Summary of Contents for Panasonic SC-HC302
- Page 1 Operating Instructions Compact Stereo System SC-HC302 Model No. SC-HC300 This illustration shows SC-HC302. Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Please keep this manual for future reference. TQBJ2074-1...
-
Page 2: Table Of Contents
Indicate features applicable to SC-HC302. [HC300]: Indicate features applicable to SC-HC300. WARNING! Unless otherwise indicated, illustrations in these operating instructions are of SC-HC302. Your system and the illustrations can look differently. Unit • To reduce the risk of fire, electric shock or product damage, –... -
Page 3: Note On Ac Mains Lead
Note on AC mains lead Supplied accessories (For the AC mains plug of three pins) Check and identify the supplied accessories. For your safety, please read the following text carefully. [HC302] Before use 1 AC mains lead Remove the connector cover. ... -
Page 4: Making The Connections
Connect the AC mains lead. Making the connections To household mains socket Connect the AC mains lead only after all the other connections have been made. Do not use any other AC mains lead except the [HC302] [HC300] supplied one. Conserving power The system consumes a small amount of power (~17) even when it is in standby mode. -
Page 5: Overview Of Controls
Overview of controls Do the procedures with the remote control. You can also use the buttons on the main unit if they are the same. Top view Standby/on switch [`], [1] Mute the sound Press to switch the unit from on to standby mode or To cancel, press the button again. -
Page 6: Preparing The Media
The device connects with this system automatically after pairing is complete. The MAC address (example: 6C:5A:B5:B3:1D:0F) USB device may be shown before “SC-HC302” or “SC-HC300” is (not supplied) shown. The name of the connected device is shown for a few seconds. -
Page 7: Media Playback
█ Disconnecting a device Media playback Press [ ] to select “BLUETOOTH”. The following marks indicate the availability of the feature. Press [PLAY MENU] repeatedly to select CD-R/RW in CD-DA format or with MP3 files. “DISCONNECT?”. USB device with MP3 files. Press [R, T] to select “OK? YES”... - Page 8 █ Note on disc Play menu • This system can play CD-R/RW with CD-DA or MP3 format content. CD USB • This system can access up to: Press [PLAY MENU] repeatedly to select – CD-DA: 99 tracks • Before playback, finalise the disc on the device it was “PLAYMODE”...
-
Page 9: Radio
█ Selecting a preset station Radio Press [PLAY MENU] repeatedly to select “TUNE MODE”. Press [RADIO/AUX] to select “FM”. Press [R, T] to select “PRESET” and then press Manual tuning [OK]. Press [2/3] or [5/6] to select the preset Press [PLAY MENU] repeatedly to select station. -
Page 10: Dab/Dab
Secondary service DAB/DAB+ You can listen to secondary services when “ ” is shown. [HC302] Press [PLAY MENU] repeatedly to select Preparation “DAB SECONDARY”. Press [RADIO/AUX] to select “DAB+”. Press [R, T] to select the secondary service and Note: then press [OK]. If you select “DAB+”... -
Page 11: Clock And Timers
• • “ ” “ ” “ ” “ ” “ ” The sleep timer always comes first. Be sure not to set an DAB+ SC-HC302 ) and can be set as the music source. overlap of timers. -
Page 12: Sound Effects
Sound effects External music device You can play music from an external music device. Press [SOUND] repeatedly to select the sound effect. Preparation • Switch off the equaliser (if any) of the external music Press [R, T] to select the setting and then press device to prevent sound distortion. -
Page 13: Others
Software update Others Occasionally, Panasonic may release updated software for this unit that may add or improve the way a feature Auto off operates. These updates are available free of charge. For more details, refer to the following website. http://panasonic.jp/support/global/cs/ This system automatically switches off when you do not (This site is in English only.) -
Page 14: Troubleshooting
• Switch off the system, determine and correct the cause, and audio output to “SC-HC302” or “SC-HC300” manually. Read then switch on again. It can be caused by straining of the the operating instructions of the device for details. - Page 15 █ Main unit displays “REMOTE 1” “REMOTE 2” “--:--” • The remote control and the main unit are using different • You connected the AC mains lead for the first time or there codes. Change the code of the remote control. was a power failure recently.
-
Page 16: Maintenance
Remote control code System memory reset When other Panasonic equipment responds to the remote Reset the memory when the following situations occur: control of this system, change the remote control code for • There is no response when buttons are pressed. -
Page 17: Specifications
Specifications █ General █ USB section USB port power DC OUT 5 V 1.5 A Power supply [HC302] AC 220 V to 240 V, 50 Hz USB standard USB 2.0 full speed [HC300] AC 110 V to 240 V, 50/60 Hz Media file format support MP3 (*.mp3) Power consumption... -
Page 18: References
– Taking apart or modifying the unit. trademarks owned by the Bluetooth SIG, Inc. and any – Removing specification indications. use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of Restrictions of use their respective owners. -
Page 19: Limited Warranty (For Australia Only)
Distributors, or Dealers, and only where the products are used and serviced within Australia or its territories. Warranty cover only applies to the services that are carried out by a Panasonic Authorised Service Centre and only if valid proof of purchase is presented when the warranty service is requested. - Page 20 Panasonic Corporation Web Site: http://www.panasonic.com TQBJ2074-1 L0218YS2038 © Panasonic Corporation 2018...
