Pressure Washer A-Frame Hose Reel
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Items #55791, #55792 & #55793
READ & SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for North Star 55791
Summary of Contents for North Star 55791
- Page 1 Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Items #55791, #55792 & #55793 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a NorthStar™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Assembly Instructions .......................... 6 Before Each Use ............................ 7 Operating Instructions .......................... 7 After Each Use ............................7 Maintenance ............................ -
Page 4: Intended Use
NPT-F (2) Technical Specifications Property Specification Pressure 5000 PSI ° Maximum Temperature Shipping Weight 30 lb. (#55791) 32 lb. (#55792 & #55793) 150’ 3/8" Hose Capacity #55791 300’ 3/8" Hose Capacity #55792 450’ 3/8" Hose Capacity #55793 Inlet 1/2" NPT-F Outlet 1/2"... - Page 5 The warnings, cautions, and instructions in this manual cannot cover all possible conditions or situations that could occur. Exercise common sense and caution when using this tool. Always be aware of the environment and ensure that the tool is used in a safe and responsible manner. ...
-
Page 6: Specific Operation Warnings
⚠CAUTION HOSE REEL USE AND CARE Do not force the hose reel. Products are safer and do a better job when used in the manner for which they are designed. Plan your work, and use the correct product for the job. ... -
Page 7: Before Each Use
Attach the pump hose to the hose reel swivel. The hose reel is now ready for operation. Before Each Use ⚠WARNING Be sure all fittings are tight. Be sure the unit is securely mounted. Operating Instructions ⚠WARNING Do not over pressurize the system. Be sure there are no leaks. Release the pin lock to unwind the hose. -
Page 8: Maintenance
Part Description Quantity 2103282 ASSY, HUB & FLANGE, #55793 2103242 ASSY, HUB & FLANGE, #55792 2103247 ASSY, HUB & FLANGE, #55791 2103283 FRAME, HOSE REEL, #55793 2103243 FRAME, HOSE REEL, #55792 2103248 FRAME, HOSE REEL, #55791 Page 8 of 11... -
Page 9: Replacement Parts
Reference Part Number Part Description Quantity 2640025 PILLOW BLOCK 2103244 ASSY, CRANK 2103245 ASSY, LOCK PIN 2540087 BRACKET, BRAKE 2660268 BRAKE 2200103 BOLT, M8 2203018 NUT, WING, M8 2200104 BOLT, M10 2203017 NUT, M10, NYLOK, SST 2200013 WASHER, M8, SS 2203413 WASHER, FLAT, M10 2103246... -
Page 10: Limited Warranty
Limited Warranty Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the NorthStar product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of two years from date of purchase. - Page 11 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 11 of 11...
