1.Introduction
Dear Rocky Mountain Radar Owner,
Congratulations on your purchase of one of the world's most sophisticated radar/laser
detectors. The RMR-D550 is a completely integrated radar/laser detector which responds not
only to all the radar guns in use today, including "Stalker", but also to the other latest
development in speed monitoring devices- the laser gun.
This model provides distinct visual and voice alerts to warn you of the presence of X, K,
and all kinds of Ka Band radar guns in the front and rear of you.
It also incorporates a new safety feature – Safety Alert(SA) and Safety Warning System(SWS).
This safety feature warns you of the presence of potential road hazards
by detecting signals from safety radar transmitting devices.
Note:
Important : The RMR-D550 is not designed to help you disobey the law. A defensive
driver always obeys the posted speed limit and legal driving methods.
Federal and Local Regulations
The FCC passed the Communications Act in 1934 to give all citizens the right to receive all
types of radio transmissions. The same radio frequencies used by police radar are also used by
other devices, such as automatic door openers, burglar alarms, and some amateur radio
equipment. Since the RMR-D550 is just a radio receiver tuned to a specific portion of the public
radio spectrum, it is protected under this act.
Some local, state, and federal regulations may prohibit the use of this detection device.
Please check with authorities regarding the use of this device before operating it.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rocky Mountain RMR-D550
Summary of Contents for Rocky Mountain RMR-D550
- Page 1 The same radio frequencies used by police radar are also used by other devices, such as automatic door openers, burglar alarms, and some amateur radio equipment. Since the RMR-D550 is just a radio receiver tuned to a specific portion of the public radio spectrum, it is protected under this act.
- Page 2 2. Control and Features 1) Included with your Radar Detector RMR-D550 Windshield Bracket with Suction Cups Hook and Loops Fastener Tape Power Cord Spare Fuse...
-
Page 3: Controls And Functions
2) Controls and Functions a. Power On/Off Button b. Volume up and down button c. DC 12V Power Input Jack d. Dim Button e. Mute Button City Button g. Rear Laser Detection Lens : Receives incoming laser signals from rear h. -
Page 4: Mounting Types
3. Installation 1) Mounting Guidelines For the best performance, select the proper location for the unit where it has a direct view of the road. The radar antenna is located behind the rear panel of the unit and the laser detection lenses are located behind the rear panel of the unit and the front window. -
Page 5: Power Connection
A. On Windshield a. Attach bracket to windshield. b. Bend bracket for correct detection angle. c. Plug Power cord into detector. d. Attach bracket to detector. e. Plug power cord into cigarette lighter. B. On Dashboard a. Peel protective paper off one side of hook-loop. b. -
Page 6: Replacing Fuse
Remove and check the fuse to see if it has blown, if it has, replace it. 4. Operation 1) Power On and Self - Test Press the Power button. The RMR-D550 goes through an automatic self-test sequence. 2) Volume Level Adjustment Press Volume up button to increase volume level. -
Page 7: City / Highway Mode
→ A voice sound will alert you that Dim mode has been activated. Each time you press Dim button, display intensity will change Dim, Dimmer, Dark, Bright. (Note : The RMR-D550 cannot activate Mute and Dark at same time. If the MUTE is engaged, the DARK cannot activate.) →... -
Page 8: Mute Mode
Press Mute Button. Mute On→ Silences the tone sound. Note : Press Mute button again to restore tone sound. 6) Select Tone Hold down the Mute button for three seconds. The RMR-D550 will change tone sound. 7) Indicator and Visual... - Page 9 a. Power On “P” LED turns on. b. X Band Detection “X” LED turns on with voice sound. c. K/Ka Band Detection “K/Ka” LED turns on with voice sound. d. Laser Alarm “2, 3, 4, L” LEDs flash with voice sound. 8) Language Selection(English and Spanish Modes)
-
Page 10: Feature Memory
Factory default is “English Mode”. 9) Feature Memory The RMR-D550 will automatically “Remember” your settings when the unit is turned off or removed from the power. All features selected are retained in memory. Bright – Dim – Dimmer - Dark Audio Tone Highway - City 1 –... - Page 11 Replacement owner’s manual ………………………… $ 3.50 Add $10.00 shipping and handling per shipment CAUTION Tampering with unit will result in a $ 75.00 repair fee! WE DO NOT ACCEPT COD SHIPMENT ROCKY MOUNTAIN RADAR 6469 DONIPHAN DRIVE EL PASO, TX 79932 915.587.0307 915.587.6408(FAX)
-
Page 12: Troubleshooting
Your Rocky Mountain radar detector is an example of superior design and craftsmanship. The following suggestions will help you care for your detector so you can enjoy it for years. Never leave your detector on the windshield or dashboard when your vehicle is left parked. -
Page 13: Specification
Radar antenna/laser sensor is obstructed. (Relocate the detector clear of any obstruction outside the windshield, such as a wiper blade.) Relocate the detector clear of the window tint. 7. Specification RADAR Receiver Type : Triple conversion Superheterodyne Antenna Type : Linear polarized, Self-Contained Antenna Detector Type : Scanning Frequency Discriminator Frequency of Operation : 10.525GHz/±... -
Page 14: Fcc Information
This unit guaranteed against defects in workmanship and materials for one year. Should you experience any difficulty with the RMR-D550 during this time, the unit will be repaired or replaced at no charge. Should you desire to have your unit checked, there will be no additional charge other than postage and handling.
