DEI 150ESP Owner's Manual

Remote start keyless entry system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model 150ESP
Owner's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 150ESP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEI 150ESP

Summary of Contents for DEI 150ESP

  • Page 1 Model 150ESP Owner's Guide...

  • Page 2: Limited Lifetime Consumer Warranty

    The warranty does not cover damage to the unit caused by installation or removal of the unit. DEI, in its sole discretion, will determine what constitutes excessive damage and may refuse the return of any unit with excessive damage.
  • Page 3 DEI does not and has not authorized any person or entity to create for it any other obligation, promise, duty or obligation in connection with this security system.

  • Page 4: Table Of Contents

    Table of Contents Limited Lifetime Consumer Warranty ....... . i What Is Included .

  • Page 5: Standard Configuration

    Standard Configuration controls the Arm function. controls the Disarm function. controls Silent Mode™and an Auxiliary Output. controls the Panic function. pressed simultaneously control Remote Start. 2000 Directed Electronics, Inc. ©...

  • Page 6: What Is Included

    By carefully reading this Owner's Guide prior to using your system, you will maximize the use of this system and its features. You can print additional or replacement copies of this manual by accessing the DEI ® internet website at www.directed.com.

  • Page 7: System Maintenance

    System Maintenance The system requires no specific maintenance. Your remote is powered by a small, lightweight 3-volt lithium battery that will last approx- imately one year under normal use. When the battery begins to weaken, operating range will be reduced and the LED on the remote will dim. Your Warranty Your warranty registration must be completely filled out and returned within 10 days of purchase.

  • Page 8: Transmitter Functions

    Transmitter Functions The receiver uses a computer-based learn routine to learn the transmitter buttons. This makes it possible to assign any specific transmitter button, or combination of buttons, to any receiver function. The transmitter initially comes programmed with the Standard Configuration, but may also be customized by an autho- rized dealer.

  • Page 9: Using Your System

    The following safety warnings must be observed at all times: Due to the complexity of this system, installation of this product must only be performed by an authorized DEI dealer. When properly installed, this system can start the vehicle via a command signal from the remote control transmitter.
  • Page 10 This testing should be performed by an authorized DEI dealer in accordance with the Safety Check outlined in the product installation guide.

  • Page 11: Locking/Arming

    PERSONAL INJURY. YOU MUST IMMEDIATELY CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AUTHORIZED DEI DEALER TO REPAIR OR DISCONNECT THE INSTALLED REMOTE START MODULE. DEI WILL NOT BE HELD RESPONSI- BLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS. Locking/Arming...

  • Page 12: Unlocking/Disarming

    NOTE: For Passive Mode to be effective, the Failsafe must be installed. Unlocking/Disarming Pressing for one second disarms the system and unlocks the doors (if connected). The horn will honk twice (if connected) and the parking lights will flash twice to confirm disarming of the sys- tem.

  • Page 13: Valet Mode

    Valet ® Mode You can prevent your system from automatically activating the Failsafe ® Starter Kill and locking the doors by using Valet This is very useful when washing the vehicle or having it serviced. In Valet ® Mode, the starter kill cannot be activated, even with the transmitter, but all convenience functions (door locks, remote start, etc.) will continue to work normally.

  • Page 14: Remote Start

    Remote Start This feature allows you to remotely start and run your vehicle for a programmable period of time. This makes it possible to warm up the engine, as well as adjust the interior temperature of the vehi- cle with the climate control system. If interior heating or cooling is desired, the climate controls must be preset, and the fan blower must be set to the desired level prior to remote starting the vehicle.

  • Page 15: Valet Take-Over

    When you are ready to drive the vehicle: 1. Insert the ignition key and turn it to the ON (not the START) position. 2. Press the brake pedal. NOTE: If the brake pedal is pressed before the key is in the ON position, the engine will shut down.

  • Page 16: Timer Mode

    To perform Valet ® Take-Over: Before turning off the engine, press and release on the transmitter (or press and release the optional momen- tary switch). Turn the ignition key to the OFF position. (The engine will stay running.) The engine will run until the pre-programmed time elapses or a shut-down input is received.

  • Page 17: Starter Anti-Grind Circuitry

    The engine may be allowed to run for its pre-programmed time period, or it can be shut down while running during Timer Mode operation by pressing Buttons the vehicle will restart every three hours for a total of six opera- tion cycles.

  • Page 18: Disabling The Remote Start System

    Check with your installer for recommended locations. LOCATION OF SHUTDOWN SWITCH_________________________ Rapid Resume Logic This DEI ® system will store its current state to non-volatile memory. If power is lost and then reconnected the system will recall the stored state from memory.

  • Page 19: Programming Options

    Programming Options Programming options control your system's normal, operational set-up. Most options do not require additional parts, but some may require additional installation labor. This system's programming options are listed below, with the factory default settings in bold: 12, 24, or 60 minute run time. Your system can be pro- grammed to allow the vehicle to run for 12, 24, or 60 min- utes when remote started or in Timer Mode.

  • Page 20: Glossary Of Terms

    Glossary of Terms Control Unit: The “brain” of your system. Usually hidden under- neath the dash area of the vehicle. It houses the microprocessor which monitors your vehicle and controls all system functions. Failsafe ® Starter Kill: An automatic switch controlled by your sys- tem which prevents the vehicle’s starter from cranking whenever the system is armed.

  • Page 21: Convenience Expansions

    Power Trunk Release: The system’s auxiliary output can be pro- grammed to operate a factory power release for the vehicle's trunk or hatch. If the factory release is not power-activated, DEI ® 's 522T trunk-release solenoid can often be added.
  • Page 22 dows automatically when the system is armed, or roll two win- dows down by using the transmitter. The 530T will roll two win- dows both up and down. The 530T also provides one touch switch operation. Progressive Door Unlocking: For added security, your system can be configured to unlock the driver’s door only, leaving the pas- senger doors locked.
  • Page 23 Notes 2000 Directed Electronics, Inc. ©...

  • Page 24: Quick Reference Guide

    QUICK REFERENCE GUIDE: To lock/arm using your remote s To arm the system press nected). The LED will begin to flash. The Failsafe vent the vehicle’s starter from cranking if it has been installed. The ve- hicle’s horn (if connected) will honk and the parking lights will flash once to confirm arming of the system.
  • Page 25 The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, DEI is ISO 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world.
