- Page 1 Avital 3100 Owner's Guide...
-
Page 2: Limited Lifetime Consumer Warranty
This warranty contains the entire agreement relating to warranty and supersedes all previous and contemporaneous representations or understandings, whether written or oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS CONTENTS. This warranty is void if the product has been damaged by accident, unreasonable use, neglect, improper service or other causes not arising out of defects in materials or construction. - Page 3 TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD- ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM- MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU- SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR- RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD.
-
Page 4: Table Of Contents
Table of Contents Limited Lifetime Consumer Warranty What Is Included ..........3 Important Information . -
Page 5: Standard Configuration
Standard Configuration 2000 Directed Electronics, Inc. ©... -
Page 6: What Is Included
What is Included The control module 2 two-button transmitters A push-button programming switch Your warranty card A shut-down toggle switch Important Information Congratulations on the purchase of your remote start keyless entry system. This system has been designed to provide years of trouble- free operation. -
Page 7: Your Warranty
Your Warranty Your warranty card must be completely filled out and returned within 10 days of purchase. Your product warranty will not be honored if your warranty card is not returned. Make sure that you receive the warranty card from your dealer. FCC/ID Notice This device complies with Part 15 of FCC rules. -
Page 8: Transmitter Functions
Transmitter Functions The receiver uses a computer-based learn routine to learn the transmitter buttons. This makes it possible to assign any specific transmitter button, or combination of buttons, to any receiver function. The transmitter initially comes programmed with the Standard Configuration, but may also be customized by an autho- rized dealer. -
Page 9: Using Your System
The following safety warnings must be observed at all times: Due to the complexity of this system, installation of this product must only be performed by an authorized DEI dealer. When properly installed, this system can start the vehicle via a command signal from the remote control transmitter. - Page 10 This testing should be performed by an authorized DEI dealer in accordance with the Safety Check outlined in the product installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the authorized DEI dealer to fix the problem.
-
Page 11: Locking
Locking Pressing for one second will lock the doors. The parking lights will flash once to confirm that the doors are locked. NOTE: Power door lock control is an optional feature. Extra parts and labor may be necessary for your system to interface with your vehicle’s power door locks. -
Page 12: Remote Start
Remote Start This feature allows you to remotely start and run your vehicle for a programmable period of time. This makes it possible to warm up the engine, as well as adjust the interior temperature of the vehi- cle with the climate control system. If interior heating or cooling is desired, the climate controls must be preset, and the fan blower must be set to the desired level prior to remote starting the vehicle. -
Page 13: Timer Mode
While the vehicle is running during remote start operation, the system will monitor the vehicle and will automatically shut down the engine if the system receives any of the following shut-down inputs: The brake pedal is pressed. The hood is opened. The shutdown toggle switch is put into the ON position. -
Page 14: Valet Take-Over
The engine will shut down and the parking lights will flash four times. The engine will then restart to confirm that Timer Mode has been entered. The engine may be allowed to run for its preset time or can be shut down by pressing Buttons it will restart every three hours for a total of six cycles. -
Page 15: Using Remote Start With Factory Remote Systems
To perform Valet Take-Over: Before turning off the engine, press and release on the transmitter (or press and release the optional Mo- mentary switch). Turn the ignition key to the OFF position. (The engine will stay running.) The engine will run until the pre-programmed time elapses or a shut-down input is received. -
Page 16: Programming Options
Programming Options Programming options control your system's normal, operational set-up. Most options do not require additional parts, but some may require installation labor. The following is a list of the programmable options, with the factory settings in Bold. 12, 24, or 60 minute run time. Your system can be pro- grammed to allow the vehicle to run for 12, 24, or 60 minutes when remote started. -
Page 17: Quick Reference Guide
QUICK REFERENCE GUIDE: To lock the doors using your remote Pressing for one second will lock the doors. The parking lights will flash once to confirm the doors are locked. NOTE: Control of power door locks is optional. Extra parts and labor may be necessary to interface with power door locks. - Page 18 Since its inception, DEI® has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered.
