- Page 1 AMN39203 (Maglan) User/Installer Manual An AMIMON Inc. Document Copyright 2014 Version 1.0...
-
Page 2: Important Notice
AMIMON does not warrant or represent that any license, either express or implied, is granted under any AMIMON patent right, copyright, mask work right, or other AMIMON intellectual property right relating to any combination, machine, or process in which AMIMON products or services are used. -
Page 3: Revision History
Revision History Version Date Description June 29,2014 Initial Release... -
Page 4: Table Of Contents
Table of Contents ............Important Notice ............Revision History ............Table of Contents ............Safety Instructions ............... Introduction Front view ......................7 Back view .......................7 LED behaviors ..................Interface Connector (J32) ............................ FCC Caution... -
Page 5: Safety Instructions
Do not open unit. Do not block the air ventilation openings. Use only accessories specified or recommended by Amimon. When devices are switched on keep away at least 20 cm from your body. Do not expose to moisture or excessive heat. -
Page 6: Introduction
Introduction The AMN39203 is wireless A/V receiver board, which works at the 5GHz unlicensed band. It is are based on AMIMON's WHDI Professional chipset that consist of the AMN2220 baseband receiver and the MAXIM 2851 ICs, presents the ultimate solution for HDMI receiver of the WHDI system. -
Page 7: Front View
PRODUCT DESCRIPTION Front view Figure 1 –Rx AMN39203 top-side Back view J32: Interface connector Figure 2 – Rx AMN39203 bottom side... -
Page 8: Led Behaviors
LED behaviors Network LED BLINKING MODE DESCRIPTION Solid When a connection to Tx is established*/Link quality is good Slow Device is in listen mode/Link quality is reasonably good Normal During link setup mode/during registration Fast System Error (Video LED flashing as well)/Link quality is poor *In Aerial mode even when Tx is out of range. -
Page 9: Interface Connector (J32)
Interface Connector (J32) The Interface connector J32 provides various interfaces to communicate with the AMN39203 MCU to configure video related parameters and settings, or receive the network status and communication related parameters. The following interface options are available: External Power Supply voltage (5VDC ±10%) - Page 10 PRODUCT INSTALLATION The AMN39203 is referred as the main platform that comprises a wireless Video Display Unit (VDU). It provides RGB video signal bus and I2S audio interface at its interface connector output. The source of the video and audio is a compatible remote wireless Video Source Device (VSU). At common application, the VSU is connected to a video source, and transmits the video over wireless to the VDU, which is connected to the video monitor.
- Page 11 SYSTEM SETUP See ‘Product Description’ for port location described in this section. Connect the Amimon-AMN39203 receiver to compatible Video Interface Board (VIB). Connect the VIB to a video monitor through the supported video interface of the VIB. Power ON the VIB according to its operating manual.
-
Page 12: Fcc Caution
FCC Caution Any changes or modifications not expressly approved by the responsible party could void the user's authority to operate this equipment. Notice: This module in its final integration requires the end-product to continue to comply with DFS requirements. A class II permissive change may be required for operation not already described in the FCC Grant filing. OEM Labeling Requirements Notice: The OEM of final integrator must ensure that FCC labeling requirements are met.
