- Page 1 KPCMCIA-RS232S Single Channel Asynchronous Serial Adapter User’s Manual A G R E A T E R M E A S U R E O F C O N F I D E N C E...
- Page 2 Upon receiving notification of a defect in the Keithley Hardware during the warranty period, Keithley will, at its option, either repair or replace such Keithley Hard- ware. During the first ninety days of the warranty period, Keithley will, at its option, supply the necessary on site labor to return the product to the condition prior to the notification of a defect.
- Page 3 KPCMCIA-RS232S Single Channel Asynchronous Serial Adapter User’s Manual ©1997, Keithley Instruments, Inc. All rights reserved. Cleveland, Ohio, U.S.A. Third Printing, January 2000 Document Number: 98931 Rev. C...
- Page 4 Revision B (Document Number 98931) ..................December 1997 Revision C (Document Number 98931) ..................... January 2000 All Keithley product names are trademarks or registered trademarks of Keithley Instruments, Inc. Other brand and product names are trademarks or registered trademarks of their respective holders.
- Page 5 Keithley products are designed for use with electrical signals that The instrument and accessories must be used in accordance with its are rated Installation Category I and Installation Category II, as de- specifications and operating instructions or the safety of the equip-...
- Page 6 Keithley Instru- symbol on an instrument indicates that the user should re- ments. Standard fuses, with applicable national safety approvals, fer to the operating instructions located in the manual.
-
Page 7: Table Of Contents
Table of Contents Introduction Getting started ..............................1-2 Technical support ............................... 1-2 Installation Introduction ................................ 2-2 Hardware installation ............................2-2 Software setup ..............................2-2 External Connections Specifications... - Page 8 List of Illustrations External Connections Figure 3-1 Adapter cable ..............................3-2 Figure 3-2 RS-232 signal assignment ..........................3-2...
-
Page 9: Introduction
Introduction... -
Page 10: Getting Started
KPCMCIA-RS232S User’s Manual Getting started The Keithley KPCMCIA-RS232S is a single channel RS-232 asynchronous serial adapter for systems equipped with PCMCIA Type II and/or Type III expansion sockets. The KPCMCIA- RS232S is a PCMCIA Type II (5mm) card and is PCMCIA PC card standard specification 2.1 compliant. -
Page 11: Installation
Installation... -
Page 12: Introduction
Installation KPCMCIA-RS232S User’s Manual Introduction A Windows 95 INF configuration file has been written for the KPCMCIA-RS232S hardware. Hardware installation To physically install the KPCMCIA- RS232S PC card, insert the card into an available Type II KPCMCIA socket. Software setup Refer to your DriverLINX documentation for a detailed description of the software installation and setup procedures. -
Page 13: External Connections
External Connections... - Page 14 External Connections KPCMCIA-RS232S User’s Manual An adapter cable is included with the KPCMCIA-RS232S to convert the 9-pin PCMCIA output connector into a standard D-9 male connector, data terminal equipment (DTE), as shown in Figures 3-1 and 3-2. A male to female gender changer is provided for your convenience.
- Page 15 Specifications...
- Page 16 Specifications KPCMCIA-RS232S User’s Manual Bus interface PCMCIA PC card standard 2.1 compliant Physical dimensions Type II PCMCIA card (5mm) Maximum baud rate 120K Power requirements +5 volts 18.85mA (typical) 25.95mA (maximum) Connector Adapter to standard male D-9 with female to female gender changer...
- Page 17 Index External connections 3-1 Introduction 1-1, 2-2 Software setup 2-2 Getting started 1-2 Specifications A-1 Hardware installation 2-2 Technical support 1-2...
- Page 18 Specifications are subject to change without notice. All Keithley trademarks and trade names are the property of Keithley Instruments, Inc. All other trademarks and trade names are the property of their respective companies. Keithley Instruments, Inc. 28775 Aurora Road • Cleveland, Ohio 44139 • 440-248-0400 • Fax: 440-248-6168 1-888-KEITHLEY (534-8453) •...
