- Page 1 RI60165, RI60165A1, RI60166-3, RI60166, RI60166A1,RI60166A2 BRUSHLESS IMPACT WRENCH PRODUCT INFORMATION MANUAL THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. DO NOT ATTEMPT TO OPERATE THE TOOL UNTIL YOU HAVE READ AND UNDERSTOOD ALL INSTRUCTIONS AND SAFETY RULES CONTAINED IN THIS MANUAL.
- Page 2 THANKS FOR CHOOSING THIS PRODUCT Durofix provides you with products at an affordable price, and we would like you to be fully satisfied with this product and our technical support. If any help or advice is needed, please kindly contact us.
-
Page 3: Important Safety Rules
Wear Eye Protection. Wear Hearing Protection. Wear Dust Mask. Power tools can vibrate in use. Keep body stance balanced and firm. Do not overreach when operating this tool. IMPORTANT SAFETY RULES DANGER When using power tools, always prevent exposure and breathing of harmful dust and particles. -
Page 4: Electrical Safety
Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. ELECTRICAL SAFETY WARNING a. Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. - Page 5 personal injury. e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
- Page 6 i. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations. j. When battery pack is not in use, keep it away from other metal objects like: paper clips, coins, keys, nails, screws, or other small metal objects that can make a connection from one terminal to another.
-
Page 7: Specific Safety Rules And Symbols
temperature „130 °C“ can be replaced by the temperature „265 °F“. h. Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire. - Page 8 Do not stare at operation lamp. SYMBOLS The label on your tool may include the following symbols. The symbols and their definitions are as follows: SYMBOL NAME EXPLANATION Volts Voltage (potential) No Load Speed No-load Rotational Speed Kilograms Weight Direct Current Type of Current IEC60417.5031(2002.10) d.c.
-
Page 9: Functional Description
FUNCTIONAL DESCRIPTION Fig. 1 1. 1/4”Drive, 3/8”, 1/2”Anvil, 2. Aluminum Gearbox Housing 3. Built-in LED light 4. Forward / Reverse Control Button 5. Variable Speed Switch 6. Anti-slip Soft Grip 7. ETC Mode setting 8. Power indicator 9. Battery Pack Release Button 10. -
Page 10: Specifications
SPECIFICATIONS Unit RI60165 RI60166-3 RI60166 Model Number Voltage V d.c. Drive/Anvil 1/4”hex. 3/8” sq. 1/2”sq. Max. Tightening Torque ft-lbs 11/25/200 11/25/290 11/25/370 15/35/270 15/35/390 15/35/500 No Load Speed 800/1600/2500 0-3000 Impacts per Minute Tool Weight(with battery 2.0Ah) 4.48 Tool Weight(with battery 2.0Ah) 2.04... - Page 11 Output Amps 1.0A 2.5A ≦ 7 5W ≦ 1 90W Input Power Battery Pack Model Number B6029LA Li-ion Type 2.0Ah Capacity ASSEMBLY INSTALLING OR REMOVING BATTERY PACK TO REMOVE BATTERY PACK: Depress the battery pack release button (A) and pull the battery pack (B) out of tool.
- Page 12 A = 17 mm B = 14 mm Fig. 3 INSTALLING SOCKETS Always follow the procedure below to install a socket. Insert a socket into the anvil (2). Make sure the bit is fixed in the anvil while clicking on the ball of the anvil. REMOVING SOCKETS Always follow the procedure below to remove a socket.
-
Page 13: Operation
Align the holes of metal hook to the tool housing. Use screws to fasten the metal hook to the tool housing. Fasten with Screw Align Hook to Hole OPERATION NOTE Always check the direction of the rotation before use. ETC MODE SETTING & DISPLAY Press the right icon to select the tightening torque which you would like to apply on the bolts of nuts. -
Page 14: Maintenance
Apply forward pressure to the tool to prevent the socket from slipping off the bolt. To start, turn impact wrench/driver on. Always check torque with a torque wrench. The fastening torque can be affected by many factors including the following: Voltage: Low voltage due to a nearly discharged battery will reduce the fastening torque. -
Page 15: Protecting The Environment
Protection Agency to find out about special restrictions on the disposal of tool or return them to a certified service center for recycling. For technical support, call: 886-4-25683366 Service address: Mobiletron Electronics Co., Ltd. No. 85, Sec. 4, Chung-Ching Rd. Ta-Ya, Taichung, 428,Taiwan www.durofix.com.tw...
