- Page 1 MANUAL Special Documentation Proline Promass 500 Modbus RS485 Web Server Manual SD01918O/06/EN/02.17 Valid as of version 01.01.zz (Device firmware) 71382450...
- Page 2 All information and technical specifications in this documentation have been carefully checked and compiled by the author. However, we cannot completely exclude the possibility of errors. TechnipFMC is always grateful to be informed of any errors. Contact us on the website.
-
Page 3: Table Of Contents
Proline Promass 500 Modbus RS485 Table of contents Table of contents About this document ....4 Document function ..... -
Page 4: About This Document
About this document Proline Promass 500 Modbus RS485 About this document Document function This manual is a Special Documentation; it does not replace the Operating Instructions pertaining to the device. It serves as a reference for using the Web server integrated in the measuring device. -
Page 5: Symbols Used
Proline Promass 500 Modbus RS485 About this document Symbols used 1.4.1 Safety symbols Symbol Meaning DANGER! This symbol alerts you to a dangerous situation. Failure to avoid this situation will DANGER result in serious or fatal injury. WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can WARNING result in serious or fatal injury. -
Page 6: Basic Safety Instructions
Basic safety instructions Proline Promass 500 Modbus RS485 Basic safety instructions Requirements for personnel Personnel involved in installation, commissioning, diagnostics and maintenance must meet the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task ‣... -
Page 7: Security
Proline Promass 500 Modbus RS485 Basic safety instructions It meets general safety standards and legal requirements. It also complies with the EC directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. -
Page 8: Product Features And Availability
Product features and availability Proline Promass 500 Modbus RS485 Product features and availability Product features Thanks to the integrated Web server, the device can be operated and configured via a Web browser and via a service interface (CDI-RJ45) or via a WLAN interface. The structure of the operating menu is the same as for the local display. - Page 9 Proline Promass 500 Modbus RS485 Product features and availability 3.3.2 Proline 500 Service Int. (CDI) IP 192.168.1.212 A0030874 2 Example of the CDI-RJ45 service interface Symbol for service interface Information on the default setting for the WLAN IP address...
-
Page 10: Commissioning
Commissioning Proline Promass 500 Modbus RS485 Commissioning Establishing a connection to the integrated Web server 1. Configure the computer → 10. 2. Check the settings on the measuring device and change them if necessary → 16. 3. Connect the measuring device to the computer → 16. - Page 11 Proline Promass 500 Modbus RS485 Commissioning JavaScript JavaScript must be enabled. If JavaScript cannot be enabled: enter http://192.168.1.212/basic.html in the address line of the Web browser. A fully functional but simplified version of the operating menu structure starts in the Web browser.
- Page 12 Commissioning Proline Promass 500 Modbus RS485 Configuring IP settings for Windows • To configure the IP settings, appropriate user rights (e.g. administrator rights) are required for the computer. • Before configuring the IP settings, close all the windows of the Web browser.
- Page 13 Proline Promass 500 Modbus RS485 Commissioning 6. Right-click to open the picklist and select Properties. The Local Area Connection Properties dialog box opens. A0024300 7. Select the Internet Protocol Version 4 (TCP/IPv4) item.
- Page 14 Commissioning Proline Promass 500 Modbus RS485 8. Click the Properties button. The Internet Protocol Version 4 (TCP/IPv4) Properties window opens. A0024309 9. In the General tab, select the Use the Following IP Address option. 10. Enter the IP address, subnet mask and default gateway as indicated in the following table and then click Ok to confirm.
- Page 15 Proline Promass 500 Modbus RS485 Commissioning Changing the proxy server settings To establish communication, the proxy server setting Use a Proxy Server for Your LAN must be deselected for the Web browser. To change the proxy server setting, appropriate user rights (e.g. administrator rights) are required for the computer.
-
Page 16: Prerequisites - Measuring Device
Commissioning Proline Promass 500 Modbus RS485 4. Under Local Area Network Settings click the LAN Settings button. This opens a new window with the Local Area Network Settings. A0024311 5. Deselect the Use a Proxy Server for Your LAN checkbox and then click Ok to confirm. - Page 17 Proline Promass 500 Modbus RS485 Commissioning 4.3.1 Via service interface (CDI-RJ45) Preparing the measuring device Proline 500 – digital 1. Loosen the 4 fixing screws on the housing cover. 2. Open the housing cover. 3. The location of the connection socket depends on the measuring device and the...
-
Page 18: Establishing A Connection To The Web Server
Commissioning Proline Promass 500 Modbus RS485 4.3.2 Via WLAN interface Configuring the Internet protocol of the mobile terminal NOTICE If the WLAN connection is lost during the configuration, settings made may be lost. ‣ Make sure that the WLAN connection is not disconnected while configuring the device. - Page 19 Proline Promass 500 Modbus RS485 Commissioning The following conditions must be met to connect: • The Web server of the measuring device is enabled → 16. • The IP address of the measuring device is known → 16.
-
Page 20: Setting The Ip Address
Commissioning Proline Promass 500 Modbus RS485 Setting the IP address The IP address of the measuring device is required to establish communication between the measuring device (Web server) and a computer (client). Assign or specify the IP address via: Description The use of the standard IP address •... - Page 21 Proline Promass 500 Modbus RS485 Commissioning IP address (7209) → 21 Subnet mask (7211) → 21 Default gateway (7210) → 21 Web server functionality (7222) → 22 Login page (7273) → 22 Parameter overview with brief description...
- Page 22 Commissioning Proline Promass 500 Modbus RS485 Parameter Description Selection / User interface Factory setting Web server functionality Switch the Web server on and off. • Off • HTML Off • On Login page • Without header With header • With header Visibility depends on order options or device settings...
-
Page 23: Operation Options
Proline Promass 500 Modbus RS485 Operation options Operation options A0031139 3 Example of a Proline flowmeter with an integrated Web server Mobile end device with Web browser (e.g. Internet Explorer) and WLAN interface Computer with Web browser (e.g. Internet Explorer), connection via cable or WLAN interface... -
Page 24: Logging On
Operation options Proline Promass 500 Modbus RS485 Logging on 2 3 4 A0029417 Picture of device Device name Device tag Status signal Current measured values Web server language User role Access code Login Reset access code 1. Select the required operating language for the Web browser (6). -
Page 25: User Interface
Proline Promass 500 Modbus RS485 Operation options User interface A0029418 Function row Local display language Navigation area 5.2.1 Header The following information appears in the header: • Device name • Device tag • Device status with status signal → 28 •... -
Page 26: Logging Out
Operation options Proline Promass 500 Modbus RS485 5.2.3 Navigation area If a function is selected in the function bar, the submenus of the function open in the navigation area. The user can now navigate through the menu structure. 5.2.4 Working area... -
Page 27: Diagnostics And Troubleshooting
Proline Promass 500 Modbus RS485 Diagnostics and troubleshooting Diagnostics and troubleshooting For details on the diagnostic information, see the Operating Instructions for the device → 4. General Web server troubleshooting For access Error Possible causes Solution Not connecting to Web server Web server disabled Using the "FieldCare"... -
Page 28: Diagnostic Information In The Web Browser
Diagnostics and troubleshooting Proline Promass 500 Modbus RS485 Error Possible causes Solution Unsuitable view settings. Change the font size/display ratio of the Web browser. No or incomplete display of • JavaScript not enabled 1. Enable JavaScript. contents in the Web browser •... -
Page 29: Diagnostic Information In The Measuring Device
Proline Promass 500 Modbus RS485 Diagnostics and troubleshooting Symbol Meaning Out of specification The device is operated: Outside its technical specification limits (e.g. outside the process temperature range) Maintenance required Maintenance is required. The measured value is still valid. The status signals are categorized in accordance with VDI/VDE 2650 and NAMUR Recommendation NE 107. - Page 30 Diagnostics and troubleshooting Proline Promass 500 Modbus RS485 4. Enter ping and the IP address, e.g.: ping 192.168.1.212 The network connection status is displayed. Depending on the operating system used, or the version of the operating system, other tools can also be used, such as Powershell.exe, prompt etc.
-
Page 31: Technical Data
Proline Promass 500 Modbus RS485 Technical data Technical data Web server Stack: standard TCP stack with IPv4 functionality Connection and session management • Fixed IP address, i.e. no access possible from outside the network • Open ports: – 80 (HTTP for Web server) –... - Page 32 Otherwise, the manufacturer assumes no responsibility for the use of specifications which may have been changed and are no longer in effect. Contact information is subject to change. For the most current contact information, visit our website at TechnipFMC.com and click on the “Contact Us” link.
