- Page 1 User’s Manual...
- Page 2 If you have any questions contact your Authorized Sherwood Scuba Dealer for immediate attention or you may contact us at www.sherwoodscuba.com. This User’s Manual contains signal words that are intended to designate levels of hazardous conditions.
- Page 3 WARNING Sherwood Scuba equipment is to be used only by individuals trained and certified by a nationally recognized scuba training agency. Diving without the necessary training in safe diving procedures or without observing the practices outlined by your training agency for your level of certification is extremely hazardous and could result in death or serious injury.
- Page 4 Deep Diving – Deeper than the generally recognized recreational diving limit at 1 feet of seawater. Decompression Diving – At combined depth and duration exposures requiring mandatory decompression stops. Cold Water Diving – Diving in water temperatures less than 0ºF (10ºC) may require special techniques to avoid conditions that could result in freezing conditions inside regulators and valves.
- Page 5 WARNING Nitrox: The SR1 is manufactured for use with standard air or enriched air nitrox (EAN) with an oxygen component not to exceed 0% at a maximum pressure of 00 psi (20) bar. If the regulator is used with standard air at any time it will no longer be suitable for use with nitrox unless it is reconditioned for nitrox use by a dealer or other expert trained in the proper cleaning methods.
- Page 6 CAUTION Chemicals & Lubricants: Do not use any lubricants on your regulator between service check-ups. No additional lubrication is required and use of an improper lubricant could introduce conditions adverse to respiratory health or increase the risk of a fire hazard. www.SherwoodScuba.com...
- Page 7 Registration is necessary to participate in Sherwood’s free service parts program and to receive product update notices. In order to qualify for free service parts every 2 months you must 1) Purchase your SR1 from an Authorized Sherwood Dealer, 2) Register your product with serial number included, ) Provide proof of service at intervals not exceeding every 2 months.
- Page 8 CAUTION After your SR1 and associated equipment has been configured be certain to assemble the unit to a diving cylinder and perform a simple test dive in shallow water in a controlled environment such as a pool to verify that the system performs normally and you are familiar with its operating characteristics.
-
Page 9: Operation
OPERATION NOTICE: The SR1 first stage is designed with a dry sealed spring chamber to keep water and other substances out of the interior of the first stage. This not only reduces interior corrosion of the first stage, it prevents ice formation in the spring chamber in cold water diving situations. - Page 10 Sealed Diaphragm www.SherwoodScuba.com...
- Page 11 ADJUSTMENT DURING THE DIVE The SR1 has only one user adjustment, the second stage knob. Adjusting this knob affects both the breathing effort and the venturi assisting effect. The operation of this knob is the same as most regulators of this type, and the easiest way to remember the operation is to think of the wheels on a car.
- Page 12 Back: minimum minimum performance Forward: performance maximum performance OUT: maximum performance www.SherwoodScuba.com...
- Page 13 When diving at the surface or when the regulator is out of the water, it is important to adjust the regulator sensitivity to the least sensitive position (rolled back, fully “IN”) to stop the venturi assisting effect and minimize the possibility of uncontrolled free flow of air.
-
Page 14: Authorized Service
(UV) exposure to maximize the life of the seals and other components. AUTHORIZED SERVICE In order to maintain the product warranty and optimum performance your SR1 must receive service from an Authorized Sherwood Dealer every 2 months or 00 hours of use, whichever comes first. Service includes disassembly, cleaning, replacement of o-rings and lubrication as necessary and adjustment for optimal performance. -
Page 15: Limited Lifetime Warranty
LIMITED LIFETIME WARRANTY Sherwood Scuba warrants that the SR1 model regulator purchased from Authorized Sherwood Scuba Dealers shall be free of defects in workmanship and materials for the lifetime of the original purchaser. Under this warranty Sherwood will either repair or replace, at its sole option, any original parts that fail to perform as intended. - Page 16 Under certain circumstances you may be eligible for free service parts. Consult your Authorized Sherwood Dealer to determine your eligibility. Sherwood specifically disclaims liability for any consequential, special or indirect damages arising out of use of your Sherwood regulator. Warranty laws in your state may affect your rights and should be consulted if you believe the terms of the warranty do not apply to you.
-
Page 17: Service Record
Purchase Date: First Stage S/N: Second Stage S/N: SERVICE RECORD Dealer Date Address Service Technician Signature Dealer Date Address Service Technician Signature Dealer Date Address Service Technician Signature www.SherwoodScuba.com... - Page 18 Dealer Date Address Service Technician Signature Dealer Date Address Service Technician Signature Dealer Date Address Service Technician Signature Dealer Date Address Service Technician Signature www.SherwoodScuba.com...
- Page 19 www.SherwoodScuba.com...
