Installing the Device
2.3.1 Mounting the Device on a DIN Rail
Mounting the Device
To mount the device to a DIN rail, do the following:
1.
2.
3.
8
Hook the top teeth of the adapter onto the DIN rail.
Note
The adapter features a sliding release with a slot at the bottom for a flathead
screwdriver.
1
DIN Rail
1
DIN Rail Adapter
2
Figure 2.1
Mounting the Device to a DIN Rail
Insert a flathead screwdriver into the slot of the sliding release and move it
down.
Push the device against the bottom of the DIN rail, then let go of the sliding re-
lease to latch the device.
3
Installation Manual, 02/2020, C79000-G8976-1032-06
1
1
2
2
RUGGEDCOM RS920L
