DP (Display Port)-HDMI 4K Video
Secure KVM Switch
User Manual
1. SV142H0– I/O 4 Port Single DP-HDMI 4K video Secure KVM without CAC PP3.0
2. SV142H1– I/O 4 Port Single DP-HDMI 4K video Secure KVM with CAC PP3.0
3. SV242H1– I/O 4 Port Dual DP-HDMI 4K video Secure KVM with CAC PP3.0
4. SV242H0– I/O 4 Port Dual DP-HDMI 4K video Secure KVM without CAC PP3.0
Advertisement
Table of Contents
Related Manuals for I/O Interconnect SV142H0
Summary of Contents for I/O Interconnect SV142H0
- Page 1 Secure KVM Switch User Manual 1. SV142H0– I/O 4 Port Single DP-HDMI 4K video Secure KVM without CAC PP3.0 2. SV142H1– I/O 4 Port Single DP-HDMI 4K video Secure KVM with CAC PP3.0 3. SV242H1– I/O 4 Port Dual DP-HDMI 4K video Secure KVM with CAC PP3.0...
-
Page 2: Table Of Contents
Table of Contents Introduction .......................2 Package Contents .................2 Item Sold Separately ................2 Safety Precautions ................3 User Guidance & Precautions ...............4 Overview ......................5 Security Features ..................5 Tamper Evident Labels .................5 Other Features ..................6 Equipment Requirements ..............7 ... -
Page 3: Introduction
Introduction Thank you for purchasing this Interconnect (I/O) DP-HDMI 4K video secure KVM switch. This Switch is designed for use in secure environment installations. The Switch offers safe centralized control, which prevents unintended data transfer between computers running at different security levels. -
Page 4: Safety Precautions
Safety Precautions Please read the following safety precautions carefully before using the product: Before cleaning, disconnect the product from any electrical power supply. Do not expose the product to excessive humidity or moisture. Do not store or use for extensive period of time in extreme thermal conditions – it may shorten product lifetime. Install the product only on a clean secure surface. -
Page 5: User Guidance & Precautions
User Guidance & Precautions Please read the following User Guidance & Precautions carefully before using the product: 1. As product powers-up it performs a self-test procedure. In case of self- test failure for any reason, including jammed buttons, the product will be Inoperable. -
Page 6: Overview
Overview Security Features Product is designed, manufactured and delivered in security-controlled environments. Below is a summary of the main advanced features incorporated in product: Advanced isolation between computers and shared peripherals: The emulations of keyboard, mouse and display EDID, prevent direct contact between computers and shared peripherals. Product design achieves maximal security by keeping the video path separate with keyboard and mouse switched together, purging keyboard buffer when switching channels. -
Page 7: Other Features
Product Enclosure Warning Label I/O Secure KVM Switch has the following Holographic Tamper Evident labels on product enclosure: Other Features The I/O Secure DP-HDMI KVM was designed with the user in mind for today’s IT environment. Below is a summary of some features incorporated into the Switch. -
Page 8: Equipment Requirements
Port Coloring The included color label can be associated with an established network to facilitate port identification and reduce user switching error. LED Indicators Each port button number illuminates to indicate that the console currently controls the corresponding computer. As a port selector is pushed, the LED number will light up. -
Page 9: System Requirements
System Requirements Operating Systems Product is compatible with devices running on the following operating systems: Microsoft® Windows® 2000 Microsoft® Windows® Vista Microsoft® Windows® 7 Microsoft® Windows® 8 Microsoft® Windows® 8.1 Microsoft® Windows® 10 Linux®: Kernel 2.6+, RedHat v6.0+, SuSE v8.2+. - Page 10 USB Port The product USB port is compatible with standard USB port, standard 2 or 3 buttons USB mouse or keyboard. Monitor Port The product DP-HDMI monitor is compatible with the highest resolution. CAC Port The product is compatible for CAC (Common Access Card) reader. PS/2 Port The product is compatible for standard PS/2 keyboard or mouse.
-
Page 11: Unit Display Diagrams
Unit Display Diagram SV142H0 Model Shown nit Display Diagram, Front View nit Display Diagram, Front View SV142H1 Model Shown Unit Display Diagram, Back View nit Display Diagram, Front View Ioint® Secure DP-HDMI 4K KVM Switch User Manual... - Page 12 SV242H1 Model Shown Unit Display Diagram, Back View nit Display Diagram, Front View SV242H0 Model Shown nit Display Diagram, Front View Unit Display Diagram, Back View Ioint® Secure DP-HDMI 4K KVM Switch User Manual...
-
Page 13: Specifications
Specifications Part No. SV142H0, SV142H1, SV242H1, CAC Ports USB Type A Female SV242H0 Enclosure Faceplate Audio Heavy-duty extruded aluminum 1/8" (3.5mm) female enclosure with metal faceplate Power Requirements 12V DC, 1.5A (maximum) power Port Selectors 4 Port (SV142H0,SV142H1 adapter with center-pin-positive SV242H1,SV242H0) polarity. -
Page 14: Installation
Installation Pre-Configuration Where to place the Switch: Important: The enclosure of the Switch is designed for desktop or rack-mount configuration. If the unit’s enclosure appears disrupted or if all channel-select Rack-mount brackets are included with the Switch (Sold Separately). LEDs Flash continuously, please remove product from Consider the following when deciding where to place the Switch: Service immediately and contact I/O Technical Support at Your proximity to the port selectors on the front of the Switch... -
Page 15: Color Code Label Installation
Step 3 – Connecting the Computers 3.1 Using USB cables, connect each computer to the USB port in “computer interface ports” area on product. 3.2 If computer uses audio output, e.g. speakers/headphones, connect audio cable from its audio output port to the corresponding audio input port on product. 3.3 If the computer uses a smart card/CAC reader, connect a USB cable between the CAC-enabled computer and the corresponding CAC port on product. -
Page 16: Operating The Kvm Switch
Operating the KVM Switch Selecting a Computer Using Port Selectors Self-Test Procedure: As product powers-up it performs a self-test procedure. In case of self- test failure for any reason, including jammed buttons, the product will be Inoperable. Self-test failure will be indicated by the following abnormal LED behavior: All channel-select LEDs will be turned ON and then OFF;... -
Page 17: Common Access Card (Cac) Configuration And Operation
Common Access Card (CAC) Configuration and Operation CAC connection to the computer requires a separate USB cable connection and allows the user to specify whether there is a CAC required for that computer or not. This allows the CAC to be connected and controlled separately to the keyboard, mouse, video and audio. -
Page 18: Troubleshooting
Troubleshooting General As product powers-up all channel-select LEDs are turned and then OFF. After that a specific, predefined combination is turned Product is inoperable. The product did not pass self-test procedure. Try to power cycle product. If problem persists please contact your system administrator or our technical support tech@ioint.com ... - Page 19 Video I am getting ghosting, shadowing, or fuzzy images on my monitor. Check that all video cables are inserted properly to the Switch, computer, and monitor. With everything connected power-cycle the I/O Secure DP-HDMI KVM to reset the video. Make sure the Video Diagnostic LED is solid green.
- Page 20 Keyboard The computer does not detect my keyboard, or my keyboard does not work when I switch computers or reboot. Check that the keyboard you are using is connected properly to the Switch, in the USB port labeled “Keyboard.” Check that the USB cable between the Switch and the computer is completely connected.
-
Page 21: Information
This product may only be plugged in to socket outlets that are easily accessible. FCC Statement DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY We at I/O Interconnect Inc., of 1202 E. Wakeham Ave Santa Ana CA 92705, declare under our sole responsibility that the product, SV142H0, SV142H1, SV242H0 and SV242H1. - Page 22 For information on product disposal please refer to www.ioint.com/ environmental. Australia Declaration of Conformity We at I/O Interconnect Inc., declare under our sole responsibility that the product SV142H0, SV142H1, SV242H0, SV242H1, to which this declaration relates, are in conformity with the requirements of AS/NZS regulations for Class B Information Technology Equipment (ITE).
- Page 23 Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Ioint® Secure DP-HDMI 4K KVM Switch User Manual...
- Page 24 Warranty Interconnect Inc., Limited 3-Year Product Warranty What this warranty covers? I/O Interconnect Inc. warrants to the original purchaser of this I/O product that the product shall be free of defects in design, assembly, material, or workmanship. What the period of coverage is? I/O warrants the I/O product for three years.
- Page 25 How to get service. To get service for your I/O product you must take the following steps: 1. Contact I/O Interconnect Inc., at 1202 E WAKEHAM AVE, SANTA ANA CA 92705, Attn: Customer Service, or call (1 (714) 564-1111), within 15 days of the Occurrence.
- Page 26 Reporting Product Security Vulnerability If you are aware of potential security vulnerability with any I/O Interconnect product, we encourage you to contact us immediately at the following email address: info@ioint.com or our technical support line at: 1 (714) 564-1111. After your communication is received, Interconnect personnel will contact you to follow To ensure confidentiality, I/O encourages you to use our PGP encryption key.
- Page 27 Ioint.com © 2018 I/O Interconnect, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Windows and Windows Vista are Ioint® Secure DP-HDMI 4K KVM Switch User Manual either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Mac OS is a trademark of Apple Inc., registered in the U.S.
