Crystal Acoustics Cuby Quick Manual

Thank you for purchasing Crystal Acoustics Cuby
Cuby uses a unique driver design to create a fully immersive 360° room filling musical experience, as well as convenient, compact size for placing it
anywhere in your house.
Small yet powerful, it produces an unexpectedly deep and clear bass.
With Cuby, you can connect numerous devices and enjoy countless hours of non compromised listening.
Acoustic Features:
• 5 Drivers (Cuby-5MR), 9 drivers (Cuby-9MR) with Balanced Directivity for wide sound everywhere in the room
• Ideal In-Room response using WiSound technology
• Incredible Bass down to 38Hz (Cuby-5MR), 35Hz (Cuby-9MR)
Place it
1
Cuby uses a unique driver
WiSound Speaker
design. By positioning drivers
Drivers firing forward, sideways and upwards
at the sides and top, your
speaker can achieve an ideal
In-Room Response.
Thanks to its innovative design,
you can place your Cuby
anywhere in the room and
hear the sound perfection
everywhere.
For the optimal use of Cuby,
please remember not to cover
the unit's top and side
speakers.
Place it near the back wall
and not too far from the side
walls in order to have richer
reflections and three
dimensional sound field.
Of course, this is a useful hint
to enhance sound perfection,
contrary to conventional
speakers that suffer from wall
reflections.
C u b y Q u i c k G u i d e
Conventional Speaker Live Music
Front-firing speakers only Sound towards all directions
Connect it
2
Connect Cuby to your devices through:
1. Optical: If available, use this connection for best quality
2. RCA: Connect both left and right channels to your device
3. AUX 3.5mm: Connect to the headphone output of your device
4. USB: Play songs from your USB HDD/Flash or charge your phone/tablet
5. Ethernet: Get network access in case of no/weak Wi-Fi signal
Note: When the 3.5mm socket is used, it takes priority over the RCA input and it becomes the Auxiliary Source. In this case the RCA input is muted.
Note: To save power, Cuby will automatically turn off (in optical / line-in mode) if no sound has played through it for 30 minutes. It will automatically turn on again once it receives a signal.
Control it
3
Control Cuby by the unit's top panel keys, or the included remote control. Use either short or long press for dual function capability.
Long press
Power BT Pairing Volume Volume
ON/OFF Down Up
Radio Preset
Selector
PAIR / RADIO
Input Play/Pause Mute Previous Next
Selector Track Track
Short press
Note: If in maximum volume you are experiencing crackling sound during heavy Bass passages, the
protection mechanism for the amplifier and speaker drivers has been activated. Turn down the volume a bit!
Select it
4
Use the Ιnput button on the unit or on the remote control,
to cycle between the various available options:
Pair it [Βluetooth]
5
You can connect your Cuby with any Bluetooth enabled device (phone,tablet, computer, etc).
1. Select the Bluetooth input either on the unit or on the remote by cycling Inputs.
PAIR / RADIO
2. To pair a Bluetooth device to Cuby, press and hold the pairing button for about 5sec. The Bluetooth indicator LED will start blinking.
PAIR / RADIO
3. Consult the instructions of the device to be paired to connect to Cuby. Successful pairing will be signaled by a 'beep' from the unit and the
Bluetooth indicator LED will stop blinking.
Once paired, music from your device will play through the unit.
To add another Bluetooth device, repeat from step 2. Cuby may store up to eight paired devices in memory.
Power ON/OFF Mute
Play/Pause Volume Up
Previous Track Next Track
Volume Down
Web Radio Presets
Bluetooth Pairing
Learning Function Input Selector
Input colors are according to table:
Color Input
Blue Bluetooth
Red Optical
PAIR / RADIO
Green
Aux
Yellow Wi-Fi
ΟR
ΟR
