O O p p e e r r a a t t i i n n g g t t h h e e M M o o n n i i t t o o r r
O O P P E E N N / / C C L L O O S S E E T T H H E E D D I I S S P P L L A A Y Y M M O O N N I I T T O O R R
To open the display monitor, push the "OPEN" button and pull the monitor down b b y y t t h h e e m m i i d d d d l l e e of the
LCD to the desired position. Use the m m i i d d d d l l e e o o f f t t h h e e LCD screen to rotate to a desired viewing position.
Clos ed Pos ition
To close the display monitor, first rotate the LCD screen to align for closure and then push the LCD
screen up until it latches closed with an audible click.
N N o o t t e e : : The ignition key must be in the Accessory or Ignition position in order for
the monitor to have power.
20
W W A A R R N N I I N N G G : : THE LCD MONITOR MUST ALWAYS BE OPENED, CLOSED, OR POSITIONED FROM
THE MIDDLE OF THE SCREEN AS SHOWN BY THE POINTING HAND BELOW. DO N N O O T T USE THE
CORNERS OF THE SCREEN, THIS CAN RESULT IN DAMAGE/LEAKAGE OF THE SCREEN.
Open Button
Use this portion of the
screen for opening, closing,
and positioning.
W W A A R R N N I I N N G G : : DO NOT CLOSE THE LCD SCREEN IF A MEMORY CARD HAS BEEN INSERTED INTO
THE DVD PLAYER. THIS CAN CAUSE THE LCD SCREEN TO BREAK OR LEAK FLUID. IF YOU
SHOULD COME IN CONTACT WITH LEAKED FLUID, WASH THE AFFECTED AREA THOROUGHLY
WITH WATER AND SEEK IMMEDIATE MEDICAL ATTENTION. REMOVE ALL MEMORY CARDS
BEFORE CLOSING THE LCD SCREEN.
Open Pos ition
© 2005 Directed Electronics, Inc.
