DVI 4K Video Secure KVM Switch
User Manual
1. SV141D0– I/O 4 Port Single DVI 4K video Secure KVM without CAC PP3.0
2. SV141D1– I/O 4 Port Single DVI 4K video Secure KVM with CAC PP3.0
3. SV241D0– I/O 4 Port Dual DVI 4K video Secure KVM without CAC PP3.0
4. SV241D1– I/O 4 Port Dual DVI 4K video Secure KVM with CAC PP3.0
5. SV121D0– I/O 2 port Single DVI 4K video Secure KVM without CAC PP3.0
6. SV121D1– I/O 2 port Single DVI 4K video Secure KVM with CAC PP3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SV141D0 and is the answer not in the manual?

Questions and answers

Related Manuals for I/O Interconnect SV141D0

Summary of Contents for I/O Interconnect SV141D0

  • Page 1 DVI 4K Video Secure KVM Switch User Manual 1. SV141D0– I/O 4 Port Single DVI 4K video Secure KVM without CAC PP3.0 2. SV141D1– I/O 4 Port Single DVI 4K video Secure KVM with CAC PP3.0 3. SV241D0– I/O 4 Port Dual DVI 4K video Secure KVM without CAC PP3.0 4.

  • Page 2: Table Of Contents

    Table of Contents Introduction ......................2 Package Contents .................2 ˙ ˙ Item Sold Separately ................2 Safety Precautions ................3 ˙ User Guidance & Precautions ...............4 ˙ Overview ......................5 Security Features ..................5 ˙ Tamper Evident Labels .................5 ˙ Other Features ..................6 ˙ ˙ Equipment Requirements ..............7 ˙...

  • Page 3: Introduction

    Introduction Introduction Thank you for purchasing this Interconnect (I/O) DVI 4K video secure KVM switch. This Switch is designed for use in secure environment installations. The Switch offers safe centralized control, which prevents unintended data transfer between computers running at different security levels.

  • Page 4: Safety Precautions

    Safety Precautions Please read the following safety precautions carefully before using the product: Before cleaning, disconnect the product from any electrical power supply.   Do not expose the product to excessive humidity or moisture.  Do not store or use for extensive period of time in extreme thermal conditions – it may shorten product lifetime. Install the product only on a clean secure surface.

  • Page 5: User Guidance & Precautions

    User Guidance & Precautions Please read the following User Guidance & Precautions carefully before using the product: 1. As product powers-up it performs a self-test procedure. In case of self- test failure for any reason, including jammed buttons, the product will be Inoperable.

  • Page 6: Overview

    Overview Security Features Product is designed, manufactured and delivered in security-controlled environments. Below is a summary of the main advanced features incorporated in product: Advanced isolation between computers and shared peripherals: The emulations of keyboard, mouse and display EDID, prevent direct contact between computers and shared peripherals. Product design achieves maximal security by keeping the video path separate with keyboard and mouse switched together, purging keyboard buffer when switching channels.

  • Page 7: Other Features

    Product Enclosure Warning Label I/O Secure KVM Switch has the following Holographic Tamper Evident labels on product enclosure: Other Features The I/O Secure DVI KVM was designed with the user in mind for today’s IT environment. Below is a summary of some features incorporated into the Switch.

  • Page 8: Equipment Requirements

    Port Coloring The included color label can be associated with an established network to facilitate port identification and reduce user switching error. LED Indicators Each port button number illuminates to indicate that the console currently controls the corresponding computer. As a port selector is pushed, the LED number will light up.

  • Page 9: System Requirements

    System Requirements Operating Systems Product is compatible with devices running on the following operating systems: Microsoft® Windows® 2000   Microsoft® Windows® Vista Microsoft® Windows® 7   Microsoft® Windows® 8  Microsoft® Windows® 8.1  Microsoft® Windows® 10  Linux®: Kernel 2.6+, RedHat v6.0+, SuSE v8.2+.
  • Page 10 USB Port The product USB port is compatible with standard USB port, standard 2 or 3 buttons USB mouse or keyboard. Monitor Port The product DVI monitor is compatible with the highest resolution. CAC Port The product is compatible for CAC (Common Access Card) reader. PS/2 Port The product is compatible for standard PS/2 keyboard or mouse.

  • Page 11: Unit Display Diagrams

    Unit Display Diagram SV141D0 Model Shown nit Display Diagram, Front View Unit Display Diagram, Back View SV141D1 Model Shown Unit Display Diagram, Back View nit Display Diagram, Front View Ioint® Secure DVI 4K KVM Switch User Manual...
  • Page 12 SV241D0 Model Shown nit Display Diagram, Front View Unit Display iagram, Back View SV241D1 Model Shown Unit Display Diagram, Back View nit Display Diagram, Front View Ioint® Secure DVI 4K KVM Switch User Manual...
  • Page 13 SV121D0 Model Shown Unit Display Diagram, Back View nit Display Diagram, Front View SV121D1 Model Shown Unit Display Diagram, Back View nit Display Diagram, Front View Ioint® Secure DVI 4K KVM Switch User Manual...

  • Page 14: Specifications

    Heavy-duty extruded aluminum Audio 1/8" (3.5mm) female enclosure with metal faceplate Power Requirements Port Selectors 12V DC, 1.5A (maximum) power 4 Port (SV141D0, SV141D1, adapter with center-pin-positive SV241D0, SV241D1) polarity. 2 Port (SV121D0, SV121D1) AC Input LED Indicators 90 to 264VAC...

  • Page 15: Installation

    Installation Pre-Configuration Where to place the Switch: Important: The enclosure of the Switch is designed for desktop or rack-mount configuration. If the unit’s enclosure appears disrupted or if all channel-select Rack-mount brackets are included with the Switch (Sold Separately). LEDs Flash continuously, please remove product from Consider the following when deciding where to place the Switch: Service immediately and contact I/O Technical Support at Your proximity to the port selectors on the front of the Switch...

  • Page 16: Color Code Label Installation

    Step 3 – Connecting the Computers 3.1 Using USB cables, connect each computer to the USB port in “computer interface ports” area on product. 3.2 If computer uses audio output, e.g. speakers/headphones, connect audio cable from its audio output port to the corresponding audio input port on product. 3.3 If the computer uses a smart card/CAC reader, connect a USB cable between the CAC-enabled computer and the corresponding CAC port on product.

  • Page 17: Operating The Kvm Switch

    Operating the KVM Switch Selecting a Computer Using Port Selectors Now that you have connected your console and computers to the Switch, it is ready for use. You can select which computer you wish to control by Self-Test Procedure: pressing the corresponding port selector on the front of the Switch.

  • Page 18: Common Access Card (Cac) Configuration And Operation

    Common Access Card (CAC) Configuration and Operation CAC connection to the computer requires a separate USB cable connection and allows the user to specify whether there is a CAC required for that computer or not. This allows the CAC to be connected and controlled separately to the keyboard, mouse, video and audio.

  • Page 19: Troubleshooting

    Troubleshooting General As product powers-up all channel-select LEDs are turned and then OFF. After that a specific, predefined combination is  turned Product is inoperable. The product did not pass self-test procedure. Try to power cycle product. If problem persists please contact your system administrator or our technical support tech@ioint.com My computer does not boot when connected to the Switch but works fine when I connect my keyboard, video, and mouse...
  • Page 20 Video I am getting ghosting, shadowing, or fuzzy images on my monitor. Check that all video cables are inserted properly to the Switch, computer, and monitor.  With everything connected power-cycle the I/O Secure DVI KVM to reset the video. ...
  • Page 21 Keyboard The computer does not detect my keyboard, or my keyboard does not work when I switch computers or reboot.  Check that the keyboard you are using is connected properly to the Switch, in the USB port labeled “Keyboard.” ...

  • Page 22: Information

    We at I/O Interconnect Inc., of 1202E Wakeham Ave Santa Ana CA 92705, declare under our sole responsibility that the product, SV141D0, SV141D1, SV121D0, SV121D1, SV241D0, and SV241D1, to which this declaration relates, complies with Part 15 of the FCC Rules.
  • Page 23 For information on product disposal please refer to www.ioint.com/ environmental. Australia Declaration of Conformity We at I/O Interconnect Inc., declare under our sole responsibility that the product SV141D0, SV141D1, SV121D0, SV121D1, SV241D0, and SV241D1 to which this declaration relates, are in conformity with the requirements of AS/NZS regulations for Class B Information Technology Equipment (ITE).
  • Page 24 Warranty Interconnect Inc., Limited 3-Year Product Warranty What this warranty covers? I/O Interconnect Inc. Warrants to the original purchaser of this I/O product that the product shall be free of defects in design, assembly, material, or workmanship. What the period of coverage is? I/O warrants the I/O product for three years.
  • Page 25 How to get service. To get service for your I/O product you must take the following steps: 1. Contact I/O Interconnect Inc., at 1202 E WAKEHAM AVE, SANTA ANA CA 92705, Attn: Customer Service, or call (1 (714) 564-1111), within 15 days of the Occurrence.
  • Page 26 Reporting Product Security Vulnerability If you are aware of potential security vulnerability with any I/O Interconnect product, we encourage you to contact us immediately at the following email address: info@ioint.com or our technical support line at: 1 (714) 564-1111. After your communication is received, Interconnect personnel will contact you to follow To ensure confidentiality, I/O encourages you to use our PGP encryption key.
  • Page 27 Ioint.com © 2018 I/O Interconnect, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Mac OS is a trademark of Apple Inc., registered in the U.S.
