Delfield N8046N Specifications

Short Form Specifications
Top is one piece 20-gauge stainless steel. Interior liner is 22-gauge
stainless steel and is creased to 1.00" (2.54 cm) diameter drain. Unit
has a sectional, removable perforated stainless steel false bottom
and is provided with adapter bars to allow placement of 12" x 20"
(30.5 cm x 50.8 cm) pans. Unit is supplied with 1" (2.54 cm) plas-
tic drain to be installed by customer. Exterior housing is 22-gauge
galvanized steel. Unit is insulated with high density closed cell poly-
urethane.
Optional Accessories & Modifications
• Custom sizes and styles
• Single or double service flip-up sneezeguards
A
14"
35.6 cm
13.68"
34.75 cm
21.62"
55 cm
24.75"
63cm
26"
66 cm
C
NOTE: NOT TO SCALE
C L
PLAN VIEW
MODEL N8018
Mechanical Data: Standard Unit
MODEL
NUMBER A
N8018
18"
45.7cm
N8030
30.75"
78.1cm
N8043
43.5"
110.5cm
N8056
56.25"
142.9cm
N8069
69"
175.3cm
N8081
81.75"
208cm
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2003 The Delfield Company. All rights reserved. Printed in U.S.A.
B
21.62"
55 cm
24.75"
63cm
26"
66cm
NOTE: NOT TO SCALE
TYPICAL PLAN VIEW
N8000 MODELS (EXCEPT N8018)
B C
6.84" 4.06"
17.3cm 10.3cm
8.68" 6.06"
22cm 15.3cm
9.82" 11.31"
24.9cm 28.7cm
9.82" 17.69"
24.9cm 44.9cm
9.82" 24.06"
24.9cm 61.1cm
9.82" 30.43"
24.9cm 77.3cm
A
A – 2.75"
A – 7 cm
A – 6"
A – 15.2 cm
B C
NOTE: NOT TO SCALE
C L
TYPICAL ELEVATION VIEW
ALL N8000 MODELS
COUNTER CUTOUT # OF 12" X 20"
DIMENSIONS (D x L) PANS HELD
17" x 25"
43.2cm x 63.5cm
29.75" x 25"
75.6cm x 63.5cm
42.50" x 25"
107.9cm x 63.5cm
55.25" x 25"
140.3cm x 63.5cm
68" x 25"
172.7cm x 63.5cm
80.75" x 25"
205.1cm x 63.5cm
PROJECT
ITEM #
QUANTITY
APPROVAL
Drop-In Ice Cooled Cold Pans
Model N8056
10.75"
27.3cm
C
NOTE: NOT TO SCALE
TYPICAL RIGHT END VIEW
ALL N8000 MODELS
SHIPPING
WEIGHT
1 37 lbs
17 kg
2 100 lbs
45 kg
3 118 lbs
53 kg
4 145 lbs
65 kg
5 164 lbs
74 kg
6 190 lbs
86 kg
DATE
N8000
9.35"
24cm
