- Page 1 Smart Embedded Switch 1 & 2 Gang WL-ZCSENPB-S0410-01, WL-ZCSENPB-S0420-01 Product Manual Version 1.0 © 2019 Logika Limited...
- Page 2 Introduction Thank you for choosing Logika. Please take a moment to carefully read through the manual to ensure safe and proper installation and use. • Before use, the product must be properly installed as described in this manual by a qualified technician.
-
Page 3: Device Layout
Device Layout This manual uses a two-gang switch as an example. -
Page 4: Specifications
Features • Communication Mode: IEEE 802.15.4 Zigbee. Embedded design designed to keep the existing switch and transform it into a smart switch. • • Keeps lights in sync with smart system. Can be linked to smart assistants such as Amazon Alexa to allow voice-controlled lighting. •... -
Page 5: Installation Steps
Installation Steps Hardware Installation The wiring diagrams for the embedded switch are below. Please refer to the one appropriate for your fitting and use case. - Page 6 1) Remove the switch panel and connect the Smart Embedded Light Switch to the incoming wiring by following the appropriate wiring diagram above. 2) Connect the S1 and/or S2 to the wall switch side and check the wiring thoroughly. 3) Prior to screwing the switch plate back onto the wall, you will need access to the SET button on the top of the unit to enable you to connect the device to the Zigbee network.
- Page 7 Adding the Device to the Smart Home Network Use the Logika Smart Home app to add the device to the Smart Home system. Please refer to the Logika Smart Mobile App user guide which will take you through the process of adding smart devices to the system.
-
Page 8: Device Functions
Device Functions When the device is first powered on, it will normally automatically attempt to connect to the Zigbee Smart Home network. The System Indicator light will flash as it’s searching for the network. If it connects, the light will remain on for 2 seconds and then go out. If this does not happen, you can manually connect via the mobile app and follow the instructions below. -
Page 9: Safety Precautions
Safety Precautions • Disable any power prior to connecting the device to the main supply. • The device must be installed by a qualified electrician. • Do not disassemble or refit this product or its accessories. • The device should be mounted in a dry environment. It is not designed to be used outdoors. -
Page 10: Troubleshooting
You should now be free to add the device to the local smart network. The issue you are experiencing is not mentioned here. Please contact us at support@logika.nz with your issue and we will do our utmost to help!
