Safety Precautions Specific to Mythos STS
The cautionary marking label is located on the bottom of the speaker,
visible through an opening in the granite base.

Power Supply

1. The fuse and power disconnect device are located on the bottom of the
speaker, accessible through a hole in the granite base.
2. The disconnect device is the power cord, detachable at either the speaker
or the wall.
3. The power cord must be disconnected from the speaker before servicing.
Unpacking Your Mythos STS
Please Inspect For Shipping Damage
Each loudspeaker leaves our plant in perfect condition. Any visible or
concealed damage most likely occurred in handling after it left our plant and
should be reported at once to your Definitive dealer or the delivery company that
delivered your loudspeaker. Please unpack your system carefully. Save all cartons
and packing materials in case you move or need to ship your system. Record the
serial number found on the back of the Mythos STS in the appropriate place on
your warranty card, answer all questions and send it in.
VERY IMPORTANT: Accessories
Various parts and accessories that you will need to assemble your Mythos STS
are in the carton but are easy to overlook. Open both ends of the shipping carton.
Carefully examine the contents of the shipping carton and packing material to find
the plastic bags with accessories.

Base Installation Instructions

Tools required: 4mm (or
in carton
Parts required: Polished Granite Base, Cable Clip for AC Cord, four Allen head
bolts, eights plastic washers. All required parts are included in the
product carton.
Instructions:
1. Carefully lay the Mythos STS on its side. Lift the base of the speaker about six
inches and support it with a soft padded object, such as a pillow. Do NOT
support the speaker with a hard object, as you might dent or scratch the
aluminum finish.
2. Place one plastic washer on each bolt.
3. Insert the bolts into the granite base from the bottom (the same side that the
levelling feet are attached).
5 / ") Allen wrench (also called Hex Key driver) included
32
3
