Mythos
Mythos
Audio/Video Magnetically Shielded Loudspeakers
Congratulations on your purchase of a Definitive Technology
Mythos Audio/Video Loudspeaker System. These superb
loudspeakers utilize state-of-the-art components (homopolymer-
coned bass-midrange drivers, moving coil ferrofluid-cooled pure
aluminum dome high frequency radiators, long excursion pressure
coupled woofers, uniphase crossover networks, etc.), a non-reso-
nant aircraft-grade aluminum monocoque cabinet, low diffraction
construction and complete magnetic shielding in order to achieve
the most lifelike sound possible in your listening room for many
years to come.
The Definitive Technology Mythos loudspeakers are compact
high-definition loudspeaker systems designed for use in audio/
video systems of the highest quality. Because of their compact
size, wide range, high power handling and natural articulate
clarity, they are ideal for use as a left main, right main, and
center speaker (which may be on-wall or in-cabinet mounted) in
conjunction with all surround sound decoding systems, including
Dolby Pro Logic*, Dolby Digital AC-3*, DTS*, Dolby Digital
EX*, as well as all 6.1 and 7.1 systems. In addition, the Mythos
loudspeakers are ideal for use as rear or side surround speakers
in all surround sound decoding systems or as audiophile quality
main speakers in a high quality stereo system.
On-Wall and On-Shelf
Owner's Manual
Congratulations
Six
™
Seven
™
&
*Registered Trademark
Advertisement
Related Manuals for Definitive Technology Mythos Seven
Summary of Contents for Definitive Technology Mythos Seven
- Page 1 (which may be on-wall or in-cabinet mounted) in conjunction with all surround sound decoding systems, including Dolby Pro Logic*, Dolby Digital AC-3*, DTS*, Dolby Digital EX*, as well as all 6.1 and 7.1 systems.
- Page 2 The Mythos Seven is designed for horizontal mounting and it can be easily mounted on a wall, using its unique mounting system.
-
Page 3: Speaker Break-In
Mythos for left and right main channel use or surround use, the Mythos Seven is perfect for that also. As a center channel, the Mythos Seven can be positioned either above or below the TV. Of course, it can be mounted on the wall, placed on a shelf, or on top of the TV itself if the top of the TV is big enough and flat... - Page 4 If you are using the Mythos as side/rear surround speakers, hook up the left surround red(+) terminal of your receiver or amplifier to the red(+) terminal of your Mythos left surround speaker and the left sur- round black(-) terminal of your receiver or amplifier to the black(-) terminal of your Mythos left surround speaker.
- Page 5 flush to your wall. The bracket can ONLY be used with a vertical installation. (For horizontal installations, the Mythos Seven speaker should be used instead.) For safety, it is extremely important that this bracket be installed with molly-bolts or similarly effective fasteners appropriate for the construction of your wall.
- Page 6 To determine the bracket’s position on the wall, the following measure- ments will be helpful. When the Mythos Seven is installed on the bracket, the top edge of the speaker is 1 inch (25 mm) from the top edge of the bracket, the bottom edge of the speaker is 1 bottom of the bracket.
-
Page 7: Home Theater Systems
Using Your Mythos Seven on a Shelf or Furniture Your Mythos Seven may be used on a shelf or on the top of a television, as long as the flat surface chosen has 5 inches of depth. Please find the supplied threaded foot for your speaker and screw into the... - Page 8 Dolby Digital Systems. Simply hook the Mythos speakers up to the left and right front (main) channels (assuming you are using them as front speakers) and hook the Mythos Seven to the center channel (assuming you are using it as a center channel). Using a low-level RCA cable, hook the subwoofer up to the LFE output on your receiver or processor.
-
Page 9: Technical Assistance
Definitive Technology dealer from whom you have purchased your loudspeakers. If, however, you wish to return the speaker to us, please contact us first, describing the prob- lem and requesting authorization as well as the location of the nearest factory service center. - Page 10 “Large.” If not, set them to “Small”. If you are using the Mythos speaker as a rear or side surround speaker, set the rear or side surround bass management to “Small”. If you are using Mythos loudspeakers without a sepa- rate subwoofer, set bass management to “Large”...
-
Page 11: Limited Warranty
5-Years for Drivers and Cabinets, 3-Years for Electronic Components Definitive Technology warrants to the original retail purchaser only that this Definitive Technology Loudspeaker Product (the “Product”) will be free from defects in materials and workmanship for a period of five (5) years covering the drivers and cabinets, and three (3) years for the electronic components from the date of the original purchase from a Definitive Technology Authorized Dealer.
