Universal Furniture 597602 Instruction Sheet

597602
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts that may have come loose inside the carton during shipment.
Caution: (1) These parts are cumbersome and heavy. This product can best be assembled with the
assistance of one or more persons in order to prevent personal injury and to insure parts are not damaged
during the assembly process. If dirty, clean finished parts with mild dishwashing liquid and water solution
applied on damp cloth. Cloth should not be excessively wet. Polish finish with soft cloth and an industry
recognized furniture polish.
(2) To prevent damage to your floor or carpet, please check the bottom of each piece of furniture for
stain residue and rough surfaces and also check for staples or nails left after removing the packaging material.
The manufacturer will not be held responsible if preventative steps are not taken prior to installation.
(3) Unpack and dispose of all packing material but be careful not to throw away any assembly parts or
hardware. Read the instruction sheet and parts list carefully. Remove all staples and screws used for
packaging carefully using pliers and or screwdrivers to prevent injury and scratching or damaging flooring.
(4) During normal use everyday, screws, bolts, nuts and wooden plugs may loosen up. They should be
periodically inspected and re-tightened to prevent damage to the furniture and (or) personal property or cause
injury. Always check to be sure all hardware on this list and the above mentioned components is attached to
the furniture properly and kept tightened at all times.
PARTS LIST:
# Description
A Seat Frame
C Shelf
Assembly Procedure:
CAUTION: PLEASE DO NOT OVER-TIGHTEN BOLTS DURING ASSEMBLY.
Step 1: Place all stool parts on a soft and smooth surface. Remove the plastic cover on the stool seat
cushion. Place the Seat Frame (A) upside down in a smooth, clean and non-abrasive surface.
Step 2: Attach Stool Legs (B)) to Seat Frame (A) using Bolt (1), Spring Washer and Flat Washer.
Tighten with Wrench (2).
Step 3: Turn the Shelf (C) face upside down and put it on bottom of the assembled legs.
Step 4: Then attach the Feet (D) to the legs through the hole in the shelf.
Step 5: After making sure all bolts are attached and hand tightened, turn the Stool upright.
Assembly is now complete.
N O
2-1/4" L
1
2
INSTRUCTION SHEET
Qty. #
1 pc B
1 pc D
Hardware List
Bolt+Spring Washer+Flat Washer -- 1/4" Dia
Wrench
KITCHEN STOOL
Description
Stool Leg
Foot
Qty.
4 pcs
4 pcs
Qty.
8pcs
1pc
