Delfield Shelleysteel SCSC-36-EF Specifications

Short Form
Specifications
Exterior Body is constructed of
18-gauge stainless steel side panels
and 14-gauge galvanized bottom. All
exterior side panels are reinforced with
overlapping corners which are welded
in place. All body cutouts are rein-
forced with 14-gauge galvanized chan-
nel supports.
Exterior top is constructed of
14-gauge stainless steel, welded,
ground and polished into one integral
unit.
The LiquiTec cold pan has 2-6 die
stamped 19.87" x 11.87" (50.5cm x
30.2cm) openings with depressed
edges. Formed well below each
opening is 6.25" (15.9cm) deep with
.5" drain mainfold to gate valve.
Each well, flush with the top, for
flush mount pans to accommo-
date 12" x 20" (30.5cm x 50.8cm)
pans 4" (7.6cm) or 6" (15.2cm)
deep, supplied by others. Product
temperatures of 33˚F (1˚C) to 41˚F
(5˚C) are maintained at 86˚F (30˚C)
ambient room temperature, meeting
NSF7 requirements. The cold pan is
separated from the exterior top by a
thermal break. Copper refrigeration
tubing is attached to the sides of
every well. Eutectic fluid is used as
the heat transfer medium. Cold pan
is fully insulated with foamed in place
polyurethane insulation.
Refrigeration system uses HFC-404A
refrigerant and has a self-contained
115 volt, 60 Hertz, single phase her-
metically sealed condensing unit with
adjustable cold pan pressure control.
Unit is wired with a 3-wire, grounded,
maximum 10' (3m) cord and plug.
Unit has an on/off switch mounted on
the exterior.
Casters: Unit is mounted on 5"
(12.7cm) diameter swivel casters with
non-marking polyolefin tires and plate
brakes. Overall height of caster assem-
bly is 6.00" (15.2cm).
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
Mobile Self-Contained LiquiTec™ Cold Pan Serving Counters
Optional Accessories and
Modifications:
A) 12" (30.5cm) wide stainless steel
fold-down tray slide
C) 10" (25.4cm) wide three-bar fold-
down tray slide
D) 10" (25.4cm) wide composite fold-
down cutting board
E) 10" (25.4cm) wide stainless steel
fold-down work shelf
F) Line-up interlock device
G) Glass-front counter protector
H) Two tier display with glass shelves
and sneeze guards
HD) Dual service two tier display with
sneeze guards
I) Three tier diplay with glass shelve\
and sneeze guards
J) 12" (30.5cm) wide 18-gauge stain-
less steel overshelf
KS) Single service flip-up sneeze guard
KD) Double service flip-up sneeze guard
L) *Fluorescent light fixtures
LI) *Incandescent light fixtures
P) Open understorage with shelf
Q) *120V/60Hz/1ø, 10 amp conve-
nience outlet with breaker
ST) Stainless steel trim strips
U) 14" x 30" (35.6cm x 76.2cm) stain-
less steel end drop shelf
V) 6" (15.2cm) high adjustable stain-
less steel legs
*Inclusion of these options will alter the elec-
trical specifications of unit.
PROJECT
ITEM #
QUANTITY
APPROVAL
SCSC-EF
Model SCSC-96-EF
DATE
