596/597A-965
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts that may have come loose inside the carton during shipment.
Caution: (1) These parts are cumbersome and heavy. This product can best be assembled with the
assistance of one or more persons in order to prevent personal injury and to insure parts are not damaged
during the assembly process. If dirty, clean finished parts with mild dishwashing liquid and water solution
applied on damp cloth. Cloth should not be excessively wet. Polish finish with soft cloth and an industry
recognized furniture polish.
(2) To prevent damage to your floor or carpet, please check the bottom of each piece of furniture for
stain residue and rough surfaces and also check for staples or nails left after removing the packaging material.
The manufacturer will not be held responsible if preventative steps are not taken prior to installation.
(3) Unpack and dispose of all packing material but be careful not to throw away any assembly parts or
hardware. Read the instruction sheet and parts list carefully. Remove all staples and screws used for
packaging carefully using pliers and or screwdrivers to prevent injury and scratching or damaging flooring.
(4) During normal use everyday, screws, bolts, nuts and wooden plugs may loosen up. They should be
periodically inspected and re-tightened to prevent damage to the furniture and (or) personal property or cause
injury. Always check to be sure all hardware on this list and the above mentioned components is attached to
the furniture properly and kept tightened at all times.
PARTS LIST:
# Description
A Left pier
C Lower Back Panel
E Front Rail
G Shelf
I Hardware Pack
Assembly Procedure
Step 1: Unpack, inspect, and read assembly instruction carefully. Lay out the parts and hardware.
Make sure the quantity of each is correct.
Step 2: Disregard from step 2 to step 4 when hutch is not in use. Connect lower back panel (C) and
upper back panel (D) to left pier (A) and right pier (B) with allen head bolts (1) using allen
wrench (3). Then lock upper back panel (D) and lower back panel (C) with wood screws (2)
by screw driver (Not provided).
Step 3: Attach the front rail (E) onto the piers (A & B) with allen head bolts (1) using allen wrench (3).
Insert wood dowels (4) into the predrilled holes of piers (A & B), then attach the hutch top (F)
onto the piers (A & B) with allen head bolts (1) using allen wrench (3). And lock it from back
side.
Step 4: Attach wood shelf (G) to left pier (A) and right pier (B) with shelf pins (5), wood screws (2) by
screw driver (not provided). Put the hutch onto entertainment (H) with wood screws (2) by
screw driver. (Not provided)
Note: It is best two or more persons are involved.
Assembly is now complete.
INSTRUCTION SHEET
Qty. #
1pc B
1pc D
1pc F
1pc H
1bag
: (Please follow the sketches below.)
Entertainment Deck
Description
Right pier
Upper Back Panel
Hutch top
Entertainment
Qty.
1pc
1pc
1pc
1pc
