M M E E N N U U ( ( C C O O N N S S O O L L E E M M E E N N U U ) )
Press "MENU" button on the monitor or remote to activate the screen parameters set-up. The
sequence of set-up items is as follows:
FM →
FM: Transmitting frequency
BRIGHTNESS: Brightness adjustment
SATURATION: Color saturation adj.
RESET: Resets above (except FM) to factory default settings.
Once the desired setting is selected, press the cursor buttons to adjust the setting. On the remote
use the up/down cursor buttons located at either side of the menu button. On the monitor use the
cursor buttons to the right side of the
this function mode will turn OFF. Once the correct function is selected, press the cursor button (to
set the desired setting). If no button is pressed, the menu mode will turn OFF in about 5 seconds.
The FM frequency setting allows the monitor to transmit audio to the vehicle's radio. Use a frequency
that is not interfered with from a local broadcast station. This setting also has an OFF position.
D D O O O O R R L L I I G G H H T T O O N N / / O O F F F F
Engage this switch
N N O O T T E E : : This function is operational only when the Gray wire of the dome light cir-
cuit is connected to the door switch.
C C O O U U R R T T E E S S Y Y L L I I G G H H T T O O N N / / O O F F F F
Activate this switch
22
SHARPNESS → BRIGHTNESS
SATURATION
button. If a button is not activated within 5 seconds,
on the monitor to activate the dome lights when a door is open.
on the monitor to control the dome light illumination.
→ CONTRAST →
→ HUE → RESET
SHARPNESS: Sharpness adjustment
CONTRAST: Contrast adjustment
HUE: Color hue adjustment
