Ratek OM1 Compact Orbital Shaker – User Manual
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
User Manual
Compact Orbital Shaker
Model : OM1
Version: 1.1 – 01/08/2015
English
www.ratek.com.au
60 Wadhurst Dve, Boronia, Victoria 3155, Australia - P: +613 9887 2161 - F: +613 9887 2163 - E:
sales@ratek.com.au
© All Rights Reserved
Made in Australia, User Manual printed in Australia
Changes without prior notification reserved
Errors and omissions excepted.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Page 1 of 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OM1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ratek OM1

  • Page 1 Ratek OM1 Compact Orbital Shaker – User Manual ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- User Manual Compact Orbital Shaker Model : OM1 Version: 1.1 – 01/08/2015 English www.ratek.com.au 60 Wadhurst Dve, Boronia, Victoria 3155, Australia - P: +613 9887 2161 - F: +613 9887 2163 - E: sales@ratek.com.au...
  • Page 2 Thank you Thank you for purchasing a Ratek product. This User Manual will assist you in the correct installation and operation of the OM1 Compact Orbital Shaker, as well as explain the safety requirements for its use. Important: Please read the contents of this User Manual before unpacking and operating the product.
  • Page 3: Table Of Contents

    Ratek OM1 Compact Orbital Shaker – User Manual ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- TABLE OF CONTENTS PAGE Cash Bo INTENDED USE....................................................................................................................................4 4 4 4 Suitable Articles For Use With This Compact Orbital Shaker ........................4 Unsuitable Articles For Use With This Compact Orbital Shaker ........................
  • Page 4: Intended Use

    Ratek OM1 Compact Orbital Shaker – User Manual ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Intended Use This Compact Orbital Shaker is intended for the purpose of agitating vessels containing liquid to create an orbital mixing action inside the vessel. The Compact Orbital Shaker is not intended to provide direct-contact between itself and an unprotected medical, food, biological or medico- techno item.
  • Page 5: Safety Labels And Markings

    • Important: If you have any concerns or questions relating to operator or user safety, please contact the appropriate Ratek Service department before installing and operating the unit. Contact details are provided in this User Manual.
  • Page 6: Operating Procedures

    Ratek OM1 Compact Orbital Shaker – User Manual ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Operating Procedures You must take the time to familiarize yourself completely with the following operating procedures before installing or operating the Compact Orbital Shaker in order to achieve the best performance and maximum attainable user safety.
  • Page 7: Safety Warnings

    Ratek OM1 Compact Orbital Shaker – User Manual ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Safety Warnings Throughout this User Manual, specific warnings will be supplied which relate to the current operation being referred to. These warnings are supplied in addition to the main warning labels affixed to the product and the key points outlined in the section of this User Manual titled ‘Operator Responsibility –...
  • Page 8: Preparation & Installation

    Ratek OM1 Compact Orbital Shaker – User Manual ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Preparation & Installation The Compact Orbital Shaker should be installed and operated in strict accordance with the following instructions. CAUTION Be careful when lifting and observe your local operational health and safety requirements for lifting before unpacking the carton.
  • Page 9: Using The Compact Orbital Shaker

    Ratek OM1 Compact Orbital Shaker – User Manual ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Using The Compact Orbital Shaker Choosing a Suitable Vessel - The Compact Orbital Shaker should only be used with vessels that are sealed and are adequately secured to the mixing platform to prevent spillage whilst in use.
  • Page 10: Optional Accessories

    Optional Accessories The OM1 platform has a Nitrile rubber mat supplied as standard and will be sufficient to hold most flasks and containers at low speeds. For higher speeds a suitable retaining system would be required. The following optional clips and racks are available from your Ratek dealer.
  • Page 11: Routine Cleaning And Maintenance

    Ratek are consulted prior to decontamination or cleaning being undertaken if there is any doubt about the compatibility of decontamination or cleaning agents with parts of the Compact Orbital Shaker or with any materials contained in it.
  • Page 12 Ratek OM1 Compact Orbital Shaker – User Manual ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Maintenance - Unplug the equipment from the mains power supply outlet. - Under good light, carefully inspect the mains power lead and check for any signs of wear, over-extension or damage. If you believe the lead to be damaged in any way, contact your supplier.
  • Page 13: Technical Specifications

    Ratek OM1 Compact Orbital Shaker – User Manual ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Technical Specifications Power requirements 240v AC / 40 watts Motor Brushless AC Speed Controller Solid State Analogue Speed Range 20 to 200 RPM Variable Drive Silent Belt & Pulley Platform 210 x 180mm with Nitrile mat.
  • Page 14: Ratek Service Contact Information

    ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Ratek Service Contact Information Ratek are here to assist you in getting the most from your Compact Orbital Shaker. Our friendly staff can you assist you at any stage of the product lifecycle. If you have any concerns or questions regarding the operation of your Compact Orbital Shaker, please contact us.
  • Page 15: Warranty Conditions

    ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Warranty Conditions This Ratek product is covered by a 3 year parts and 12 months labour return-to-base warranty effective from the date of purchase. The product is manufactured in Melbourne, Australia. The warranty is offered by Ratek Instruments Pty. Ltd. located at 60 Wadhurst Drive, Boronia, Victoria, Australia 3155, phone number +613 9887 2161.
  • Page 16 Contact the supplier from where the equipment was purchased. If this is not possible, please contact Ratek Instruments either via email to service@ratek.com.au, or phone on +613 9887 2161 during business hours AEST. You may be referred to a local repair agent for service.
