COMPONENTS
No. Part
1
Base Shelf
2
Left Leg – Front
3
Left Leg – Back
4
Right Leg – Front
5
Right Leg – Back
6
Wheel
7
Axle
8
Sleeve
9
Top Frame
10 Fixing Plates
Quantity
No. Part
1
11
1
12
1
1
13
1
14
2
15
1
A
2
B
1
C
4
D
Handle
Oven Body
with Fire Brick Tiles
Chimney
Chimney Cap
Door
M6*12 Screws
M6 Lock Nuts (for wheels)
OD18*ID6.5 T1.0 Washers
M6*38 Screws
Quantity
1
1
1
1
1
27
2
2
4
3
