Definitive Technology UIW RSS II Owner's Manual page 6

Step-by-Step Installation
Hole location options and requirements
• In-Wall installation for studs spaced 16" on-center (or more):
– Place template at least 1
Template does not need to be centered between studs.
– Trace around template with pencil.
– Cut hole.
See Diagram 1, page 10 for reference.
• In-Wall installation for studs spaced 16" on-center (or more) where desired
location is closer than 1
– Place template against inside of existing stud.
– Trace around template with pencil.
– Cut hole.
See Diagram 2, page 10 for reference.
• In -Ceiling installation, in-line with joists spaced 16" on-center (or more) :
– Place template against inside edge of existing joist.
– Trace around template with pencil.
– Cut hole.
– If required, install supporting cross braces inside cavity.
– Install framing material inside cavity, running parallel to existing joists,
leaving 9
7
See Diagram 3, page 11 for reference.
• In-Ceiling installation, centered, in-line with joists spaced 16" on-center
(or more):
– Center template between inside edges of existing joists.
– Trace around template with pencil.
– Cut hole.
– If required install supporting cross braces inside cavity.
– Install framing material inside cavity, running parallel to existing joists,
leaving 9 7
See Diagram 4, page 10 for reference.
6
1 / " away from existing studs (to clear lock arms).
4
1 / " to stud:
4
/ " between frame sides.
8
/ " between frame sides.
8
(continued)
