade via Windows®
7 Ultimate
Ubuntu® Linux® (select countries); FreeDOS for N-series
Integrated ATI Radeon HD 4200 Graphics; 256MB ATI® RADEON® HD 3450 (dual DVI or dual VGA options)*; 256MB ATI RADEON HD 3470 (dual DP or DP/DVI options)*;
Graphic Options
512MB NVIDIA NVS420 (SFF only, quad DP or quad DVI options)*; 256MB NVIDIA GeForce 9300 (dual DVI or dual VGA options)*; 512MB ATI RADEON HD 4550 (DP/ DVI)*
Memory Options MT/DT/SFF- Four DIMM slots; Non-ECC dual-channel 1066MHz DDR3 SDRAM*, up to 16GB*
Networking Integrated Broadcom 5761 Ethernet LAN 10/100/1000; optional Broadcom® 1505 PCIe WLAN card (802.11 N)
Standard I/O Ports MT/DT/SFF- 8 External USB 2.0 ports (2 front/ 6 rear); 1 Serial; 1 RJ-45; 1 VGA; 1 Display Port; 1 eSATA; 2 Line-in (stereo/microphone); 2 Line-out (headphone/speaker)
3.5" Hard Drives: 80GB, 160GB, 250GB, 500GB* 7200 RPM SATA 3.0GB/s, 80GB, 160GB* 10K RPM SATA 3.0GB/s
Hard Drive Options 2.5" Hard Drives: 160GB, 250GB* 7200 RPM SATA 3.0GB/s, 64GB* SATA Solid State Drive
MT/DT/SFF- RAID 0 & 1 support on select configurations
Dimensions
(H x W x D)
Inches/(cm)
Weight (lbs/kg)
Number of Bays
Chassis Options
Expansion Slots
DIMM Slots
Power Supply Unit
(PSU)
Monitors:
Dell G-Series and Entry Standard and Widescreen Flat Panel Analog:
Dell G2210, G2410, E170S, E190S, E1709W, E1909WDD, E1910H, E1910, E2010H, E2009W, E2210H, E2210, E2310H
Dell Professional Digital Standard and Widescreen Flat Panel:
Dell P170S, P190S, 1909W, 2009W, P2010H, P2210H, P2210, P2310H
Dell UltraSharp™ Digital Standard and Widescreen Flat Panel, Adjustable Stand:
Peripheral Options
Dell 1907FPV, 2007FP, 2209WA, U2410
Keyboards: Dell USB Entry Keyboard, Dell QuietKey™ Keyboard, Dell Multimedia Pro Keyboard
Mouse: Dell USB Optical Mouse, Dell Laser Mouse
Audio Speakers: Internal Dell Business audio speaker, Dell AX210 2.0 and AY410 2.1 Desktop Speakers; Dell AX510 and AX510PA Sound Bar Speakers
Trusted Platform Module (TPM) 1.21*, Non-(TPM in select countries only), Dell ControlPoint, Chassis lock slot and lock loop support, optional Chassis Intrusion Switch,
Security Options
Setup/BIOS Password, I/O Interface Security, Smart Card keyboards, BIOS support for optional Computrace®*
Systems Broadcom TruManage™ ready
Management
Options
Environmental Standards (eco-labels): ENERGY STAR® 5.0 (select configurations), EPEAT Gold (select configurations), CECP, TCO 05, WEEE, Japan Energy Law, CES,
Environmental
Japan Green PC, FEMP, South Korea Eco-label, EU RoHS, China RoHS
and Regulatory
Other Environmental Options: Dell Energy Smart settings (select configurations); Carbon Off-set; System Recycle (Asset Recovery Service)
Standards
Warranty and Limited Hardware Warranty*; Standard 3-year Next Business Day On Site Service after Remote Diagnosis* (3-3-3); Optional 3-year Dell ProSupport™ for IT*; 4 year and
5 year extended warranty andservice options

Service Options

1 This form factor utilizes a more efficient Active Power Factor Correction (APFC) power supply. Dell recommends only Universal Power Supplies (UPS) based on Sine Wave output for APFC PSUs,
not an approximation of a Sine Wave, Square Wave, or quasi-Square Wave (see UPS technical specifications). If you have questions, please contact the manufacture to confirm the output type.
*Important Information:
System Memory and Graphics: Significant system memory may be used to support graphics, depending on system
memory size and other factors.
4GB or Greater System Memory Capability: A 64-bit operating system is required to support 4GB or more of system memory.
Hard Drive: GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.
TPM: TPM is not available in all regions.
Next Business Day Onsite Service after Remote Diagnosis: Remote Diagnosis is determination by online/phone technician of cause of issue; may involve customer access to inside of system and
multiple or extended sessions. If issue is covered by Limited Hardware Warranty (www.dell.com/warranty) and not resolved remotely, technician and/or part will be dispatched, usually within 1
business day following completion of Remote Diagnosis. Availability varies. Other conditions apply.
Limited Hardware Warranty: For copy of Ltd Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or see www.dell.com/warranty.
Dell Services: Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescriptions.
Computrace: Not a Dell offer. Certain conditions apply. For full details, see terms and conditions at www.lojackforlaptops.com.
MINITOWER
16.1 x 7.4 x 17.0 /
(40.8 x 18.7 x 43.3)
25.8 / 11.7
2 internal 3.5"
1 external 3.5"
2 external 5.25"
1 full height PCIe x16
1 full height PCIe x16 (routed as x4)
2 full height PCI
4
305W Standard PSU or optional 255W 88%
Efficient PSU; Energy Star 5.0 compliant
DESKTOP SMALL FORM FACTOR
4.5 x 15.7 x 13.9 / 3.65 x 12.4 x 13.4 /
(11.4 x 39.9 x 35.3) (9.26 x 31.4 x 34.0)
18.2 / 8.26 15.0 / 6.8
1 internal 3.5" 1 internal 3.5"
1 external 3.5" 1 external3.5" (slimline)
1 external 5.25" 1 external 5.25" (slimline)
1 low-profile PCIe x16 1 low-profile PCIe x16
1 low-profile PCIe x16 (routed as x4) 1 low-profile PCIe x16 (routed as x4)
1 low-profile PCI
4 4
255W Standard PSU or optional 255W 88% 235W Standard PSU or optional 235W
Efficient PSU; Energy Star 5.0 compliant 88% Efficient PSU; Energy Star 5.0
