- Page 1 Smart Scene Switch SR-ZRCPBPW-S4160-01 Product Manual Version 1.0 © 2019 Logika Limited...
- Page 2 Introduction Thank you for choosing Logika. Please take a moment to carefully read through the manual to ensure safe and proper installation and use. • Before use, the product must be properly installed as described in this manual by a qualified technician.
-
Page 3: Device Layout
Device Layout Battery Compartment Application Indicator Scene Switch 2 Scene Switch 3 Scene Switch 4 Scene Switch 5 System Indicator Scene Switch 6 Scene Switch 1 Multi-Function Button Screen Display Back Front Packing List Scene Switch Big Base Small Base Screw/Wall Plug x2 Screw Plug x1 M4*30 Screw x2... -
Page 4: Specifications
Features • Communication Mode: IEEE 802.15.4 Zigbee. Activate pre-set customised scenes. • • Can bind with multiple smart devices to control in real-time. Can be linked to smart assistants such as Amazon Alexa to allow voice-controlled scenes. • Battery operated and easy to install or use in-hand. •... -
Page 5: Installation Steps
Installation Steps Hardware Installation The Scene Switch is designed to be carried like a remote and can also be mounted on the wall if so desired. Option A: If installing onto a back box, use the M4 screws and screw the Big Base onto the back box. Option B: You can also mount the Big Base directly onto the wall. - Page 6 Adding the Device to the Smart Home Network Use the Logika Smart Home app to add the device to the Smart Home system. Please refer to the Logika Smart Mobile App user guide which will take you through the process of adding smart devices to the system.
-
Page 7: Device Functions
Device Functions When the device is first powered on, it will normally automatically attempt to connect to the Zigbee Smart Home network. The System Indicator light will flash as it’s searching for the network. If it connects, the light will remain on for 2 seconds and then go out. If this does not happen, you can manually connect via the mobile app and follow the instructions below. -
Page 8: Safety Precautions
Safety Precautions • Disable any power prior to connecting the device to the main supply. • The device must be installed by a qualified electrician. • Do not disassemble or refit this product or its accessories. • The device should be mounted in a dry environment. It is not designed to be used outdoors. -
Page 9: Troubleshooting
You should now be free to add the device to the local smart network. The issue you are experiencing is not mentioned here. Please contact us at support@logika.nz with your issue and we will do our utmost to help!
