Industrial Electronic Devices
User Manual
Revision 1.102
English
M-Bus - Repeater - Isolator
(Order Code: HD67032M, HD67032-B2-40, HD67032-B2-80,
HD67032-B2-160, HD67032-B2-250)
for Website information:
www.adfweb.com?Product=HD67032-B2-20
www.adfweb.com?Product=HD67032-B2-40
www.adfweb.com?Product=HD67032-B2-80
www.adfweb.com?Product=HD67032-B2-160
www.adfweb.com?Product=HD67032-B2-250
for Price information:
www.adfweb.com?Price=HD67032-B2-20
www.adfweb.com?Price=HD67032-B2-40
www.adfweb.com?Price=HD67032-B2-80
www.adfweb.com?Price=HD67032-B2-160
www.adfweb.com?Price=HD67032-B2-250
Benefits and Main Features:
Very easy to configure
Electrical isolation of M-Bus branches
Industrial temperature range: -40°C / 70°C (-40°F / 158°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual M-Bus – Repeater – Isolator
Document code: MN67032_ENG
Revision 1.102
For other M-Bus products see also the following link:
Converter M-Bus /
www.adfweb.com?Product=HD67021
www.adfweb.com?Product=HD67022
www.adfweb.com?Product=HD67030
M-Bus Analyzer - Scanner -Sniffer
www.adfweb.com?Product=HD67031
M-Bus / Modbus - Converter
www.adfweb.com?Product=HD67029M-232
www.adfweb.com?Product=HD67029M-485
M-Bus / Modbus TCP - Converter
www.adfweb.com?Product=HD67044
M-Bus / CANopen - Converter
www.adfweb.com?Product=HD67051-B2
M-Bus Master / PROFIBUS DP Slave - Converter
www.adfweb.com?Product=HD67053M
M-Bus - Concentrator - Datalogger
www.adfweb.com?Product=HD67054M
M-Bus Slave / Modbus Master - Converter
www.adfweb.com?Product=HD67059M-232
Do you have an your customer protocol? Then go to:
www.adfweb.com?Product=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Phone +39.0438.30.91.31
Page 1 of 26
(RS232)
(RS485)
(Ethernet)
(Modbus on RS232)
(Modbus on RS485)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADF Web HD67032M
Summary of Contents for ADF Web HD67032M
- Page 1 Page 1 of 26 Industrial Electronic Devices User Manual Revision 1.102 English M-Bus - Repeater - Isolator (Order Code: HD67032M, HD67032-B2-40, HD67032-B2-80, HD67032-B2-160, HD67032-B2-250) for Website information: For other M-Bus products see also the following link: www.adfweb.com?Product=HD67032-B2-20 www.adfweb.com?Product=HD67032-B2-40 Converter M-Bus / www.adfweb.com?Product=HD67021...
-
Page 2: Updated Documentation
1.102 03/07/2018 Revision SOFTWARE OPTIONS SET COMMUNICATION WARNING: UPDATE DEVICE (FOR HD67032M) UPDATE DEVICE (FOR HD67032-B2-XXX) ADFweb.com reserves the right to change information in this manual about DOWNLOAD CONF. our product without warning. MECHANICAL DIMENSIONS ADFweb.com is not responsible for any error this manual may contain. -
Page 3: Security Alert
User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 3 of 26 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Examples Of Connection
User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 4 of 26 Industrial Electronic Devices EXAMPLES OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 5 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 5 of 26 Industrial Electronic Devices ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
- Page 6 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 6 of 26 Industrial Electronic Devices ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 7: Connection Scheme
User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 7 of 26 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67032-B2-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 8 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 8 of 26 Industrial Electronic Devices CHARACTERISTICS: The HD67032 series are M-Bus - Repeater- Isolator with the following features: Electrical isolation of M-Bus branches; Baud Rate and Parity changeable with software; Mountable on 35mm DIN Rail;...
-
Page 9: Power Supply
User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 9 of 26 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 15…21V AC and 18…35V DC. The consumption depends to the code of the device. For more details see the two tables below. -
Page 10: Function Modes
User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 10 of 26 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending on the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’... - Page 11 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 11 of 26 Industrial Electronic Devices LEDS: The HD67032-B2-xxx device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
- Page 12 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 12 of 26 Industrial Electronic Devices M-BUS: The M-Bus is a unpolarized bus. A two wire standard telephone cable (JYStY N*2*0.8 mm) is used as the transmission medium for the M-Bus. The maximum distance between a slave and the repeater is 350m;...
- Page 13 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 13 of 26 Industrial Electronic Devices ETHERNET: The Ethernet port is used for programming the device. The Ethernet connection must be made using Connector2 of HD67032-B2-xxx with at least a Category 5E cable. The maximum length of the cable should not exceed 100m.
- Page 14 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 14 of 26 Industrial Electronic Devices USE OF COMPOSITOR SW67032: To configure the Converter, use the available software that runs with Windows called SW67032. It is downloadable from the site www.adfweb.com and its operation is described in this document (this manual is referenced to the last version of the software present on our web site).
-
Page 15: New Configuration / Open Configuration
User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 15 of 26 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “M-Bus –... -
Page 16: Software Options
User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 16 of 26 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. -
Page 17: Set Communication
Communication” button from the main window for SW67032 (Fig. 2) the window “Set Communication” appears (Fig. 3). The window is divided in two sections. In the section “Hardware Type” it is possible to define the hardware used: HD67032M; HD67032M-40/80/160/250; HD67032-B2. - Page 18 Document code: MN67032_ENG Revision 1.100 Page 18 of 26 Industrial Electronic Devices UPDATE DEVICE (for HD67032M-20): By pressing the “Update Device” button it is possible to load the created Configuration into the device, and also the Firmware if is necessary, using the RS232 port.
- Page 19 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 19 of 26 Industrial Electronic Devices UPDATE DEVICE (for HD67032-B2-xxx): By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn off the Device;...
- Page 20 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 20 of 26 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67032 device.
- Page 21 Conf.” button, it is possible to download the Configuration that is inside the device into the opened project. After having set the type of hardware used, it is possible to download it by serial (HD67032M-20 or HD67032M-40/80/160/250) or by Ethernet (HD67032-B2).
-
Page 22: Mechanical Dimensions
User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 22 of 26 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7: Mechanical dimensions for HD67032-B2-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 23: Ordering Informations
User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 23 of 26 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67032 – B 2 - xxx Maximum number of slaves supported 20: up to 20 standard slaves (1.5mA consumption) connected to M-Bus 40: up to 40 standard slaves (1.5mA consumption) connected to M-Bus... - Page 24 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 24 of 26 Industrial Electronic Devices ACCESSORIES: Order Code: APW020 Power Supply for M-Bus Master device that supports up to 20 Slaves Order Code: APW040 Power Supply for M-Bus Master device that supports up to 40 Slaves Order Code: APW080 Power Supply for M-Bus Master device that supports up to 80 Slaves...
- Page 25 User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 25 of 26 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
-
Page 26: Warranties And Technical Support
User Manual M-Bus – Repeater – Isolator Document code: MN67032_ENG Revision 1.100 Page 26 of 26 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
