Delfield Shelleymatic N-1200 Specifications

Short Form Specifications
Exterior sides shall be 20-gauge stainless steel. Top and corner supports shall be
16-gauge stainless steel, welded, ground and polished into one integral unit.
Inner liner shall be water-tight and constructed of 22-gauge stainless steel with
1.25" (3.2cm) I.P.S. drain. Unit shall be insulated with high-density, foamed in place
polyurethane insulation with a non-conductive to breaker strip.
Each opening shall have a stainless steel sliding lid with recessed handles.
(3) stainless steel louvers shall be installed in the end and sides of the cabinet to
allow proper air flow to the condensing unit.
each self-leveling mechanism shall be field adjustable by adding or removing stainless
steel extension springs in the elevator housing inside the unit. The elevators shall be
connected by removable platform carriers constructed of 18-gauge stainless steel.
(6) anodized aluminum divider trays will be supplied per deep cabinet section. (2)
anodized aluminum divider trays will be supplied per deep cabinet section over the
machine compartment. NOTE: See chart on back for milk storage capacity.
Refrigeration system shall use HFC-134a refrigerant. Refrigerant flow shall be con-
trolled by an expansion valve. Cabinet shall maintain 36°F to 40°F (2°C to 4°C)
temperature with lids closed for storage.
Refrigeration system shall be controlled by a pressure control, located near the
condensing unit.
Electrical connections shall be 115 volt, 60 cycle, single phase. Unit shall have a 9'
(2.7m) long electrical cord and NEMA 5-15P plug.
Unit shall be mounted on 6.00" (15.2cm) high adjustable stainless steel legs.
Optional Accessories and Modifications
• 4.00" (10.2cm) diameter swivel casters (all locking) with corner bumpers
(adds 2.50" (6.4cm) to overall length and depth and reduces overall height
by 1.00" (2.5cm)
• Heavy-duty casters (contact factory)
• Corner bumpers (adds 2.50" [6.4cm] to overall length and depth)
• Wrap-around bumpers (adds 1.75" [4.4cm] to overall length and depth)
• Wire baskets (13.81" x 11.62" x 3.87" [35.1cm x 29.5cm x 9.8cm])
• Laminate panels
• Fiberglass panels
• Lid locking device
• Special voltages (consult factory)
NOTE: This equipment is intended for storage and /or display of pre-
packaged or bottled products only.
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
PROJECT
ITEM #
QUANTITY
APPROVAL
Free-Standing Self-Contained Milk or Beverage Dispensers
DATE
Model N-860
shown with optional casters and
wrap-around bumpers
N
