D-Link DSL-100D Quick Install Manual page 10

DSL-100D/CZ Driver Installation Continued...
In the configuration window, make sure that PVC Setup is selected to ADSL
Service Provider.
The default ADSL Mode is set to
ANSI T1.413 Issue 2. Remove the
Check Mark from ANSI T1.413
Issue 2.
Check ITU G.992.1 Annex A
(G.dmt)
Click on "Set Mode."
Please wait approximate 2 minutes
for the ADSL mode to take its effect.
The link like will be turn off and then
will show once the connection is
made.
Click Close.
Note: If you are not sure of the correct settings, please contact your DSL
service provider for appropriate settings.
If any changes are made in the PVC Table, make sure that the settings comply
with the DSL provider's settings.
Highlight ADSL Service
Provider and click Edit.
10
