- Page 1 MANUAL Special Documentation Proline Promass 300 EtherNet/IP Web Server SD02129O/06/EN/01.17 Valid as of version 01.00.zz (Device firmware) 71382455...
- Page 2 All information and technical specifications in this documentation have been carefully checked and compiled by the author. However, we cannot completely exclude the possibility of errors. TechnipFMC is always grateful to be informed of any errors. Contact us on the website.
-
Page 3: Table Of Contents
Proline Promass 300 EtherNet/IP Table of contents Table of contents About this document ....4 Document function ..... -
Page 4: About This Document
About this document Proline Promass 300 EtherNet/IP About this document Document function This manual is a Special Documentation; it does not replace the Operating Instructions pertaining to the device. It serves as a reference for using the Web server integrated in the measuring device. -
Page 5: Symbols Used
Proline Promass 300 EtherNet/IP About this document Symbols used 1.4.1 Safety symbols Symbol Meaning DANGER! This symbol alerts you to a dangerous situation. Failure to avoid this situation will DANGER result in serious or fatal injury. WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can WARNING result in serious or fatal injury. -
Page 6: Basic Safety Instructions
Basic safety instructions Proline Promass 300 EtherNet/IP Basic safety instructions Requirements for personnel Personnel involved in installation, commissioning, diagnostics and maintenance must meet the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task ‣... -
Page 7: It Security
Proline Promass 300 EtherNet/IP Basic safety instructions It meets general safety standards and legal requirements. It also complies with the EC directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. -
Page 8: Product Features And Availability
Product features and availability Proline Promass 300 EtherNet/IP Product features and availability Product features Thanks to the integrated Web server, the device can be operated and configured via a Web browser and via a service interface (CDI-RJ45) or via a WLAN interface. The structure of the operating menu is the same as for the local display. -
Page 9: Commissioning
Proline Promass 300 EtherNet/IP Commissioning Commissioning Establishing a connection to the integrated Web server 1. Configure the computer → 9. 2. Check the settings on the measuring device and change them if necessary → 15. 3. Connect the measuring device to the computer . - Page 10 Commissioning Proline Promass 300 EtherNet/IP JavaScript JavaScript must be enabled. If JavaScript cannot be enabled: enter http://192.168.1.212/basic.html in the address line of the Web browser. A fully functional but simplified version of the operating menu structure starts in the Web browser.
- Page 11 Proline Promass 300 EtherNet/IP Commissioning Configuring IP settings for Windows • To configure the IP settings, appropriate user rights (e.g. administrator rights) are required for the computer. • Before configuring the IP settings, close all the windows of the Web browser.
- Page 12 Commissioning Proline Promass 300 EtherNet/IP 6. Right-click to open the picklist and select Properties. The Local Area Connection Properties dialog box opens. A0024300 7. Select the Internet Protocol Version 4 (TCP/IPv4) item.
- Page 13 Proline Promass 300 EtherNet/IP Commissioning 8. Click the Properties button. The Internet Protocol Version 4 (TCP/IPv4) Properties window opens. A0024309 9. In the General tab, select the Use the Following IP Address option. 10. Enter the IP address, subnet mask and default gateway as indicated in the following table and then click Ok to confirm.
- Page 14 Commissioning Proline Promass 300 EtherNet/IP Changing the proxy server settings To establish communication, the proxy server setting Use a Proxy Server for Your LAN must be deselected for the Web browser. To change the proxy server setting, appropriate user rights (e.g. administrator rights) are required for the computer.
-
Page 15: Prerequisites - Measuring Device
Proline Promass 300 EtherNet/IP Commissioning 4. Under Local Area Network Settings click the LAN Settings button. This opens a new window with the Local Area Network Settings. A0024311 5. Deselect the Use a Proxy Server for Your LAN checkbox and then click Ok to confirm. -
Page 16: Connecting The Computer To The Measuring Device
Commissioning Proline Promass 300 EtherNet/IP IP address Determine IP address settings via parameters or DIP switches assigned or Local display Operating tool e.g. DIP switches in specified via: (if available) FieldCare, DeviceCare, electronics compartment AMS Device Manager, SIMATIC PDM Dynamic Host... - Page 17 Proline Promass 300 EtherNet/IP Commissioning Configuring the Internet protocol of the computer NOTICE Risk of electric shock! Components carry dangerous voltages! ‣ Never open the measuring device while it is connected to the supply voltage. ‣ The information and safety instructions in the Operating Instructions pertaining to the measuring device must always be observed →...
- Page 18 Commissioning Proline Promass 300 EtherNet/IP NOTICE In principle, avoid simultaneous access to the measuring device via the service interface (CDI-RJ45) and the WLAN interface from the same mobile terminal. This could cause a network conflict. ‣ Only activate one service interface (CDI-RJ45 service interface or WLAN interface).
-
Page 19: Establishing A Connection To The Web Server
Proline Promass 300 EtherNet/IP Commissioning 4.3.3 Via Ethernet-based fieldbus If the IP address of the measuring device is assigned via hardware or software addressing, the network connection can be established directly via the Ethernet network. The device is configured at the factory to work with the Dynamic Host Configuration Protocol (DHCP), i.e. - Page 20 Commissioning Proline Promass 300 EtherNet/IP 4.4.2 Starting the Web browser If JavaScript cannot be enabled: enter http://192.168.1.212/basic.html in the address line of the Web browser. A fully functional but simplified version of the operating menu structure starts in the Web browser.
-
Page 21: Setting The Ip Address
Proline Promass 300 EtherNet/IP Commissioning Setting the IP address The IP address of the measuring device is required to establish communication between the measuring device (Web server) and a computer (client). There are various options to assign or specify the IP address depending on the hardware and software settings. - Page 22 Commissioning Proline Promass 300 EtherNet/IP Parameter overview with brief description Parameter Description Selection Factory setting Web server language Set web server language. • English English • Deutsch • Français • Español • Italiano • Nederlands • Portuguesa • Polski • русский язык (Russian) •...
- Page 23 Proline Promass 300 EtherNet/IP Commissioning Capability flags (7439) User description (7432) Parameter overview with brief description Parameter Description Selection / User interface / Factory setting User entry Web server language Set web server language. • English English • Deutsch • Français • Español •...
-
Page 24: Operation Options
Operation options Proline Promass 300 EtherNet/IP Operation options A0031139 3 Example of a Proline flowmeter with an integrated Web server Mobile end device with Web browser (e.g. Internet Explorer) and WLAN interface Computer with Web browser (e.g. Internet Explorer), connection via cable or WLAN interface... -
Page 25: Logging On
Proline Promass 300 EtherNet/IP Operation options Logging on 2 3 4 A0029417 Picture of device Device name Device tag Status signal Current measured values Web server language User role Access code Login Reset access code 1. Select the required operating language for the Web browser (6). -
Page 26: User Interface
Operation options Proline Promass 300 EtherNet/IP User interface A0029418 Function row Local display language Navigation area 5.2.1 Header The following information appears in the header: • Device name • Device tag • Device status with status signal → 32 •... -
Page 27: Logging Out
Proline Promass 300 EtherNet/IP Operation options 5.2.3 Navigation area If a function is selected in the function bar, the submenus of the function open in the navigation area. The user can now navigate through the menu structure. 5.2.4 Working area... - Page 28 Operation options Proline Promass 300 EtherNet/IP Addressing mode ex Software addressing; all DIP switches for hardware addressing are set to OFF. works IP address ex works DHCP server active Software addressing: The IP address is entered via the IP address parameter (→...
- Page 29 Proline Promass 300 EtherNet/IP Operation options A0034499 1. Depending on the housing version, loosen the securing clamp or fixing screw of the housing cover. 2. Depending on the housing version, unscrew or open the housing cover and disconnect the local display from the main electronics module where necessary .
-
Page 30: Diagnostics And Troubleshooting
Diagnostics and troubleshooting Proline Promass 300 EtherNet/IP Diagnostics and troubleshooting For details on the diagnostic information, see the Operating Instructions for the device → 4. General Web server troubleshooting For access Error Possible causes Solution Not connecting to Web server Web server disabled Using the "FieldCare"... -
Page 31: Diagnostic Information In The Web Browser
Proline Promass 300 EtherNet/IP Diagnostics and troubleshooting Error Possible causes Solution WLAN communication disabled – Not connecting to Web server, No WLAN network available • Check if WLAN reception is FieldCare or DeviceCare present: LED on display module is lit blue •... - Page 32 Diagnostics and troubleshooting Proline Promass 300 EtherNet/IP A0031056 Status area with status signal Diagnostic information Remedy information with Service ID In addition, diagnostic events which have occurred can be shown in the Diagnostics menu: • Via parameter • Via submenu...
-
Page 33: Diagnostic Information In The Measuring Device
Proline Promass 300 EtherNet/IP Diagnostics and troubleshooting Diagnostic information in the measuring device 6.3.1 Overview of Web server information events Unlike a diagnostic event, an information event is displayed in the event logbook only and not in the diagnostic list. -
Page 34: Technical Data
Technical data Proline Promass 300 EtherNet/IP Technical data Web server Stack: standard TCP stack with IPv4 functionality Connection and session management • Open ports: – 80 (HTTP for Web server) – 8000 (for Endress+Hauser Service communication) • Only one connection possible at any one time via Hypertext Transfer Protocol (HTTP) •... - Page 36 Otherwise, the manufacturer assumes no responsibility for the use of specifications which may have been changed and are no longer in effect. Contact information is subject to change. For the most current contact information, visit our website at TechnipFMC.com and click on the “Contact Us” link.
